HP HPE6-A29 Online Practice Questions and Exam Preparation

HP HPE6-A29 Online Questions & Answers

• Question 101:

  An access port has been placed in trusted mode. The VLAN on the port is in Untrusted mode. Which of the following statements is true?

  A. The traffic is trusted since the port is trusted
  B. The traffic is untrusted since the VLAN is untrusted
  C. This is an invalid configuration, both must be set the same
  D. You cannot set VLANs as trusted or untrusted
  E. Only traffic from that specific port is trusted, all other traffic is untrusted
  B. The traffic is untrusted since the VLAN is untrusted

• Question 102:

  As an admin/root user, what other type of role-based management users can be created on Aruba controllers?

  A. Auditing-compliance user
  B. AirWave management user
  C. Reporting Generation user
  D. Guest provisioning user
  E. Maintenance user
  D. Guest provisioning user

• Question 103:

  When creating a firewall rule on an Aruba controller, which parameter is optional?

  A. Destination
  B. Service
  C. Source
  D. Log
  E. Action
  D. Log

• Question 104:

  An administrator sets up a captive portal tor guest access with these specifications:

  *

  VLAN 18 for the guest users will terminate on the controller and will not extend into the corporate network.

  *

  Aps that advertise the guest SSID will tunnel traffic to the controller, and the controller will authenticate the users.

  *

  Once the users are authenticated, the user traffic will be translated to a different VLAN before it is forwarded to the corporate network to reach the internet.

  When the administrator sets up this solution, the users fails to see the captive portal web page for authentication and cannot access the internet. The administrator determines the problem is that the guest VLAN does not have any ports

  associated to it on the controller.

  Which CLI command should the administrator implement to resolve the issue?

  A. interface vlan 19 no shutdown
  B. vlan 18 operstate up
  C. vlan 18 enable
  D. interface blan 19 operstate up.
  D. interface blan 19 operstate up.

• Question 105:

  What is true about an AP in Hybrid Spectrum mode?

  A. Scan home channel and services client traffic on home channel
  B. Scans all channels and services clients on home channel
  C. Puts the selected band in spectrum mode and services clients on other band D. Makes the AP a spectrum monitor, but does not affect other APs in the AP-group
  E. All APs in AP-group scan home channel and service clients
  A. Scan home channel and services client traffic on home channel

• Question 106:

  A company uses Aruba Mobility Controllers and Aruba Aps. The Aps incur a power outage.

  Which Aruba feature should be implemented to allow the surrounding Aps to provide wireless coverage for the area of the AP that lost power?

  A. Airtime Fairness
  B. Adaptive Radio Management
  C. Band Balancing
  D. High Availability
  B. Adaptive Radio Management

• Question 107:

  Which profiles are required in an AP Group to enable an SSID with VLAN 1, WPA2 and LMSIP? (Choose three)

  A. Virtual-AP profile
  B. WLAN profile
  C. 802.1x authentication profile
  D. AP System Profile
  E. SSID Profile
  A. Virtual-AP profile
  D. AP System Profile
  E. SSID Profile

• Question 108:

  Which tunnel protocol is used between controllers to support L2 mobility in an Aruba environment?

  A. Basic IP
  B. GRE
  C. IPinIP
  D. Mobile IP
  E. None of the above
  E. None of the above

• Question 109:

  Which type of traffic is protected by control place security (CPSec) feature on Aruba wireless products?

  A. all AP packets to the controller
  B. AP GRE packets
  C. AP PAPI packets
  D. inter-controller packets
  A. all AP packets to the controller

• Question 110:

  Referring to the above screen capture,



  Which tab tells you which licenses are installed on the controller?

  A. Controller Summary
  B. All Wlan Controllers
  C. Process Logs
  D. Inventory
  D. Inventory
