OMG-OCUP-300 Real Exam Questions

OMG-Certified UML Professional - Advanced

134 questions available · Page 1 of 14

Updated Exam DumpsVerified AnswersPass Guarantee

Get Complete Exam Dumps
Question 1 Single choice

What is usually true of an Execution Environment?

  1. A

    an implementation of a state machine

  2. B

    a standalone type of node

  3. C

    part of a more general node

  4. D

    an infrastructure in which actions occur

Show answer and explanation

Correct answer: C

Question 2 Multiple choice

An association class possesses the properties of which elements? (Choose two)

  1. A

    association

  2. B

    interface

  3. C

    class

  4. D

    constraint

  5. E

    expression

Show answer and explanation

Correct answers: A, C

Question 3 Single choice

What is wrong with the collaboration occurrence shown in the exhibit?

  1. A

    The <<role>> keywords are missing.

  2. B

    The <<occurrence>> keyword is missing.

  3. C

    Client and Server role names should be underlined.

  4. D

    The collaboration occurrence name should be underlined.

  5. E

    Role bindings should be represented by dashed lines.

Show answer and explanation

Correct answer: E

Question 4 Single choice

What can be used when the source of an object flow has values of type Customer, and the target needs the name of the customer?

  1. A

    transformation

  2. B

    effect

  3. C

    weight

  4. D

    ordering

  5. E

    selection

  6. F

    upper bound

Show answer and explanation

Correct answer: A

Question 5 Single choice

How is a power type name indicated in a diagram?

  1. A

    enclosed by guillemots

  2. B

    preceded by a colon

  3. C

    preceded by an equal sign

  4. D

    enclosed by braces

Show answer and explanation

Correct answer: B

Question 6 Single choice

What happens if the explicit context declaration is omitted from an OCL statement on a diagram?

  1. A

    Nearest operation is made the context.

  2. B

    Nearest classifier is made the context.

  3. C

    Context may be specified by a dashed line.

  4. D

    Last identified context is used.

  5. E

    Statement is malformed.

Show answer and explanation

Correct answer: C

Question 7 Single choice

A DeploymentSpecification serves what purpose?

  1. A

    indicates the kind of casters upon which a device sits

  2. B

    gives a deployment a name so it can be referenced in constraints

  3. C

    describes the type of input-output medium used to create a deployment

  4. D

    parameterizes a deployment relationship

Show answer and explanation

Correct answer: D

Question 8 Single choice

What is true about an information flow?

  1. A

    requires that a relationship (dependency, association, connector, etc.) does not exist between sources and targets

  2. B

    defines the order in which information is exchanged

  3. C

    may directly indicate a concrete element such as a class, and is conveyed instead of using an information item

  4. D

    requires that a relationship (dependency, association, connector, etc.) exists between sources and targets

Show answer and explanation

Correct answer: C

Question 9 Single choice

What standard UML stereotype best captures a component's ability to represent larger-scale features of a data processing installation?

  1. A

    <<specification>>

  2. B

    <<subsystem>>

  3. C

    <<systemModel>>

  4. D

    <<realization>>

  5. E

    <<installation>>

Show answer and explanation

Correct answer: B

Question 10 Single choice

In the protocol state machine exhibited, what does m1 represent?

  1. A

    part of a guard condition for the transition between S1 and S2

  2. B

    an operation that is a feature of the corresponding interface

  3. C

    a method corresponding to operation m1

  4. D

    an invocation of the operation m1 of the corresponding interface

Show answer and explanation

Correct answer: B
