CheckPoint Checkpoint Certifications 156-115.77 Questions & Answers

• Question 201:

  What file contains IKEv2 debug messages?

  A. $FWDIR/log/ikev2

  B. $FWDIR/log/ike.xml

  C. $FWDIR/log/vpnd.elg

  D. $FWDIR/log/ike.elg

  Correct Answer: A

• Question 202:

  What is the log file that shows the keep alive packets during the debug process?

  A. $FWDIR/log/ikev2.xmll

  B. $FWDIR/log/ike.xmll

  C. $FWDIR/log/ike.elg

  D. $FWDIR/log/vpnd.elg

  Correct Answer: C

• Question 203:

  Which command displays compression/decompression statistics?

  A. vpn ver k

  B. vpn compstat

  C. vpn compreset

  D. vpn crlview

  Correct Answer: B

• Question 204:

  What debug file would you check to see what IKE version is being used?

  A. fwpnd.elg

  B. vpn.txt

  C. debug.txt

  D. vpnd.elg

  Correct Answer: D

• Question 205:

  You are in VPN troubleshooting with a Partner and you suspect a mismatch configuration in Diffie- Hellman (DH) group to Phase1. After starting a vpn debug, in which packet would you look to analyze this option in your debug file?

  A. Packet3

  B. Packet4

  C. Packet5

  D. Packet1

  Correct Answer: D

• Question 206:

  The file ike.elg is a log file used to log IKE negotiations during VPN tunnel establishment. Where is this file located?

  A. /opt/CPshrd-R77/log

  B. /opt/CPsuite-R77/fw1/log

  C. /var/log/opt/CPsuite-R77/fg1/log

  D. /opt/CPsuite-R77/fg1/log

  Correct Answer: B

• Question 207:

  What is the function of the setting "no_hide_services_ports" in the tables.def files?

  A. Preventing the secondary member from hiding its presence by not forwarding any packets.

  B. Allowing management traffic to be accepted in an applied rule ahead of the stealth rule.

  C. Hiding the particular tables from being synchronized to the other cluster member.

  D. Preventing outbound traffic from being hidden behind the cluster IP address.

  Correct Answer: D

• Question 208:

  Which command will you run to list established VPN tunnels?

  A. fw tab -t vpn_active

  B. vpn compstat

  C. fw tab -t vpn_routing

  D. vpn tu

  Correct Answer: D

• Question 209:

  Your customer has an R77 Multi-domain Management Server managing a mix of firewalls of R70 and R77 versions. A change was made to the file $FWDIR/lib/tables.def on one of the domains. However, it was found that the change was not applied to the R70 firewalls. What could be the problem?

  A. Changes to the table.def can only be applied to firewalls matching the Management Server version. The customer needs to upgrade the firewalls to the same version as the firewall.

  B. R70 is end of life and is not supported. Most functions will work, but modifying the table.def will not.

  C. In order to make changes on R70 machines you need work within GuiDBedit

  D. To support R70, the file in the compatibility directory should have been modified.

  Correct Answer: D

• Question 210:

  Your customer reports that the time on the standby cluster member is not correct. After failing over and making it active, the time is now correct. NTP has been configured on both machines, so it is expected that both machines be in sync with the NTP server. Upon investigating, it was found that the standby member was never able to communicate with the NTP server while it was in standby configuration. What could be the problem?

  A. You should be syncing your backup to the primary for time settings.

  B. NTP is not supported in active-passive mode.

  C. Traffic from the standby member was hidden behind the cluster IP address and was therefore returning to the active member.

  D. Routing prevents the standby member from performing functions such as peering with dynamic routing and obtaining NTP updates.

  Correct Answer: C
