IBM Tivoli Storage Manager V7.1 Fundamentals

Explanation: Server ANR messages list. Examples:
ANR0107W: Source file(line number): Transaction transaction ID was not committed due to an internal error.
ANR0115W: The server script script name attempted to start more parallel commands than are allowed for a single script. A single script is limited to parallel command limit parallel commands.
ANR0116W: The server script script name attempted to start more parallel commands than are allowed for the server. The server is limited to parallel command limit parallel commands.

Explanation: Example:
Task: Display a list of recovery plan files that were created for this server using the specified device class.

Command query rpfile devclass=* format=detailed
Output

Recovery Plan File Name: ALASKA.20000406.170423
Node Name: BRANCH1
Device Class Name: REMOTE
Recovery Plan File Type: RPFILE
Mgmt Class Name: STANDARD
Recovery Plan File Size: 16,255 Bytes
Marked for Deletion: Yes Deletion Date: 06/12/2000 13:05:31

Recovery Plan File Name: ALASKA.20000407.170845
Node Name: BRANCH1
Device Class Name: REMOTE
Recovery Plan File Type: RPFSNAPSHOT
Mgmt Class Name: STANDARD
Recovery Plan File Size: 16,425 Bytes
Marked for Deletion: No

Explanation: The query filespace command displays a list of file spaces for a node that are stored on the Tivoli Storage Manager server, or that are inside a backup set from the Tivoli Storage Manager server, when the backupsetname option is specified. You can also specify a single file space name to query.

Example: Task
Display your file spaces.
Command: query filespace

Explanation: * Example:

http://www-01.ibm.com/support/docview.wss?uid=swg21651428&aid=20

* The severity codes give an indication of the severity of the issue that generated the message. The severity codes and their meanings are as follows:
E Error Processing cannot continue.
W Warning Processing can continue, but problems may occur later. I Information Processing continues.
User response is not necessary.

Explanation: The Operations Center is IBM's next-generation graphical user interface for Tivoli Storage
Manager. It provides advanced end-to-end visibility of the entire backup environment. Over time, IBM plans to add more control and automation capabilities, which will dramatically simplify daily management and operational tasks for a wide range of users.
Incorrect:
Not A: IBM Tivoli Storage Manager is a client and server program that provides storage management solutions to customers in a multi-vendor computer environment. IBM Tivoli Storage Manager provides an automated, centrally scheduled, policy-managed backup, archive, and space-management facility for file servers and workstations. Not D: No such thing as an Integrated Storage Console.

Explanation: A: TSM Servers
The status indicator shows whether the Tivoli Storage Manager servers that are managed by the Operations Center are available to provide data protection services to clients.
E: TSM Clients
A client is considered to be at risk if a problem occurs during its most recent scheduled backup, or during a backup that starts within a specified time interval. The term backup also includes archive operations for Tivoli Storage Manager for Enterprise Resource Planning clients.
Use the information that is shown in the TSM Clients section to check for failed or missed backups and to determine whether backup schedules are running as expected.

Explanation: The Disaster Recovery Manager (DRM) The TSM (Tivoli Storage Manager) Disaster
Recovery Manager is a feature that is included with TSM Extended Edition and it is the part of the TSM application that can be used to assist with the management of off-site disaster recovery.

References:
A Brief Introduction to IBM Tivoli Storage Manager Disaster Recovery Manager

Explanation: When a file is migrated from your local system to Tivoli Storage Manager storage, a placeholder, or stub file, is created in place of the original file. Stub files contain the necessary information to recall your migrated files and remain on your local file system so that the files appear to reside locally. This contrasts with archiving, where you usually delete files from your local file system after archiving them.

Explanation: When you configure client-side data deduplication, the following requirements must be met:

* The client and server must be at version 6.2.0 or later.
* (not D) Client-side deduplication cannot be used in combination with LAN-free backups.
* (not C) Files that are intended for deduplication must not be encrypted. Encrypted files and files from encrypted file systems cannot be deduplicated.
Etc.

Explanation: After the initial full backup of your storage pools, incremental storage pool backups are done
nightly.
