VMware VCP-510 Online Practice Questions and Exam Preparation

VMware VCP-510 Online Questions & Answers

• Question 21:

  When deploying an OVF template, the resulting virtual disk is created in what file format?

  A. OVF
  B. VMDK
  C. VMX
  D. VSWP
  B. VMDK

• Question 22:

  Click the Exhibit button. An administrator has received reports of poor network performance with a virtual machine. Which task will improve the network performance of this virtual machine?



  A. Adjust shares for the virtual NIC on the virtual machine.
  B. Traffic-shape this virtual machine.
  C. Move the virtual machine to another virtual switch.
  D. Add a CPU to the virtual machine.
  C. Move the virtual machine to another virtual switch.

• Question 23:

  What are possible valid uses for the default No Access role in vCenter? (Choose two.)

  A. Restrict usage on a object for a member of a group assigned full permissions to the object
  B. Restrict access to sensitive VMs for helpdesk staff
  C. Restrict ESX Admins from managing specific hosts directly
  D. Restrict administrators from managing hosts via vCenter
  B. Restrict access to sensitive VMs for helpdesk staff
  D. Restrict administrators from managing hosts via vCenter

• Question 24:

  The VMware vCenter Server Appliance has been deployed using default settings. What user name and password are used to log in to the administration interface to configure the appliance?

  A. The initial user name and password must be supplied on the first login attempt.
  B. The initial user name and password must be supplied during deployment.
  C. The initial user name is root and the password is blank.
  D. The initial user name is root and the password is vmware.
  D. The initial user name is root and the password is vmware.

• Question 25:

  An existing vSphere 4 environment will be upgraded to vSphere 5.x. The current implementation utilizes ESXi 4.1 and the new implementation will use ESXi 5.x. In which two ways will the new ESXi 5.x implementation differ from the ESXi 4.1 implementation? (Choose two.)

  A. VMware ESXi 5.x provides a host-based firewall.
  B. VMware ESXi 5.x can boot from additional local sources such as a USB drive.
  C. VMware ESXi 5.x can be managed from a web browser.
  D. VMware ESXi 5.x can support virtual machines with larger hard drive configurations.
  B. VMware ESXi 5.x can boot from additional local sources such as a USB drive.
  D. VMware ESXi 5.x can support virtual machines with larger hard drive configurations.

• Question 26:

  What are two requirements for successful vMotion migration? (Choose two.)

  A. CPUs with matching SpeedStep settings must exist on both the source and destination hosts.
  B. Virtual machines must not utilize hardware local to the host such as SCSI pass-through.
  C. Virtual machines must not have a CDROM connected via the vSphere client.
  D. Dedicated Gigabit Ethernet Networking must exist between the source and destination hosts.
  B. Virtual machines must not utilize hardware local to the host such as SCSI pass-through.
  C. Virtual machines must not have a CDROM connected via the vSphere client.

• Question 27:

  When defining a NIC team (bond) on an vNetwork Standard Switch, it is possible to designate some of the physical NICs that make up the bond as "standby" NICs. Which statement most accurately describes the purpose of a standby NIC?

  A. Used to implement traffic shaping for the rest of the team.
  B. Used only in the case of the failure of other NICs in the team.
  C. Not used as part of the team until activated by the administrator.
  D. Used only when network traffic exceeds the capacity of the rest of the team.
  B. Used only in the case of the failure of other NICs in the team.

• Question 28:

  Which two are requirements when booting from SAN? (Choose Two)

  A. The Storage Array port WWN specified in the BIOS configuration of the HBA must be passive
  B. The HBA should be plugged into the lowest PCI bus and slot number
  C. The boot LUN should only be visible to the ESX Server that is booting from it
  D. The boot LUN should be visible to all ESX Servers for HA failover
  B. The HBA should be plugged into the lowest PCI bus and slot number
  C. The boot LUN should only be visible to the ESX Server that is booting from it

• Question 29:

  An administrator has determined that storage performance to a group of virtual machines is reduced during peak activity.

  The virtual machines are located in a VMFS datastore called Production1 on an active-active storage array.

  The ESXi 5.x host running the virtual machines is configured with an MRU multipathing policy. Which two actions can be taken to improve the storage performance of these virtual machines? (Choose two.)

  A. Add virtual storage, create a VMFS datastore called Production2 on the new storage, and then migrate some of the virtual machines from Production1 to Production2.
  B. Change the storage multipathing policy to Round Robin.
  C. Add physical storage, create a VMFS datastore called Production2 on the new storage, and then migrate some of the virtual machines from Production1 to Production2.
  D. Change the storage multipathing policy to Fixed with default settings.
  B. Change the storage multipathing policy to Round Robin.
  C. Add physical storage, create a VMFS datastore called Production2 on the new storage, and then migrate some of the virtual machines from Production1 to Production2.

• Question 30:

  An administrator is using Update Manager 5.0 to update virtual appliances in a vSphere environment. The environment is using the vCenter Server appliance. The administrator is unable to remediate the vCenter Server appliance. What would cause the remediation to fail?

  A. Updating of the appliance can only be done if the vCenter Server Appliance has been
  B. Remediation must be configured on the Appliance Administration page before use
  C. Remediation of the vCenter Server Appliance with Update Manager is not supported
  D. Remediation of the vCenter Server Appliance must be done from the PowerCLL
  C. Remediation of the vCenter Server Appliance with Update Manager is not supported
