IBM C2180-276 Online Practice Questions and Exam Preparation

IBM C2180-276 Online Questions & Answers

• Question 31:

  A BPM application developer has built an integration service that executes SQL calls. Within this service, the BPM application developer makes use of the "SQL Execute Statement" service found within the TWSYS toolkit. Review the snapshot of the data mapping for this service. The BPM application developer wants to manage the "dataSourceName" value at runtime, instead of hardcoding the value "jdbc/BPMTEST".



  Which features of IBM Business Process Manager V8.0 will allow the BPM application developer to do this? (Choose two)

  A. environment variables
  B. auto tracked variables
  C. localization resources
  D. shared process variables
  E. exposed process variables
  A. environment variables
  E. exposed process variables

• Question 32:

  Which statement correctly describes a type of service available in Business Process Manager V8.0?

  A. An Ajax service can be used to generate tasks in the IBM Process Portal user interface.
  B. An Integration service is the only type of service that can contain a Java or Web Service integration component.
  C. In addition to implementing business rules, Decision services are used for manipulating variable data.
  D. General System services are used to build custom functionality into the BPD for any non-supported service types.
  B. An Integration service is the only type of service that can contain a Java or Web Service integration component.

• Question 33:

  A company has a coach view that provides a list of questions within a Custom HTML control. Refer to the screen shot of the coach view's layout below.



  The company would like all question paragraphs to be padded top, bottom, left, and right with 5 pixels and a background of #EEEEEE.

  What should a BPM application developer place within the Inline CSS of the coach view?

  A. div.company-question-container > p { padding: 5px; background: #EEEEEE; }
  B. div.company-question-container > p { padding: 5px; background: #EEEEEE; }
  C. div.companyQuestions > p { padding: 5px; background: #EEEEEE; }
  D. div.companyQuestions > p { padding: 5px; background: #EEEEEE; }
  B. div.company-question-container > p { padding: 5px; background: #EEEEEE; }

• Question 34:

  After the completion of several tasks, an order shipping process for electronic devices must wait to receive a message from a separate inventory replenishment process before proceeding to an activity for order delivery.

  How should the BPM application developer implement the receive message event?

  A. As an Ad-hoc event.
  B. As a message start event.
  C. As an intermediate event in the process flow.
  D. As an intermediate event attached to the order delivery activity.
  C. As an intermediate event in the process flow.

• Question 35:

  A process owner of an insurance company requests to receive an email if the amount of a loan is higher than $50,000. After creating the custom Key Performance Indicator (KPI) Amount (currency) and associating it to the activity, how should the BPM application developer configure the Assignment Setting to set the value of the KPI to the amount of the loan object? Uncheck "use KPI defaults", and apply the following settings.

  A. Assignment Type: Select Absolute Value Value: tw.local.loan.amount
  B. Assignment Type: Select Absolute Value Value: tw.perf.value = tw.local.loan.amount
  C. Assignment Type: Select custom JavaScript Value: tw.perf.value = tw.local.loan.amount
  D. Assignment Type: Select custom JavaScript Value: tw.local.loan.amount
  D. Assignment Type: Select custom JavaScript Value: tw.local.loan.amount

• Question 36:

  A company has stated that a supervisor search is required within a number of activities for their Office Requisition Process. A BPM application developer has chosen to implement this search within a coach view using AJAX. Refer to the variable declarations of the coach view below.



  The configuration option retrieveSupervisors is of Type Service. Assuming that the AJAX function parameters are properly specified within the variable serviceArgs, how would the developer invoke the AJAX service within the appropriate coach view event handler?

  A. this.context.options.RetrieveSupervisors(serviceArgs);
  B. this.context.options.retrieveSupervisors(serviceArgs);
  C. this.context.options.get("RetrieveSupervisors", serviceArgs);
  D. this.context.options.get("retrieveSupervisors", serviceArgs);
  B. this.context.options.retrieveSupervisors(serviceArgs);

• Question 37:

  A document imaging and management company is implementing a business process diagram which requires a rules evaluation for the retention time of incoming documents. A BPM Analyst has requested that these rules be created using a natural language technology within IBM Business Process Manager V8.0.

  What decision service component should the BPM application developer use to create these rules?

  A. BAL Rule
  B. Server Script
  C. Decision Table
  D. JRules Decision Service
  A. BAL Rule

• Question 38:

  A BPM application developer has been called into a training session with a group of developers who are new to IBM Business Process Manager V8.0. The BPM application developer needs to describe the process of building an Ajax service to help the new developers complete their assignment.

  What statement will the BPM application developer make regarding the process of building an Ajax service in the training session? Creating an Ajax service is:

  A. similar to the process for creating other services, except they are created in the library area where User Interface library items are stored.
  B. similar to the process for creating other services and just like other services, they are created in the library area where Implementation library items are stored.
  C. different from the process for creating other services because they are coupled with the human service in which they are used. However, they are created in the library area where Implementation library items are stored.
  D. different from the process for creating other services because they are coupled with the human service in which they are used. This is why they are created in the library area where User Interface library items are stored.
  A. similar to the process for creating other services, except they are created in the library area where User Interface library items are stored.

• Question 39:

  A sales company wants to be able to report on the total amount of sales per region.

  How can a BPM application developer capture this information so that the data can be reported on? (Choose two) The BPM application developer needs to use:

  A. Autotracking
  B. Shared Business Object
  C. Exposed Process Value (EPV)
  D. Service Level Agreement (SLA)
  E. Custom Key Performance Indicator (KPI)
  A. Autotracking
  E. Custom Key Performance Indicator (KPI)

• Question 40:

  A BPM application developer is asked to route a task to a user in the participant group named "Loan Officers". In order to populate a list of all the direct users in the "Loan Officers" participant group, which one the following Javascript API calls can the BPM application developer use?

  A. tw.system.org.findAllUsersFrom("Loan Officers").get
  B. tw.system.org.findParticipantGroupByName("Loan Officers").users
  C. tw.system.org.findParticipantGroupByName("Loan Officers").allUsers
  D. tw.system.process.findParticipantGroupByName("Loan Officers").users
  B. tw.system.org.findParticipantGroupByName("Loan Officers").users
