• Question 41:

  The storage solution based on the exhibit is deployed at a customer site.



  How can the sequential read performance values be enhanced for this configuration?

  A. By adding another expansion shelf
  B. By increasing the amount of 10/25 Gb NICs
  C. By replacing 10/25 Gb with a 32 Gb FC HBA
  D. By adding SCM to the solution
  B. By increasing the amount of 10/25 Gb NICs

  ---

  The exhibit shows a system delivering ~2.3 GB/s sequential read. For large-block sequential workloads, aggregate host link bandwidth (number ?speed of front-end ports) is the primary limiter. Increasing the count of 10/25 Gb iSCSI NICs adds parallel lanes, raising sustained read GB/s to the hosts. This is a recommended first step in HPE sizing before changing protocols. Analysis of Incorrect Options (Distractors):

  A: Adding an expansion shelf increases capacity, not front-end bandwidth.

  C: Moving to 32 Gb FC can help, but simply adding more existing 10/25 Gb ports achieves the same goal without a protocol/adapter change and is the straightforward, supported scale-out path.

  D: SCM (Storage Class Memory) targets latency/IOPS; it doesn't materially lift sequential GB/s if the link budget is the bottleneck.

  Key Concept: Scale front-end connectivity to increase sequential throughput; capacity or media class changes won't fix a link-limited system.

  HPE Alletra 6000/MP Sizing and Host Connectivity Guidelines (throughput scaling via additional host ports).

• Question 42:

  Refer to the exhibit of Zerto Vault architecture.



  Which statement about the Zerto Vault architecture is correct?

  A. Data is replicated via encrypted periodic replication between Production and the Replication Target.
  B. Data is replicated via encrypted periodic replication between the Replication Target and the Vault.
  C. The Resilience Automation Server manages port access between Production and the Replication Target.
  D. Immutable snapshots of all Zerto components are taken at the Replication Target and replicated to the Vault.
  B. Data is replicated via encrypted periodic replication between the Replication Target and the Vault.

  ---

  In the Zerto Vault architecture, production workloads replicate continuously to a Replication Target (secondary site). From there, data is further replicated periodically and encrypted into the Vault (air-gapped, isolated site). This two-step process ensures ransomware resilience and immutability, as the Vault acts as a hardened third copy.

  A: Production-to-replication target traffic is continuous synchronous/asynchronous replication, not periodic. Periodic replication applies to Replication Target # Vault.

  C: The Resilience Automation Server (RAS) is responsible for orchestrating failover and immutability enforcement, but it does not control port access between production and replication target.

  D: Snapshots of Zerto components are not what is replicated - it's application data VMs/volumes. The Vault ensures immutability of replicated data, not ZVM components.

  Key Concept: Zerto Vault = encrypted, periodic replication from replication target to immutable vault.

  HPE Zerto Vault Architecture White Paper, HPE Ransomware Recovery Solutions.

• Question 43:

  A customer is implementing ransomware-resilient backups using Veeam v12 with HPE StoreOnce at two sites. They are concerned that a single StoreOnce administrator could delete or expire backups. Which StoreOnce capability best addresses this insider-risk concern?

  A. Dual Authorization for destructive operations
  B. CHAP authentication on iSCSI targets
  C. Data-at-rest encryption on Catalyst stores
  D. Increasing the Catalyst store quota limits
  A. Dual Authorization for destructive operations

  ---

  Dual Authorization enforces a "two-person rule" for destructive actions, reducing risk from compromised credentials or insider threats.

  B: CHAP controls access authentication, not authorization for deletion/expiration.

  C: Encryption protects confidentiality, not deletion protection.

  D: Quotas affect capacity controls, not administrative delete controls.

  Key Concept: Dual Authorization reduces insider risk for backup deletion/modification.

  HPE StoreOnce security feature guidance.

• Question 44:

  Two HPE Alletra 6000 arrays are configured for peer persistence between datacenters A and B, which have a fiber distance of 50km (31mi) . The datacenter B hardware will be relocated to a new location that will increase the fiber distance to 150km (93mi) . Which condition is valid once the relocation is finished?

  A. The peer persistence configuration is supported, when latency remains
  B. The peer persistence replication links need to be changed to RC transport.
  C. The peer persistence setup needs to be changed to active peer persistence.
  D. The fiber distance exceeds the distance supported for peer persistence setup.
  A. The peer persistence configuration is supported, when latency remains

  ---

  HPE Peer Persistence is supported over distances of up to 150?00 km , as long as the round-trip latency is #10ms . Therefore, even after relocation to 150km, Peer Persistence remains supported provided latency requirements are met.

  B: RC (Remote Copy) transport is already the underlying technology, but no change is required.

  C: Peer Persistence is already an active-active design; no change to "active" mode is needed.

  D: Distance does not exceed the supported range; only latency matters.

  Key Concept: Latency <10ms is the critical requirement for Peer Persistence . Reference: HPE Alletra 6000/Primera Peer Persistence Best Practices .

• Question 45:

  Exhibit shows HPE StoreOnce Catalyst Store Security Settings: Server Controlled Data Immutability enabled (7 days). Maximum ISV Controlled Data Immutability Retention (90 days). Which statement is correct?





  A. Maximum ISV Controlled Data Immutability Retention allows the ISV backup application to manage item-level immutability.
  B. Server-Controlled Data Immutability is required to achieve the highest immutability with Veeam v12 backups.
  C. Server-Controlled and ISV-Controlled Data Immutability values do not need to match when both are configured.
  D. The Maximum ISV Controlled Data Immutability Retention parameter must be set to 0 for optimal Veeam v12 support.
  A. Maximum ISV Controlled Data Immutability Retention allows the ISV backup application to manage item-level immutability.

• Question 46:

  Refer to the exhibit.



  The above image represents an existing Alletra 6000 Peer Persistence configuration . Which statement could be true in this scenario?

  A. The amount of active (0) paths could reduce the performance of the array.
  B. The performance of the array could be reduced due to the amount of paths active.
  C. The performance of the array could be reduced due to a missing controller.
  C. The performance of the array could be reduced due to a missing controller.

  ---

  In the exhibit, several paths show "Standby" and some appear "Dead" , while only a subset is Active (0) . This typically indicates that one storage controller may be missing or offline , which reduces redundancy and can cause performance degradation. In a healthy Peer Persistence environment, both controllers should present active and non-optimized paths.

  A and B: Having multiple active paths does not inherently reduce performance; in fact, MPIO load balances traffic. The issue here is path failures , not excessive active paths.

  Key Concept: MPIO pathing in HPE Peer Persistence and controller health .

  HPE Alletra 6000 Peer Persistence Implementation Guide .

• Question 47:

  Select the scenario where implementing FCoE would be an appropriate solution.

  A. A large enterprise data center with existing Fibre Channel SANs is looking to reduce hardware complexity and costs by consolidating their storage and production networks onto a single infrastructure, while maintaining high performance for mission-critical applications.
  B. A corporation needs to replicate data between data centers in different countries. The data must be synchronized in real-time across a WAN, and the solution must tolerate variable network conditions with minimal impact on performance.
  C. A company with data centers in different states wants to establish a unified SAN infrastructure. The goal is to centralize storage management across all sites, using a single protocol that can efficiently handle high-latency, long-distance connections between data centers.
  D. A tech startup is developing an AI-based application that relies heavily on machine learning models. The team needs a solution that allows them to access and process large datasets in the cloud.
  A. A large enterprise data center with existing Fibre Channel SANs is looking to reduce hardware complexity and costs by consolidating their storage and production networks onto a single infrastructure, while maintaining high performance for mission-critical applications.

  ---

  Option A is correct because Fibre Channel over Ethernet (FCoE) is designed for large enterprise environments that already have Fibre Channel (FC) infrastructures but want to simplify cabling and reduce hardware by converging LAN and SAN traffic over a single Ethernet fabric. FCoE retains the efficiency, low latency, and reliability of Fibre Channel while leveraging Ethernet to minimize physical infrastructure costs. This aligns with HPE's best practices for environments using HPE Alletra 9000/Primera or HPE Nimble arrays connected to converged networks where cost reduction and high performance are equally important.

  Analysis of Incorrect Options (Distractors):

  B: Real-time replication across WANs requires protocols like HPE 3PAR/Alletra Remote Copy, asynchronous/synchronous replication, or HPE Peer Persistence . FCoE is not suited for high-latency WANs because it is a LAN protocol designed for short distances within a data center.

  C: For inter-data center SAN unification, FCIP (Fibre Channel over IP) or iSCSI are more suitable. FCoE does not handle long-distance high-latency links effectively.

  D: A startup building AI applications with cloud workloads typically benefits from object storage (HPE Scality RING, HPE GreenLake for File and Object) or direct cloud-native APIs (S3/Blob). FCoE is irrelevant in this use case since it is on-prem and infrastructure-focused.

  Key Concept:

  The question is testing knowledge of FCoE and its appropriate deployment scenarios - specifically, its role in consolidating storage and network traffic inside enterprise data centers while preserving Fibre Channel protocol advantages.

  HPE Storage Networking Best Practices Guide

  HPE Primera/Alletra 9000 Technical White Paper

  Fibre Channel over Ethernet Standards Overview (IEEE 802.1Qbb, 802.1Qaz)

• Question 48:

  Two HPE Storage Alletra MP B10000 arrays are deployed with Active Peer Persistence . Both arrays and hosts are installed in close proximity to each other. To enable symmetric access, Peer Persistence must be configured accordingly. Which Host Proximity Parameter should be selected for host ESX31 in this case?

  A. Secondary
  B. All
  C. Exclusive
  D. Primary
  B. All

  ---

  Option B (All) is correct because in an Active Peer Persistence deployment where both arrays and hosts are in close proximity (metro or campus cluster scenario), the hosts should be configured with Host Proximity = All. This ensures that the host (ESX31) can access both arrays symmetrically and concurrently, enabling active-active paths. This is essential to deliver seamless failover and load balancing across the arrays in an HPE Alletra MP Peer Persistence environment.

  Analysis of Incorrect Options (Distractors):

  A (Secondary): This is used for hosts located closer to the secondary array, to bias access toward it in asymmetric deployments. Not applicable here since the hosts are near both arrays.

  C (Exclusive): This option assigns the host to a single array exclusively, preventing dual-active access. This would defeat the purpose of symmetric Peer Persistence.

  D (Primary): Similar to Secondary, this biases access to only the primary array, which is not correct when arrays and hosts are in the same site for active-active.

  Key Concept:

  This question focuses on Host Proximity parameters in HPE Peer Persistence.

  Primary/Secondary = asymmetric designs (hosts closer to one array).

  All = symmetric design (hosts equidistant to both arrays, enabling active-active).

  Exclusive = restricts access to one array only.

  HPE Alletra MP Storage Peer Persistence Best Practices Guide

  HPE Primera/Alletra Remote Copy and Peer Persistence Technical White Paper

  VMware Metro Storage Cluster with HPE Peer Persistence Implementation Notes

• Question 49:

  A customer is purchasing new infrastructure and wants predictable monthly payments, eventual ownership, and the ability to customize and upgrade equipment during the term. They want to avoid returning the equipment at the end. Which procurement option best fits?

  A. Operating lease
  B. Consumption model
  C. Capital lease
  D. Short-term rental
  C. Capital lease

  ---

  A capital (finance) lease is commonly used to spread payments while providing a path to ownership, supporting predictable payments and long-term control over the equipment lifecycle.

  A: Operating leases typically involve returning the equipment and do not align with "eventual ownership."

  B: Consumption models emphasize usage-based OpEx and generally do not imply ownership.

  D: Short-term rental conflicts with long-term use and ownership objectives. Key Concept: Capital lease aligns monthly payments with ownership intent. Reference: HPE Financial Services procurement options guidance.

• Question 50:

  You are sizing an HPE Alletra 5030. Unless otherwise indicated by the HPE sizer or the customer's requirements, HPE best practices state that you should default to which minimum FDR calculation?

  A. 23% of the largest drive size
  B. Above 12% for low-read latency
  C. Below 12% for low-read latency
  D. 23% of the smallest drive size
  A. 23% of the largest drive size

  ---

  In Alletra 5000/6000 sizing , the Failure Domain Reserve (FDR) is used to account for rebuild overhead in case of drive failure. HPE best practices define that, unless otherwise directed by the sizing tool or customer requirements, the minimum FDR value should be set to 23% of the largest drive size . This ensures enough reserve capacity for fault tolerance and sustained performance during rebuilds. B/C: Low-read latency is influenced by cache and workload profile, not by arbitrary FDR percentages.

  D: Using the smallest drive is incorrect - rebuild impact must be sized against the largest drive.

  Key Concept: FDR sizing based on 23% of largest drive = HPE best practice.

  HPE Alletra 5000/6000 Sizing and Configuration Guide .
