Avaya ACSS-7240 72400X Questions & Answers

• Question 1:

  Among other video-related settings on Communication Manager, which parameter on a user's station form/ endpoint profile should be set to "Y" (YES) to allow video on calls between Avaya IXTM Workplace Clients?

  A. Direct Multimedia

  B. Enable Video

  C. H.264

  D. IP Video

  Correct Answer: D

  Reference: https://downloads.avaya.com/css/P8/documents/100133665

• Question 2:

  Which CLI command is used to launch the configuration script in AAWG Servers?

  A. configure app

  B. app configure

  C. application config

  D. app config

  Correct Answer: B

  Reference: https://downloads.avaya.com/css/P8/documents/101045462 (327)

• Question 3:

  An Avaya support engineer has advised the customer to use the Diagnostic feature of the Avaya IXTM Workplace Client for Windows to collect the client log files and attach them to an email message to Avaya Support.

  Where in the Avaya IXTM Workplace Client for Windows can the customer generate an email message with an attached zip archive of the Client logs?

  A. Select Settings > Trouble Ticket and then click on Report a Problem.

  B. Select Settings > Logs and then click on Report a Problem.

  C. Select Settings > Support and then click on Report a Problem.

  D. Select Settings > Log Pack and then click on Report a Problem.

  Correct Answer: B

• Question 4:

  A support technician wants to check if a specific Avaya IXTM Workplace user is receiving the correct

  configuration parameters from Avaya Aura Device Services (AADS).

  Which URL is used to verify this information?

  A. https:///acs/resources/configurations

  B. https:///aem/resources

  C. http:///acs/resources/configurations

  D. http:///aem/resources

  Correct Answer: A

  Reference: https://downloads.avaya.com/css/P8/documents/101064669

• Question 5:

  How does setting the "IP Video" parameter to "N" (NO) on the signaling group between Communication Manager and Session Manager affect Avaya IXTM Workplace Clients (Windows/Mac/iOS/Android)?

  A. The Clients can't use video during any type of calls.

  B. The Clients can use video when calling each other, but can't use video when calling CM (H.323) users.

  C. The Clients can use video during P2P calls, but can't use video during multipoint calls (calls to an Avaya Equinox Virtual Meeting Room).

  D. The Clients can use video during multipoint calls (calls to an Avaya Equinox Virtual Meeting Room), but can't use video during P2P calls.

  Correct Answer: B

• Question 6:

  A customer has hired a new system technician to support their Avaya IXTM Workplace solution. While troubleshooting an issue with Avaya IXTM Workplace AAMS, the system technician has locked the Avaya IXTM Workplace AAMS Server as part of the procedure, however accidentally forgot to unlock it later.

  How will Clients be affected by a locked AAMS?

  A. Avaya IXTM Workplace clients will display the error "AAMS resource is locked".

  B. Users will be able to register on their Avaya IXTM Workplace Clients (Windows/Mac/iOS/Android), but not on Avaya IXTM Workplace for Web Clients.

  C. Users will not be able to register on their Avaya IXTM Workplace Clients (Windows/Mac/iOS/Android) and Avaya IXTM Workplace for Web Clients

  D. Calls to/from Avaya IXTM Workplace for Web Clients will fail.

  Correct Answer: C

• Question 7:

  A user is trying to register their Avaya IXTM Workplace for Web Client from the Public Network, but it

  displays the message:

  "Connecting" indefinitely

  Using traceSBC reveals no messages at all.

  What is the reason for the clients failure to register?

  A. There is a problem with the user's Client certificate.

  B. The STUN/TURN configuration is incorrect on the ASBCE.

  C. The STUN/TURN configuration is incorrect on the Media Server.

  D. There is an issue with the ASBCE B1 interface.

  Correct Answer: D

• Question 8:

  If enabled on AAWG and assuming AAWG R3.3 default web access port setting, what is the URL format to access AAWG built-in Developer's Test Application?

  A. http://:8433/devclient/testApp/index.html

  B. https://:8444/devclient/Testapp/index.html

  C. https://:443/devclient/testapp/index.html

  D. http://:8443/devclient/Testapp/index.html

  Correct Answer: D

  Reference: https://downloads.avaya.com/css/P8/documents/101051566

• Question 9:

  Users are unable to access Avaya Equinox Conferencing for Web from the public network. One user said

  that when trying to access the Unified Portal, they received the following error message:

  HTTP Request Sent to HTTPS Port.

  What is causing this problem?

  A. In ASBCE "Rewrite URL", in the Reverse Proxy, is disabled.

  B. In ASBCE the "Rewrite URL" information, in the Reverse Proxy, is mis-configured for HTTP.

  C. Avaya Aura Web Gateway (AAWG) has been configured to block HTTPS.

  D. Avaya Aura Web Gateway (AAWG) has been configured to block HTTP.

  Correct Answer: B

• Question 10:

  The Instant Messaging and Multimedia Messaging capabilities of a User can be checked using which technique?

  A. From the Multimedia Messaging GUI on the Messaging Profile page

  B. From the Multimedia Messaging GUI on the User Management page

  C. Addressing a web browser to https:///acs/resources/configurations

  D. Addressing a web browser to https:///aem/resources

  Correct Answer: B
