Avaya 7220X Online Practice Questions and Exam Preparation

Avaya 7220X Online Questions & Answers

• Question 61:

  When viewing the Avaya Aura?System Manager (SMGR) alarms, which alarm information is particularly useful for finding more information in the available documentation?

  A. NotificationOID
  B. Status
  C. Source IP address
  D. Event ID
  E. M/E Ref Number/SysOID
  D. Event ID

• Question 62:

  When observing the Session Manager dashboard, you notice that one entity is marked as down. Which two troubleshooting tools can be used to investigate the problem? (Choose two.)

  A. List trace station on Avaya Aura?Communication Manager
  B. statapp on the Command Line Interface of Avaya Aura?Session Manager
  C. traceSM on the Command Line Interface of Avaya Aura?Session Manager
  D. the replication page in Avaya Aura?System Manager
  E. Avaya Aura?Session Manager Entity Link Connection Status page in Avaya Aura?System Manager
  C. traceSM on the Command Line Interface of Avaya Aura?Session Manager
  E. Avaya Aura?Session Manager Entity Link Connection Status page in Avaya Aura?System Manager

• Question 63:

  Who is responsible for completing Discipline 4 ?Determining Root Cause, of the 8D Troubleshooting Methodology?

  A. Avaya Tier 2
  B. Avaya Tier 1
  C. Avaya Tier 3
  D. Avaya Tier 4
  C. Avaya Tier 3

• Question 64:

  When retrieving a message from Avaya Aura?Messenger (AAM), what is the function of the RE-INVITE?

  A. The RE-INVITE is only used when the initial INVITE is not transmitted successfully.
  B. The RE-INVITE shuffles the media path off Avaya Aura?Communication Manager (CM).
  C. The RE-INVITE is to allow the user to be authenticated.
  D. The RE-INVITE is only sent if a voice port cannot be initially connected to the caller.
  C. The RE-INVITE is to allow the user to be authenticated.

• Question 65:

  A customer has just added a CS1000 SIP Entity and Entity Link using TLS port 5061. Users are unable to call any Avaya Aura?users which are connected via the same Avaya Aura?Session Manager (SM).

  They have run a traceSM and see no SIP messages coming from the CS1000 in the trace.

  They can ping between the CS1000 and SM100.

  Which two traces or logs are most relevant to debugging this problem and should be included in the trouble ticket raised with Tier 3 support? (Choose two.)

  A. "list trace tac xxx", where xxx is the TAC of the trunk group between Avaya Aura?Communication Manager and SM
  B. "tshark -i eth1 -w " on SM
  C. the latest /var/log/ecs logfile on Avaya Aura?Communication Manager
  D. traceSM with TLS handshaking enabled on SM
  E. the ppm.log in /var/log/Avaya/jboss/SessionManager on SM
  B. "tshark -i eth1 -w " on SM
  D. traceSM with TLS handshaking enabled on SM

• Question 66:

  Refer to the Exhibit.



  A SIP user is calling an H.323 user.

  In this call flow, in which phase does Avaya Aura?Communication Manager (CM) handle the call processing foe each endpoint?

  A. both endpoints in the originating phase
  B. H.323 endpoint in originating phase, SIP endpoint in terminating phase
  C. SIP endpoint on originating phase, H.323 endpoint in terminating phase
  D. both endpoints in the terminating phase
  C. SIP endpoint on originating phase, H.323 endpoint in terminating phase
