VMware VCPN610 Online Practice Questions and Exam Preparation

VMware VCPN610 Online Questions & Answers

• Question 41:

  Which port is used for NSX REST API Requests?

  A. 80
  B. 443
  C. 5480
  D. 8443
  B. 443

• Question 42:

  -- Exhibit



  -- Exhibit -An administrator is testing connectivity between two ESXi hosts and uses the ping utility.

  Based on the results shown in the exhibit, which statement is correct?

  A. Communication between the hosts is working correctly.
  B. The hosts are in separate subnets.
  C. The MTU size is too small.
  D. A logical router has not been deployed and configured.
  C. The MTU size is too small.

• Question 43:

  -- Exhibit



  -- Exhibit -An administrator has configured an NSX network as shown:

  Both VM-A and VM-B use the same Distributed Router for their default gateway.

  If VM-A sends a packet to VM-B,what happens to the packet before it reaches VM-B?

  A. Distributed Router in Host-A receives the packet from VM-A and forwards it to Logical Switch 7775 in Host-B, via a VXLAN frame, which delivers it to VM-B.
  B. Logical Switch 7321 in Host-A receives the packet inside a frame from VM-A and forwards it to Logical Switch 7775 in Host-B, via a VXLAN frame, which delivers it to VM-B.
  C. Distributed Router in Host-A receives the packet from VM-A and forwards it to Logical Switch 7321 in Host-B, via a VXLAN frame, which delivers it to Logical Switch 7775 before it is delivered to VM-B.
  D. Logical Switch 7321 in Host-A receives the packet from VM-A and forwards it to the Distributed Router in Host-B, which passes it along to Logical Switch 7775 in Host-B before it is delivered to VM
  A. Distributed Router in Host-A receives the packet from VM-A and forwards it to Logical Switch 7775 in Host-B, via a VXLAN frame, which delivers it to VM-B.

• Question 44:

  Which statement is correct when upgrading vShield Data Security to NSX Data Security?

  A. NSX Data Security does not support a direct upgrade.
  B. NSX Controller must be deployed before the upgrade.
  C. The vCloud Network and Security Virtual Wires must have been upgraded.
  D. vCould Network and Security must be at least version 5.1 before starting the upgrade.
  A. NSX Data Security does not support a direct upgrade.

• Question 45:

  Which two configurations are valid on a vSphere Standard Switch using the vSphere Web Client? (Choose two.)

  A. Enable the use of SR-IOV for a physical adapter.
  B. Set the MTU frame size on the vSwitch.
  C. Configure Route Based on Physical NIC Load on a nic team.
  D. Configure Port Mirroring on a portgroup.
  A. Enable the use of SR-IOV for a physical adapter.
  B. Set the MTU frame size on the vSwitch.

• Question 46:

  A vSphere administrator deploys the NSX Edge Load Balancer in Inline mode. Which is not a requirement for the Load Balancer to operate correctly?

  A. Perform Source NAT on the traffic from the clients.
  B. Connect the Load Balancer directly to the same subnet as the VMs that are part of the Server Pool.
  C. Perform Destination NAT on the traffic from the clients.
  D. Point the virtual machines in the Server Pool to the Load Balancer as their default gateway.
  A. Perform Source NAT on the traffic from the clients.

• Question 47:

  Your data center is made up of two VMware vCenter Server instances. Each vCenter Server manages three clusters with 16 hosts per cluster. In preparing for your VMware NSX deployment, how many vShield Endpoint instances will you have?

  A. 2
  B. 6
  C. 48
  D. 96
  D. 96

• Question 48:

  How is the Bridge Instance chosen?

  A. It is chosen based on the ESXi host where the Logical Router Control VM is running.
  B. It is manually assigned by the vSphere administrator when the distributed portgroup is configured.
  C. During an election process among all ESXi hosts. The host with the highest MAC address is selected.
  D. The VTEP configured with the highest VXLAN Network Identifier (VNI) is selected.
  A. It is chosen based on the ESXi host where the Logical Router Control VM is running.

• Question 49:

  Which service cannot be included in a Security Policy using Service Composer?

  A. Endpoint Services
  B. Firewall Rules
  C. Virtual Private Network Services
  D. Network Introspection Services
  C. Virtual Private Network Services

• Question 50:

  Using VMware's best practices, choose two statements that define the best solution for scaling layer 2 services for the virtual network. (Choose two.)

  A. Employ a layer 2 switched network.
  B. Employ a layer 3 switched network.
  C. Use GRE for an overlay network.
  D. Use VXLAN for an overlay network.
  B. Employ a layer 3 switched network.
  D. Use VXLAN for an overlay network.
