Axis Communications AX0-100 Online Practice Questions and Exam Preparation

Axis Communications AX0-100 Online Questions & Answers

• Question 41:

  Adding network surveillance cameras to an existing Ethernet network

  A. Is not recommended, since bandwidth demands from the surveillance video would likely congest the network.
  B. Will benefit from using VLANs, to keep the surveillance video separate from other network traffic, reducing the risk for network congestion.
  C. Will cause unacceptable video latency, due to the amount of UDP traffic taking precedence on the network.
  D. Will benefit from establishing VPN connections to the cameras, reducing the risk of malicious users eavesdropping on the video.
  B. Will benefit from using VLANs, to keep the surveillance video separate from other network traffic, reducing the risk for network congestion.

• Question 42:

  Which feature in Axis cameras allows for a fixed box style camera to tell a PTZ camera to move to a preset?

  A. HTTP server
  B. QoS
  C. FTP server
  D. TCP/IP
  A. HTTP server

• Question 43:

  In setting up PTZ control for an Axis encoder, it's very easy to overlook a very important step in the configuration process. After properly connecting the communication wires to the encoder, the next recommended step in the setup is:

  A. Downloading the correct Device ID from the Axis website
  B. Setting the Baud Rate to match the analog PTZ' s
  C. Setting the Device ID to match the analog ID
  D. Uploading the correct PTZ driver
  D. Uploading the correct PTZ driver

• Question 44:

  Match the protocol to its default port number. Drag each gray box from the left column to the matching blue box in the right column.

  Select and Place:





• Question 45:

  The capability to view and record up to four different areas of the whole image of an AXIS P1346 is called

  A. Multicast streaming.
  B. Multi-view streaming.
  C. Broadcast streaming.
  D. Multi-link streaming.
  B. Multi-view streaming.

• Question 46:



  Which setting would best adjust a hard yellow tint as shown in the pictures below?

  A. Image contrast
  B. White balance
  C. Color saturation
  D. Image brightness
  B. White balance

• Question 47:

  After an installer sets up a motion detection window they then zoom out the camera. How will this affect the camera's ability to detect motion if no settings are changed?

  A. More pixels are needed to change to trigger motion detection
  B. Less pixels are needed to change to trigger motion detection
  C. More movement needed to change to trigger motion detection D. Less movement needed to change to trigger motion detection
  C. More movement needed to change to trigger motion detection D. Less movement needed to change to trigger motion detection

• Question 48:

  An analog system that should be upgraded to IP using encoders must have the end of the analog signal terminated. How many Ohm () should that be?

  B. 55
  C. 60
  D. 75
  D. 75

• Question 49:

  The advantage of using multicast in the network is that

  A. Many cameras can share the same network connection.
  B. The video stream reaches every computer in the network simultaneously.
  C. The video stream only needs to be sent once, even though there are multiple viewers.
  D. The video stream is rerouted in case of network dropout.
  C. The video stream only needs to be sent once, even though there are multiple viewers.

• Question 50:

  Before upgrading firmware, which of the following should be checked?

  A. Verify that the Video Management Software (VMS) supports the latest firmware version
  B. Verify that both rack mounted and standalone servers support the latest firmware version
  C. Verify that the IEEE 802.3af compliant PoE switch supports the latest firmware version
  D. Verify that the SD card is properly ejected before the upgrade is started
  A. Verify that the Video Management Software (VMS) supports the latest firmware version
