HP HP0-S33 Online Practice Questions and Exam Preparation

HP HP0-S33 Online Questions & Answers

• Question 11:

  VMware HA has a prerequisite that includes the ability to power on a virtual machine from all hosts within the cluster. This means all hosts have to access to which common resource?

  A. VMware HA agent
  B. vCenter server
  C. Redundant heartbeat network
  D. Shared storage
  D. Shared storage

• Question 12:

  Referring to the exhibit, which Smart Carrier innovation was introduced with the HP ProLiant server platform to help reduce/eliminate downtime as a result of the wrong hard drive being removed after a failure?



  A. When a drive fails, the backlight flashes blue to auto locate. The drive status goes to amber.
  B. When a drive fails, it turns amber. The remaining healthy drives are held in place with an automatic latch mechanism to present removal.
  C. When a drive fails, it is disabled and powered off. The remaining healthy drives illuminate the Do not LED.
  D. When a drive fails, it turns amber. The remaining healthy drives illuminate the Do Not remove LED.
  D. When a drive fails, it turns amber. The remaining healthy drives illuminate the Do Not remove LED.

  ---

  http://198.235.14.21/HP/images/stories/ProliantServers/Q212/4aa39937enw.pdf (Page 3, Resiliency, 4th bullet)

  Reduce failures and downtime--HP Smart Drives deliver the best overall customer experience and improves uptime. Virtually eliminate inadvertent drive removal with an icon-based display and a "Do Not Remove" indicator during a drive failure. HP Predictive Spare Activation identifies and resolves failures before they occur and automatically moves data to a spare device.

• Question 13:

  Which host is selected as a master host in the VMware HA cluster?

  A. The host with access to the greatest number of the datastores
  B. The host with the redundancy configured for management network
  C. The host with the greatest number of virtual machines configured with fault tolerance
  D. The host with the greatest CPU and memory capacity
  A. The host with access to the greatest number of the datastores

  ---

  http://pubs.vmware.com/vsphere-50/index.jsp?topic=

  %2Fcom.vmware.vsphere.avail.doc_50%2FGUIDB9ACCE9B-A14D-4B2F-87EF- 4B0A67ABDF58.html

  When you add a host to a vSphere HA cluster, an agent is uploaded to the host and configured to communicate with other agents in the cluster. Each host in the cluster functions as a master host or a slave host.

  When vSphere HA is enabled for a cluster, all active hosts (those not in standby or maintenance mode, or not disconnected) participate in an election to choose the cluster's master host. The host that mounts the greatest number of

  datastores has an advantage in the election. Only one master host exists per cluster and all other hosts are slave hosts. If the master host fails, is shut down, or is removed from the cluster a new election is held.

• Question 14:

  Which Windows performance Monitor counter indicates that a network bottlenecks is occurring?

  A. Network Interface: Output Queue Length
  B. Network Interface: Current Bandwidth
  C. Network Interface: Packets Sent/Sec
  D. Network Interface: Packets Received/Sec
  A. Network Interface: Output Queue Length

• Question 15:

  Which HP software offering enables IT organization to provision infrastructure consistently and automatically from pools of shared resources, using a self-service portal?

  A. Insight Control Server Deployment
  B. Systems Insight Manager
  C. Operations Orchestrations
  D. Matrix OE infrastructure Orchestration
  D. Matrix OE infrastructure Orchestration

  ---

  http://h20000.www2.hp.com/bc/docs/support/SupportManual/c03482833/c03482833.pdf (page 4, enabling technologies for HP cloud maps)

  Enabling technologies for HP Cloud Maps HP Matrix Operating Environment (OE) is cloud management software for IaaS that enables you to design and provision infrastructure services in minutes via a self-service portal, optimize infrastructure for capacity planning, and protect service continuity with automated, cost-effective failover. Matrix OE is fully integrated into HP CloudSystem, providing the ability to deliver IaaS. A core component of HP Matrix OE is infrastructure orchestration (IO). It allows you to use a self-service portal to provision infrastructure consistently and automatically from pools of shared resources. With the Matrix OE IO designer interface, you can easily import, create, or customize these infrastructure templates using a drag-and-drop editor. Figure 1 shows the infrastructure orchestration designer interface for managing templates. Once a template is complete, you can publish it to the self-service portal and export it in XML format to share. You can also assign costs per component to use for reports or showback/chargeback

• Question 16:

  Which Windows performance counters must be monitored to determine if a processor is overloaded?

  A. Processor: % Processor Time and system: Processes
  B. Processes: % Processor Time and system: Processor Queue length
  C. Processor\% Processor Time and system\Processor Queue Length
  D. Disk: Average Disk Queue Length and system: Processor Queue length
  C. Processor\% Processor Time and system\Processor Queue Length

  ---

  http://technet.microsoft.com/en-us/library/cc938603.aspx Identify the processes that are running when Processor\% Processor Time and System\Processor Queue Length values are highest to determine.

• Question 17:

  You configured disk thresholds for all servers running Windows Server 2008 R2. You want HP SIM to react by running a script that will delete all IE temporary files on the server that reports problems with the available capacity on the drive. What do you have to configure from the HP SIM level to achieve this?

  A. Configure the Single Sign On feature for all the servers that should be covered that script.
  B. Establish a trust relationship between HP SIM and all servers covered by that script, and apply the Insight Control licenses.
  C. Create a custom command that will delete temporary files and configure an automatic event handling task to run this script when a specific event occurs.
  D. Import the HP SIM certificate to the HP System Management homepage for all of the servers that should be covered by that script and configure SNMP security to allow remote command execution.
  C. Create a custom command that will delete temporary files and configure an automatic event handling task to run this script when a specific event occurs.

• Question 18:

  What is a recommended best practice when installing multiple enclosures?

  A. Disable the Single Sign-On feature
  B. Place OA and iLO on separate subnets
  C. Use DHCP to avoid static addressing
  D. Place the OA on a management network
  B. Place OA and iLO on separate subnets

  ---

  http://h20000.www2.hp.com/bc/docs/support/SupportManual/c00705292/c00705292.pdf (pag 20 Security considerations)

• Question 19:

  Which event default actions can you configure using the Automatic Event Handling feature of HP SIM? (Select two)

  A. Run the identity task
  B. Forward as an SNMP trap
  C. Shut down the server
  D. Restart Insight Management Agents
  E. Assign the event to the user
  B. Forward as an SNMP trap
  E. Assign the event to the user

  ---

  http://www.hp.com/wwsolutions/misc/hpsim-helpfiles/mxhelp/mxportal/en/admin_events_newRule.html

  Send page (Windows only) Send e-mail Run custom tool Assign :Type in the name of the person to assign the task to. The event is assigned to this user when received. Forward as SNMP trap Write to system log Clear event

• Question 20:

  Which features are activated by the Smart Array Advance Pack (SAAP)? (Select two)

  A. Online spare configuration
  B. User selectable-strip sizes
  C. Zero Memory configurations
  D. Mirror splitting
  E. RAID 6 and RAID 60
  D. Mirror splitting
  E. RAID 6 and RAID 60

  ---

  Reference: http://h20000.www2.hp.com/bizsupport/TechSupport/Document.jsp? (See lang=enandcc=usandtaskId=115andprodSeriesId=428936andprodTypeId=15351andobjectID=c02793166 the bulleted point at the end of the page)

  When activated with a registered license key, SAAP provides the following features:

  RAID 6 (ADG).

  RAID 60.

  Advanced Capacity Expansion.

  Mirror splitting and recombining in offline mode.

  Drive Erase.

  Performance optimization for video on demand.
