• Question 91:

  Which organizational entities do the process areas of maturity level 2 of the Business Process Maturity Model (BPMM) focus on?

  A. work units
  B. business area managers
  C. information technology operations
  D. end-to-end product and service offerings
  A. work units

  ---

  Explanation

  In the Object Management Group (OMG) Business Process Maturity Model (BPMM), each maturity level is characterized by a specific scope of focus and a defined set of process areas. For Maturity Level 2 - Managed, BPMM clearly states that the emphasis is on bringing basic management discipline to individual organizational units where work is performed, typically called work units (e.g., departments, teams, projects, operational units).

  At this level: Processes are planned, performed, monitored, and controlled at the work unit level. The goal is to ensure that commitments are met, performance is tracked, and issues are managed within these units.

  Process areas at Level 2 (such as those concerned with work unit management, performance, and corrective action) explicitly assume that theprimary organizational entity of concern is the work unit, not yet the end-to-end, cross-functional business process.

  This is a key distinction in BPMM: Level 1 (Initial):Work is performed, but processes are ad hoc and largely unmanaged. Level 2 (Managed):Processes are managed within work units. The discipline of basic planning, monitoring, and control is introduced at this local level.

  Level 3 (Standardized):Processes become standardized and harmonized across the organization, and attention shifts to end-to-end processes that cut across functional and organizational boundaries. Higher levels (4 and 5) further institutionalize measurement, predictability, and continuous optimization across these standardized processes.

  Given this structure:

  Option A - work units Correct. This is exactly the organizational focus of Level 2 process areas in BPMM.

  Option B - business area managers

  While business area managers may be involved, BPMM does not define maturity level 2 as focusing on managers as entities; it focuses on work units as the organizational locus of process management.

  Option C - information technology operations IT operations may constitute a particular type of work unit, but BPMM Level 2 is not limited to IT; it is generic to all work units across the enterprise. Therefore, this is too narrow and not aligned with the model's definition.

  Option D - end-to-end product and service offerings.

  This reflects a Level 3 and above concern, where cross-functional, end-to-end processes are standardized and managed as a whole. It is not the focus of maturity level 2, which is still concentrated on the local, work-unit perspective.

  Accordingly, based on the OMG Business Process Maturity Model specification, the process areas at maturity level 2 focus on work units as the primary organizational entities.

• Question 92:

  Which statement correctly states the order of sending and receiving Messages between the Producer and the Consumer?



  A. Consumer sends Message 1 to Producer; Producer sends Message B to Consumer; Consumer sends Message A to Producer.
  B. Consumer sends Message 1 and Message A simultaneously and Producer sends Message B before, during, or after Message 1 and Message A arrive.
  C. The order of sending and receiving Messages cannot be determined from the diagram.
  D. No Messages are exchanged because the diagram illustrates invalid BPMN; a Collaboration between two Participants must involve only a pair of exchanged Messages.
  C. The order of sending and receiving Messages cannot be determined from the diagram.

  ---

  Explanation

  In BPMNmessage flowsshowwho communicates with whom, butthey do not define temporal order. Ordering is defined only bysequence flows inside each participant's process(inside the Producer pool and the Consumer pool).

  The diagram shows three message exchanges (Message 1, Message B, Message A) between Producer and Consumer, butno internal sequence flowsthat would say which send/receive happens first.

  Therefore:

  You can seewhich directioneach message goes, But youcannot determine the orderof sending and receiving them from this diagram alone.

  So the only correct statement is:

  C. The order of sending and receiving Messages cannot be determined from the diagram.

• Question 93:

  Given this process:



  which alternative representation will execute identically?



  A. Option A
  B. Option B
  C. Option C
  D. Option D
  B. Option B

  ---

  Explanation

  The left-hand diagram shows asub-process(container) that includes several activities (A, C, B) and hasone outgoing sequence flowto activity

  D. From the parent process' point of view, this whole container behaves like asingle step that is complete only when all contained work is finished, after which control passes to

  D. OptionBshows activities A and B executed inparallel(via an AND-gateway) and thenjoinedbefore proceeding to

  D. This has the same execution semantics from the outside:

  All required internal activities must complete Only then can the flow continue to D

  The other alternatives represent different semantics: Aimplies a particular loop/order between A, B, and D.

  Cuses an exclusive gateway (only one branch executes).

  Duses an event-based gateway (waiting for events, not all branches). Thus,Option Bis the only diagram that executes identically from the perspective of when D is allowed to start.

• Question 94:

  Which statement is true regarding the two diagram fragments?



  A. There is no difference between the two diagrams - Both are valid and imply the same execution semantics.
  B. Fragment A is invalid because a Boundary Error Event is always Interrupting and always is shown with a double-ring circle, while Fragment B is valid.
  C. In Fragment A, the machine is always cleaned while in Fragment B, the machine is only cleaned if the Run Candy Production Task ended without the Extruder Stuck On condition.
  D. In Fragment A, the Candy Production Task is interrupted by the first Extruder Stuck On event while in Fragment B, the Extruder Stuck On? condition is checked only at the end of the last Consume Excess and Substandard Candies Task.
  D. In Fragment A, the Candy Production Task is interrupted by the first Extruder Stuck On event while in Fragment B, the Extruder Stuck On? condition is checked only at the end of the last Consume Excess and Substandard Candies Task.

  ---

  Explanation

  InFragment A,Run Candy Productionis a subprocess with aboundary eventlabeledExtruder Stuck Onattached to it.

  According to BPMN 2.0:

  A boundary event attached directly to an activity/subprocess is evaluatedwhile that activity is executing. When it triggers (here, when the "Extruder Stuck On" condition occurs), itinterruptsthe subprocess (for an interrupting boundary event) and the normal internal flow stops. Control is redirected along the boundary-event's outgoing sequence flow (toward the alarm/handling path). So, in Fragment A, the first time the extruder gets stuck during the execution ofRun Candy Production, that subprocess is interrupted and the alternate flow (e.g., cease production alarm, possibly skipping remaining steps inside the subprocess) is taken.

  InFragment B, the "Extruder Stuck On?" is modeled as anExclusive Gatewayafter the internal tasks (afterConsume Excess and Substandard Candies). That means: The condition ischecked only when the token reaches that gateway, i.e., after finishing the last internal task.

  If "Yes", we follow the alarm/cease path; if "No", we continue to the normal completion/cleaning path.

  This is exactly what optionDstates.

  Options A and C say the fragments have the same or inverted behavior, which contradicts the execution semantics of boundary events vs. gateways.

  Option B incorrectly assumes the boundary event is specifically an Error Event and misstates the validity of Fragment A. The fragment is valid BPMN; the key difference iswhen and howthe stuck-extruder condition is handled, captured correctly only by optionD.

• Question 95:

  A bank call center receives a banking customer incoming call for customer support. Upon receiving the call, the help desk staff identifies the reason the customer is calling for assistance. If the call is related to a problem with the Bank's web site, the customer is transferred to the web site web resolution team. If the call is related to a forgotten or incorrect password or account id, the customer is transferred to the account maintenance group. If the customer would like to modify their existing set of services or add a service, they are transferred to the bank services group.

  Which representation correctly depicts these options?



  A. Option A
  B. Option B
  C. Option C
  D. Option D
  C. Option C

  ---

  Explanation

  In BPMN, whenexactly oneof several alternative paths is chosen based on a condition (type of issue in the call), anExclusive Gateway (XOR)is used.

  OptionCshows the task"Triage Customer Problem"followed by an exclusive gateway that routes the token intooneof three mutually exclusive paths: Account Access Issue # Account Maintenance Group

  Web Site Issue # Web Resolution Group

  Add or Change Services # Banking Services Group

  OptionDdepicts three parallel outgoing paths directly from the task, which would mean all three groups are engaged simultaneously, which doesnotmatch the scenario. Thus,Cis the correct representation.

• Question 96:

  According to the OMG's BPMM, which is a responsibility of the sponsor of a business process change effort?

  A. To develop concepts for product and service offerings
  B. To manage flow of materials, resources, information, and money
  C. To establish long-term plans and commitments for funding, staffing, and other resources
  D. To define requirements, procedures, and plans for data collection, storage, access, distribution, and disposal
  E. To agree to perform specific actions and/or provide identified work products, services, or support within agreed time and resource constraints
  C. To establish long-term plans and commitments for funding, staffing, and other resources

  ---

  Explanation

  In BPMM, the sponsor is responsible for securing and committing long-term resources such as funding, staffing, and organizational support for a process improvement effort.

• Question 97:

  Which graphic about data objects in BPMN is correct?





  A. Option A
  B. Option B
  C. Option C
  D. Option D
  A. Option A

  ---

  Explanation

  In BPMN,Data Objectsare artifacts that show what data isusedorproducedby activities. They are connected usingData Associations, which are drawn asdashed/dotted lines with arrowheads: Arrowfrom Data Object to Activity= the data is aninputto that activity. Arrowfrom Activity to Data Object= the data is anoutputproduced by that activity.

  Looking at the options:

  Option AshowsTask Awith: A dashed association arrow fromData Object 1 to Task A(Data Object 1 is input). A dashed association arrow fromTask A to Data Object 2(Data Object 2 is output).This matches BPMN rules exactly and is a canonical textbook example of input and output data objects for a task. Option Bshows both data objects associated as outputs only (arrows from Task A to both), which would not reflect the typical input-output pattern and is generally not the intended "correct" example for demonstrating BPMN data object usage.

  Options C and Dinvolve attaching a data object to a sequence flow. While BPMN allows associating a data object to a sequence flow as shorthand, the official specification states that when associating an artifact with asequence or message flow, the association is normallynon-directional(no arrowheads), because the flow itself already shows direction. One of these options uses directional arrows incorrectly, and thus these are not preferred as the "correct" representation in a strict exam context. Given the OMG specification and common BPMN teaching examples,Option Ais the clearly correct and standards-compliant diagram for data objects and data associations.

• Question 98:

  When connecting Flow Objects with Message Flows, which constraint is valid?

  A. Message Flows must be at a 90 degree angle from Sequence Flows.
  B. A Message Flow cannot connect a Pool with a Collapsed Sub-Process.
  C. Message Flows cannot connect to Flow Objects that are within the same Pool.
  D. A Message Flow cannot connect a Message End Event with a Catch-Message Intermediate Event.
  C. Message Flows cannot connect to Flow Objects that are within the same Pool.

  ---

  Explanation

  By BPMN rules,Message Flowsare usedonly between different participants (different Pools). You cannot use a Message Flow between Flow Objects inside the same Pool; inside a Pool you must useSequence Flowinstead. Therefore, optionCstates the valid constraint.

• Question 99:

  Which is a characteristic of process discovery?

  A. Making organizational understanding of current business processes explicit
  B. Optimizing existing business processes based on simulation of new alternatives
  C. Identifying key business stakeholders and subject matter experts
  D. Transforming existing process definitions into an executable format
  A. Making organizational understanding of current business processes explicit

  ---

  Explanation

  In OMG BPM,process discoveryrefers to uncovering and making explicit theas-isstate of business processes. The primary goal is to document and visualize what actually happens-before analysis, redesign, or automation.

  OptionAcorrectly describes this:Process discoverycaptures, documents, and makes explicitthe organizational understanding of current business processes.

  OptionBrefers toprocess optimization, which comes later.

  OptionCis part of project initiation, not discovery itself.

  OptionDrefers toprocess implementationin a BPMS.

  Thus, the correct characteristic of process discovery ismaking current processes explicit.

• Question 100:

  Why is Service Oriented Architecture (SOA) beneficial to BPM?

  A. SOA allows monolithic applications to be replaced by new innovative systems.
  B. SOA removes the reliance of processes on the technologies of underlying applications.
  C. SOA permits IT to create customized solutions to satisfy each department's specific needs.
  D. SOA forces a comprehensive integration between processes and their essential back-end systems.
  B. SOA removes the reliance of processes on the technologies of underlying applications.

  ---

  Explanation

  In OMG-aligned BPM architecture,SOA decouples processes from specific application technologiesby exposing system functions as standardized services.

  This allows BPM processes to: Orchestrate services regardless of underlying technology Promote reuse, loose coupling, and interoperability Increase agility and maintainability OptionBis correct because SOAremoves the tight dependenceof process logic on the specific technologies used in back-end systems. OptionAdescribes a possible outcome, not the core benefit.

  OptionCcontradicts SOA's goal of standardization and reuse. OptionDincorrectly implies forced tight integration; SOA actually promotesloosely coupledintegration. Thus,SOA benefits BPM by separating business processes from application-specific technologies, enabling flexible orchestration.
