NetApp NS0-502 Online Practice Questions and Exam Preparation

NetApp NS0-502 Online Questions & Answers

• Question 31:

  Click the Exhibit button.





  In the diagram shown, a portset is created on controller 1 with the command:

  controller1>portset create -f ntapportset conroller1:0b. This portset is bound to the igroup with all the intiators in it. How many paths can the host 1 see to a LUN on controller 1?

  A. six paths
  B. four paths
  C. three paths
  D. one path
  D. one path

• Question 32:

  Which command do you use to see the rate of change between two successive Snapshot copies in a flexible volume in Data ONTAP?

  A. snap diff
  B. snap calculate
  C. snap delta
  D. snap space
  C. snap delta

• Question 33:

  Click the Exhibit button.







  In the diagram shown, how should the zoning configuration be changed to better comply with NetApp best practices?

  A. four zones, each with one initiator, first two with the first target port and the second two with the second target port
  B. two zones, each with two initiators and one target port
  C. two zones, each with all four initiators and one target port
  D. four zones, each with one initiator and both target ports
  D. four zones, each with one initiator and both target ports

• Question 34:

  An organization currently has a NetApp Fibre Channel block-based solution. With limited budget and resources, they want to create a new disaster recovery site that utilizes a NetApp solution. What would the optimal solution include?

  A. SnapMover and Fibre Channel at the disaster recovery site for all hosts
  B. SnapMirror and iSCSI at the disaster recovery site for all hosts
  C. Fibre Channel at both locations using ftp to replicate storage
  D. MetroCluster and NAS
  B. SnapMirror and iSCSI at the disaster recovery site for all hosts

• Question 35:

  A company wants to use jumbo frames in their Ethernet network.

  They should set the packet size to which industry conventional value?

  A. 1200
  B. 1500
  C. 9000
  D. 12000
  C. 9000

• Question 36:

  A user wants to access a FCP VMFS datastore created on a NetApp LUN using a properly configured ESX 3.5 system with a new ESX 4.0 system. Without making changes to the LUN or igroup attributes, what setting should be used for the SATP (Storage Array Type Plugin)?

  A. VM_SATP_ALUA
  B. VMW_SATP_DEFAULT_AA
  C. The LUN has to be changed to ALUA before accessing from ESX 4.0)
  D. VM_SATP_DEFAULT
  B. VMW_SATP_DEFAULT_AA

• Question 37:

  A 100-GB thinly provisioned LUN is allocated to a Windows host. 100 GB of data is written into the LUN. The current capacity utilization on the disk array as well as the host is 100%. 50 GB of data is deleted from the LUN. Space reclaimer has NOT been run.

  What is the current capacity utilization on both the host and the disk array?

  A. 50% on the host, 100% on the disk array
  B. 100% on the host, 50% on the disk array
  C. 50% on the host, 50% on the disk array
  D. 100% on the host, 100% on the disk array
  A. 50% on the host, 100% on the disk array

• Question 38:

  Which three does NetApp support for iSCSI with Microsoft Windows solutions? (Choose three.)

  A. VLANs
  B. Jumbo frames
  C. NIC teaming
  D. Microsoft MCS
  E. NIC trunking
  A. VLANs
  B. Jumbo frames
  D. Microsoft MCS

• Question 39:

  Which row of items should you look up in the IMT (Interoperability Matrix Tool) when designing a NetApp Storage Solution for a customer?

  A. Host OS and patches, FC WWPN, Volume Manager, File System version
  B. Host OS, iSCSI IQN, Volume Manager, Clustering
  C. Host OS and patches, HBA driver, Volume Manager, File System, Clustering
  D. Host OS, HBA driver, Host Memory and CPU Speed, File System, Clustering
  C. Host OS and patches, HBA driver, Volume Manager, File System, Clustering

• Question 40:

  What does NetApp recommend as best practice for zone configuration?

  A. single target zoning
  B. single initiator zoning
  C. multiple initiator zoning
  D. single port zoning
  B. single initiator zoning
