Cisco 200-125 Online Practice Questions and Exam Preparation

Cisco 200-125 Online Questions & Answers

• Question 471:

  Which condition that defines a DMVPN cloud is most important?

  A. It is a Layer 2 MPLS cloud that includes devices in different physical locations.
  B. It uses point-to-point links to connect hub pairs
  C. It uses point-to-point links to connect the hub and spoke routers.
  D. It uses mGRE tunnels to interconnect the hub and spoke routers.
  D. It uses mGRE tunnels to interconnect the hub and spoke routers.

• Question 472:

  Which Layer 2 protocol encapsulation type supports synchronous and asynchronous circuits and has built-in security mechanisms?

  A. HDLC
  B. PPP
  C. X.25
  D. Frame Relay
  B. PPP

  ---

  PPP: Provides router-to-router and host-to-network connections over synchronous and asynchronous circuits. PPP was designed to work with several network layer protocols, including IP. PPP also has built-in security mechanisms, such as Password Authentication Protocol (PAP) and Challenge Handshake Authentication Protocol (CHAP).

• Question 473:

  Which of these represents an IPv6 link-local address?

  A. FE80::380e:611a:e14f:3d69
  B. FE81::280f:512b:e14f:3d69
  C. FEFE:0345:5f1b::e14d:3d69
  D. FE08::280e:611:a:f14f:3d69
  A. FE80::380e:611a:e14f:3d69

  ---

  In the Internet Protocol Version 6 (IPv6), the address block fe80::/10 has been reserved for link-local unicast addressing. The actual link local addresses are assigned with the prefix fe80::/64. They may be assigned by automatic (stateless) or stateful (e.g. manual) mechanisms.

• Question 474:

  Which definition of default route is true?

  A. A route that is manually configured.
  B. A route used when a destination route is missing.
  C. A route to the exact /32 destination address
  D. Dynamic route learned from the server.
  B. A route used when a destination route is missing.

• Question 475:

  Which set of conditions comprises a successful ping attempt between two connected routers configured with IP addresses on the same subnet?

  A. The destination host receives an echo reply from the source host within one second and the source host receives an echo request from the destination host.
  B. The destination host receives an echo request from the source host within one second.
  C. The destination host receives an echo replyfrom the source host within one second and the source host receives an echo reply from the destination host within two seconds.
  D. The destination host receives an echo request from the source host and the source host receives an echo request from the destination host within one second.
  E. The destination host receives an echo request from the source host and the source host receives an echo reply from the destination host within two seconds.
  E. The destination host receives an echo request from the source host and the source host receives an echo reply from the destination host within two seconds.

• Question 476:

  what are two common types of copper cable ?(choose two)

  A. OM4
  B. shielded twisted pair
  C. single-mode
  D. multimode
  E. unshielded twisted pair
  B. shielded twisted pair
  E. unshielded twisted pair

• Question 477:



  You are verifying the EIGRP configurations in the topology. Which statement is true?

  A. Branch2 Lan network 172.16.11.0/24 is not advertised into the EIGRP network.
  B. Branch2 Lan network 172.16.10.0/24 is not advertised into the EIGRP network.
  C. R3 server farm2 network 10.20.30.0/24 is not advertised into the EIGRP network.
  D. Branch1 Lan network 172.16.12.0/24 is not advertised into the EIGRP network.
  D. Branch1 Lan network 172.16.12.0/24 is not advertised into the EIGRP network.

• Question 478:

  What are two drawbacks of implementing a link-state routing protocol? (Choose two.)

  A. the sequencing and acknowledgment of link-state packets
  B. the high volume of link-state advertisements in a converged network
  C. the requirement for a hierarchical IP addressing scheme for optimal functionality
  D. the high demand on router resources to run the link-state routing algorithm
  E. the large size of the topology table listing all advertised routes in the converged network
  C. the requirement for a hierarchical IP addressing scheme for optimal functionality
  D. the high demand on router resources to run the link-state routing algorithm

• Question 479:

  What is the function of the command switchport trunk native vlan 999 on a Cisco Catalyst switch?

  A. It creates a VLAN 999 interface.
  B. It designates VLAN 999 for untagged traffic.
  C. It blocks VLAN 999 traffic from passing on the trunk.
  D. It designates VLAN 999 as the default for all unknown tagged traffic.
  B. It designates VLAN 999 for untagged traffic.

  ---

  Configuring the Native VLAN for Untagged Traffic A trunk port configured with 802.1Q tagging can receive both tagged and untagged traffic. By default, the switch forwards untagged traffic in the native VLAN configured for the port. The native VLAN is VLAN 1 by default.

• Question 480:

  Exhibit: After you apply the given configuration to R1, you determine that it is failing to advertise the 172.16.10.32/27 network which action is most likely to correct the problem ?



  A. enable passive interface
  B. enable manual summarization
  C. enable autosummarization
  D. enable RIPV2
  D. enable RIPV2
