EMC EMC Other Certification DES-5121 Questions & Answers

• Question 31:

  What describes the POE+ capabilities of the Dell EMC N1100P Series?

  A. Supported on any of the first half of switch ports or the first 12 switch ports, whichever is fewer. May only be enabled on a maximum of half of the supported ports.

  B. Supported on any of the first 12 switch ports or all switch ports, whichever is fewer. May only be enabled on a maximum of half of the supported ports.

  C. Supported on all of the first 12 switch ports or all switch ports, whichever is fewer.

  D. Supported on all of the first half of switch ports or the first 12 switch ports, whichever is fewer.

  Correct Answer: B

• Question 32:

  A network administrator has configured a 4-port port-channel between two Dell EMC Campus networking switches. The physical interfaces show as administratively up and operationally up on both switches. However, the port-channel shows as operationally up on Switch A and operationally down on Switch B.

  What is a potential reason for the inconsistent port-channel state?

  A. Switch A is configured to use dynamic port-channels and Switch B is configured to use static port-channels

  B. Ports in the port-channel on Switch A are all the same speed but the ports in the port-channel on Switch B are a mix of speeds

  C. Switch A is configured using channel-group # mode on and Switch B is configured using channel-group # mode auto

  D. N-Series supports a maximum number of physical interfaces that can be included in port-channels on a per-device basis

  Correct Answer: C

• Question 33:

  A network administrator added a new Dell EMC N-Series switch into their network with RSTP configured. The spanning-tree priority on all existing switches has been left at the default value. If the administrator wants this new switch to become the spanning tree root, which command should be used?

  A. spanning-tree priority 4096

  B. spanning-tree priority 32768

  C. spanning-tree priority 36864

  D. spanning-tree priority 61440

  Correct Answer: A

  Reference: https://www.dell.com/support/article/en-us/how10394/how-to-manage-rapid-spanning-tree-rstp-thru-command-line-on-dell-networking-powerconnect-switches?lang=en

• Question 34:

  You need to configure OSPF on a DNOS 6 switch and have entered the following:

  Switch-1(config)# ip routing Switch-1(config)# interface vlan 20 Switch-1(config-if-vlan20)# ip address 10.1.20.1 255.255.255.0

  Switch-1(config)# router ospf Switch-1(config-router)# router-id 10.1.1.1

  Based on the information referenced above, what is missing from the configuration?

  A. area 0 is missing from the ip routing command

  B. ip ospf area 0 is missing from the interface vlan 20 section

  C. router ospf is missing the routing instance

  D. area 0 is missing from the router-id command

  Correct Answer: B

• Question 35:

  A network administrator is setting up several stacks in their network that includes different Dell EMC N-Series models. Which N-Series switch models require mini-SAS stacking cables?

  A. N1100 and N1500

  B. N1500 and N3000

  C. N2000 and N3000

  D. N3000 and N4000

  Correct Answer: C

  Reference: https://cdn.cnetcontent.com/syndication/mediaserverredirect/c1ddae5629f69c40c5da9c0d36cb045f/original.pdf

• Question 36:

  Which ports on a spanning tree root switch are always forwarding?

  A. Alternate ports

  B. Designated ports

  C. Backup ports

  D. Root ports

  Correct Answer: B

• Question 37:

  To which destination MAC address are MLAG peer-keepalive packets sent?

  A. 01:00:B5:00:00:00

  B. 01:00:C5:00:00:00

  C. B5:00:01:00:00:00

  D. C5:00:01:00:00:00

  Correct Answer: A

  Reference: https://www.manualslib.com/manual/858353/Dell-Networking-N4000-Series.html?page=941

• Question 38:

  Which default security level can be assigned to limit access of a specific user to a Dell EMC N-Series switch?

  A. Level 0

  B. Level 1

  C. Level 5

  D. Level 15

  Correct Answer: A

  Reference: https://www.dell.com/support/manuals/us/en/04/force10-s4048-on/s4048_on_9.9.0.0_config_pub-v1/configuring-privilege-levels?guid=guid-2fa480e0-1660-41d8-8ac2-45aa90d5bb71andlang=en-us

• Question 39:

  In a traditional campus network design using a three-tier hierarchical model, what are the key attributes of the Core layer in this model?

  A. Provides a wide range of services, is highly available, and operates in an active-passive mode

  B. Provides a limited set of services, is highly available, and operates in an always-on mode

  C. Provides a wide range of services, is highly available, and operates in an always-on mode

  D. Provides a limited set of services, is highly available, and operates in an active-passive mode

  Correct Answer: B

• Question 40:

  You are tasked with deploying a single Dell EMC N-Series switch with a 2-port port-channel to uplink to an existing upstream switch. The following reflects the upstream switch configuration:

  N4032F#show running-config interface tengigabitethernet 1/0/5 channel-group 1 mode on N4032F#show running-config interface tengigabitethernet 1/0/6 channel-group 1 mode on

  Which type of port-channel should be configured to successfully uplink?

  A. Active

  B. MLAG

  C. Static

  D. Passive

  Correct Answer: C
