Cisco CCT 010-151 Questions & Answers

• Question 41:

  Which two commands allow you to view the state of high availability between the two clustered Fabric Interconnects? (Choose two.)

  A. show cluster state extended

  B. show cluster extended-state

  C. show cluster HA status

  D. show cluster state

  E. show cluster HA state

  Correct Answer: BD

• Question 42:

  Which statement about RAID is true?

  A. RAID is a scheme used to logically combine several independent disks to form an array or group of drives.

  B. RAID provides data redundancy with either odd parity or even parity.

  C. RAID drive group appears to the host computer as multiple physical storage units.

  D. RAID parity information can be stored across multiple RAID levels.

  E. RAID stores data in the array with data striping, encryption, and parity to organize the data among the disks.

  Correct Answer: A

• Question 43:

  Which two statements about the Ethernet media are true? (Choose two.)

  A. A twisted-pair cable system has each pair of wires twisted together to reduce electromagnetic interference.

  B. Compared to multimode fiber, the single-mode fiber is designed for shorter distances with higher cost.

  C. 40 Gigabit Ethernet twinax cables deploy Enhanced Quad Small Form Factor Pluggable (QSFP+) connectors.

  D. The twinax cables can be found in either a shielded twisted-pair or an unshielded twisted-pair variation.

  E. A passive twinax cable can carry an Ethernet signal over 5m.

  Correct Answer: AC

• Question 44:



  Refer to the exhibit. Which statement correctly identifies the hardware features on the Cisco Nexus 9500 Series supervisor A modules?

  A. A is 10/100/1000 Management port; B is USB port; C is Console port; D is external clock input B. A is Console port; B is USB port; C is 10/100/1000 Management port; D is external clock input

  C. A is Optical port; B is USB port; C is 10/100/1000 Management port; D is external clock input

  D. A is Console port; B is USB port; C is 10/100/1000 Management port; D is Diagnostic port

  Correct Answer: B



  Reference: https://www.cisco.com/c/en/us/products/collateral/switches/nexus-9000-series-switches/white-paper-c11-729987.html

• Question 45:

  In Cisco UCS C480 M5 server, which PCle slot is the default slot for the rear RAID controller when the rear drive module is used with SAS/SATA drives?

  A. PCle slot 09

  B. PCle slot 10

  C. PCle slot 11

  D. PCle slot 12

  Correct Answer: C

  Reference: https://www.cisco.com/c/en/us/td/docs/unified_computing/ucs/c/hw/C480M5/install/C480M5/C480M5_chapter_01.html

• Question 46:

  When activating the firmware via UCSM which two firmware versions must be activated at the same time?

  A. UCS Manager and System

  B. UCS Manger and Kernel

  C. CIMC and Kernel

  D. System and Kernel

  Correct Answer: D

  Reference:

  https://www.cisco.com/c/en/us/td/docs/unified_computing/ucs/ucs-manager/GUI-User-Guides/Fifirmware-Mgmt/3-1/ b_UCSM_GUI_Fifirmware_Management_Guide_3_1/

  b_UCSM_GUI_Fifirmware_Management_Guide_3_1_chapter_011.html

• Question 47:

  What are two common steps to troubleshooting a rack server with unrecognized or memory errors? (Choose two.)

  A. Ensure DIMMs are installed in correct slots

  B. Check CPU sockets for bent pins

  C. Check that the AC power cord is OK

  D. Reseat DIMMs

  E. Check the front I/O cable connection to the motherboard

  Correct Answer: AD

  Reference: https://www.cisco.com/c/en/us/td/docs/unified_computing/ucs/c/ts/guide/b_C-Series_Troubleshooting_Guide.pdf page 11

• Question 48:

  Which Cisco UCS Virtual Interface Card Series is designed exclusively for the M5 generation?

  A. M81KR VIC

  B. VIC 1400 Series

  C. VIC 1300 Series

  D. VIC 1200 Series

  Correct Answer: B

  Reference: https://www.cisco.com/c/dam/en/us/products/collateral/interfaces-modules/unified-computing-system-adapters/whitepaper-c11-741550.pdf

• Question 49:

  What enables NVM Express host software to communicate with nonvolatile memory?

  A. SATA

  B. SAS

  C. PCle

  D. SCSI

  Correct Answer: C

  Reference:

  https://nvmexpress.org/wp-content/uploads/NVM-Express-1_4-2019.06.10-Rati ed.pdf page 6

• Question 50:

  Which two transceivers can support 100 Gigabit Ethernet? (Choose two.)

  A. SFP+

  B. SFP28

  C. QSFP+

  D. QSFP28

  E. SFP-DD

  Correct Answer: CD
