VMware VCP-510 Online Practice Questions and Exam Preparation

VMware VCP-510 Online Questions & Answers

• Question 191:

  A vSphere environment is created with two virtual machines, VM23 and VM43. Each virtual machine has an instance of the front-end web application for the company's manufacturing management database. A physical load-balancer is configured for the application. Which type of DRS rule should be implemented for VM23 and VM43?

  A. Separate Virtual Machines
  B. Virtual Machines to Hosts
  C. Host DRS Groups
  D. Keep Virtual Machines Together
  A. Separate Virtual Machines

• Question 192:

  An administrator is configuring Storage DRS in their environment. The Datastore cluster is composed of 4 VMFS3 volumes and 9 VMFS5 volumes.

  Storage DRS has been enabled, but is showing as disabled on several virtual machine disks in the datastore cluster.

  Which two conditions would cause this error to occur? (Choose two.)

  A. The virtual machine is stored on a VMFS 3 volume.
  B. One or more virtual machines have Persistent disks.
  C. The virtual machine is stored on a NFS datastore.
  D. The virtual machine is stored on a datastore with a 2mb block size.
  A. The virtual machine is stored on a VMFS 3 volume.
  B. One or more virtual machines have Persistent disks.

• Question 193:

  Click the Exhibit button. For the selected item, what two properties could the storage administrator use to create a zone? (Choose two.)



  A. 20.00.00.1b.32.13.14.a7
  B. vmhba1.C0.T0.L1
  C. fc.2000001b321314a7.2100001b321314a7
  D. 50.06.01.60.c1.e0.65.22
  A. 20.00.00.1b.32.13.14.a7
  D. 50.06.01.60.c1.e0.65.22

• Question 194:

  Several virtual machines residing in a resource pool are exhibiting pools and critical virtual machines in the pool appear hung. The resource pool has been allocated exactly 500MHz of CPU and does not have the Expandable Reservation option selected. The cluster in which the resource pool resides has a total of 6000MHz, with 1000MHz available. Which step can be used to increase the performance of the critical vms?

  A. Increase the CPU limit on the critical virtual machine.
  B. Increase the CPU reservations on the critical virtual mach
  C. Increase the CPU reservations on the resource pool
  D. Increase the CPU limit on the resource pool
  C. Increase the CPU reservations on the resource pool

• Question 195:

  An administrator has deployed a vCenter Server to manage a virtual environment. The administrator has been asked to develop a plan for handling major upgrades to the application. What should be included in the upgrade plan?

  A. Utilize vCenter Configuration Manager to upgrade the vCenter Server in place
  B. Install a new vCenter Server and import the information from the existing vCenter Server
  C. Install a new vCenter Server over the existing vCenter Server as an in-place upgrade
  D. Utilize Update Manager to upgrade the vCenter Server in place
  B. Install a new vCenter Server and import the information from the existing vCenter Server

• Question 196:

  An administrator is configuring a vNetwork Standard Switch for load balancing. The physical network is configured for switch-assisted load balancing using EtherChannel. Which load- balancing policy must be used to support this configuration?

  A. Route based on source MAC hash
  B. Route based on IP hash
  C. Route based on the originating port ID
  D. Route using Round-Robin
  B. Route based on IP hash

• Question 197:

  An administrator is using Update Manager 5.x to update virtual appliances in a vSphere environment. The environment is using the vCenter Server Virtual Appliance (vCSA). What would cause the remediation to fail?

  A. Updating of the appliance can only be done if the vCenter Server Virtual Appliance (vCSA) has been put into Maintenance Mode.
  B. Remediation must be configured on the Appliance Administration page before use.
  C. Remediation of the vCenter Server Virtual Appliance (vCSA) with Update Manager is not supported.
  D. Remediation requires the hosts to be connected to vCenter using an IPv4 address.
  D. Remediation requires the hosts to be connected to vCenter using an IPv4 address.

• Question 198:

  Click the Exhibit button. An administrator has deployed a two-node cluster with HA and DRS enabled. DRS has been configured for fully automated mode. The management and vMotion interfaces have been configured on separate physical networks. Initial DRS testing on this cluster reveals that virtual machines are not being migrated despite great disparity in resource use between the ESX hosts in the cluster. The exhibit shows the error and the network configuration for one of the hosts. Which task would successfully resolve this problem?



  A. Add a vmnic to the VMkernel port
  B. Configure the DRS Migration Threshold to Aggressive
  C. Connect the network cable to the correct physical network
  D. Migrate virtual machines manually using vMotion
  C. Connect the network cable to the correct physical network

• Question 199:

  Users are complaining that a Windows application server virtual machine configured with 1GB RAM is not performing satisfactorily. The virtual machine is in a fully automated DRS cluster. An administrator opens the Performance tab for the

  guest virtual machine and adds the counters for Memory Ballooned and Memory Swapped in MB. The performance chart displays a value of 0 for Memory Ballooned and 240 for Memory Swapped.

  Which action should be taken?

  A. Install VMware Tools into the virtual machine.
  B. Adjust Mem.CtlMaxPercent to read 75.
  C. Migrate the virtual machine to another host.
  D. Add memory to the virtual machine.
  A. Install VMware Tools into the virtual machine.

• Question 200:

  Windows VM is experiencing the poor application performance. The suspected issue is a lack of available memory. Windows Task Manager shows 30% of the memory within the VM is not currently being used. What this indicate and what could be checked next?

  A. Windows Task Manager is not reading actual memory usage in the VM. Windows System Monitor should be used to get precise reading on memory usage.
  B. The application problems are defintely due to a non-memory related problem. CPU affinity settings should be checked for this VM.
  C. The VM has memory available, however it may not actually have "Physical" memory available. VMkernel swap activity on the ESX Server host should be checked next.
  D. The application problems are definitely due to a non-memory related problem. CPU utilization should be checked next using Windows Task Manager.
  C. The VM has memory available, however it may not actually have "Physical" memory available. VMkernel swap activity on the ESX Server host should be checked next.
