Cisco 200-125 Online Practice Questions and Exam Preparation

Cisco 200-125 Online Questions & Answers

• Question 111:

  which two pins does an RJ-45 connector use to transmit data?(choose two)

  A. 1
  B. 2
  C. 3
  D. 4
  E. 6
  A. 1
  B. 2

• Question 112:

  Which two networking standards use copper cable? (Choose two)

  A. 100BASE-LX
  B. 10BASE-T
  C. 802 11ac
  D. 802.3d
  E. 802.3
  A. 100BASE-LX
  B. 10BASE-T

• Question 113:

  Which protocol verifies connectivity between two switches that are configured with IP addresses in the same network?

  A. ICMP
  B. STP
  C. VTP
  D. HSRP
  A. ICMP

• Question 114:

  Refer to the exhibit.



  The two connected ports on the switch are not turning orange or green. What would be the most effective steps to troubleshoot this physical layer problem? (Choose three.)

  A. Ensure that the Ethernet encapsulations match on the interconnected router and switch ports.
  B. Ensure that cables A and B are straight-through cables.
  C. Ensure cable A is plugged into a trunk port.
  D. Ensure the switch has power.
  E. Reboot all of the devices.
  F. Reseat all cables.
  B. Ensure that cables A and B are straight-through cables.
  D. Ensure the switch has power.
  F. Reseat all cables.

  ---

  The ports on the switch are not up indicating it is a layer 1 (physical) problem so we should check cable type, power and how they are plugged in.

• Question 115:

  Which NTP type designates a router without an external reefrence clock as an authoritative time source?

  A. server
  B. peer
  C. master
  D. client
  C. master

• Question 116:

  What are three parts of an IPv6 global unicast address? (Choose three.)

  A. an interface ID that is used to identify the local host on the network
  B. an interface ID that is used to identify the local network for a particular host
  C. a subnet ID that is used to identify networks inside of the local enterprise site
  D. a global routing prefix that is used to identify the network portion of the address that has been provided by an ISP
  E. a global routing prefix that is used to identify the portion of the network address provided by a local administrator
  A. an interface ID that is used to identify the local host on the network
  C. a subnet ID that is used to identify networks inside of the local enterprise site
  D. a global routing prefix that is used to identify the network portion of the address that has been provided by an ISP

• Question 117:

  When a switch is running in VTP server mode, VLAN configuration information is stored in which file?

  A. config.text
  B. vlan.config
  C. startup-config
  D. vlan-dat
  D. vlan-dat

• Question 118:

  Drag and Drop the descriptions of IP protocol transmissions from the left onto the correct IP traffic types on the right.

  Select and Place:





• Question 119:

  which command should you enter to configure an LLDP delay time of 5 seconds?

  A. lldp timer 5000
  B. lldp holdtime 5
  C. lldp reinit 5000
  D. lldp reinit 5
  D. lldp reinit 5

• Question 120:

  Which effect of the copy tftp:flash: command is true?

  A. It copies the startup configuration from a remote server to the local device.
  B. It copies the system image from the local device to a remote server.
  C. It copies the running configuration from the local device to a remote server.
  D. It copies the system image from a remote server to the local device.
  D. It copies the system image from a remote server to the local device.
