• Question 41:

  Which two statements describe the 8D Troubleshooting Methodology? (Choose two.)

  A. It is eight steps that guarantee a logical way to isolate an issue.
  B. It is eight steps that guarantee a thorough analysis of a failure, containment actions, full resolution, prevention for the future.
  C. It is eight steps that define how to escalate third-party integration issues.
  D. It is eight steps that used to guarantee systems are operational after an implementation.
  E. It is eight steps that ensure a faster time to resolution.
  B. It is eight steps that guarantee a thorough analysis of a failure, containment actions, full resolution, prevention for the future.
  D. It is eight steps that used to guarantee systems are operational after an implementation.

• Question 42:

  When viewing Avaya Aura?Communication Manager (CM) trusted certificates, you notice that the installed certificates are marked with either A, C, W, or R.

  What do these letters stand for?

  A. Accepted, Confirmed, Whitelisted and Rejected
  B. Accumulated, Compressed, Write and Read
  C. Authentication, Authorization and Accounting Services, Communication Manager, WEB Server and Remote Logging.
  D. Authentication, Access and Accounting Services, Communication Manager, Web Server and Remote logging.
  C. Authentication, Authorization and Accounting Services, Communication Manager, WEB Server and Remote Logging.

• Question 43:

  Immediately after Registration, how does an Avaya SIP telephone learn if any of its Call Forward features are active right now?

  A. It queries the LDAP database for active feature status.
  B. It sends a Subscribe ?avaya-cm-feature-status event package to Aura?Communication Manager (CM) via Aura?Session Manager (SM).
  C. It sends a PPM getDeviceData request to Aura?Session Manager (SM); Aura?Session Manager (SM) replies with a getDeviceData response.
  D. It sends a Subscribe ?avaya-ccs-profile event package to Aura?Session Manager (SM); Aura?Session Manager (SM) in turn replies with a Notify-avaya-ccs-profile.
  B. It sends a Subscribe ?avaya-cm-feature-status event package to Aura?Communication Manager (CM) via Aura?Session Manager (SM).

• Question 44:

  What is the function of a Virtual Network Region?

  A. It allows one Network Region to temporarily use bandwidth allocated to another Network Region if it runs out of bandwidth.
  B. It makes DSP resources available in other Network Regions.
  C. It allows Inter-Gateway Alternate Routing (IGAR).
  D. It prevents oversubscription of WAN links for interconnecting Network Regions with different bandwidth limitations.
  A. It allows one Network Region to temporarily use bandwidth allocated to another Network Region if it runs out of bandwidth.

• Question 45:

  How can you obtain a list of Avaya Aura?Communication Manager (CM) alarms that have been raised today, including previous alarms that are no longer active using CM SAT?

  A. Execute the display alarms previous command and hit F3.
  B. Execute the display alarms command, then change the 'Previous ?' field from N to Y and hit F3.
  C. Execute the display alarms command, then change the 'Resolved ?' field from N to Y and then hit F3.
  D. Execute the display alarms command, then change the 'Historical ?' field from N to Y and hit F3.
  C. Execute the display alarms command, then change the 'Resolved ?' field from N to Y and then hit F3.

• Question 46:

  A customer called Avaya Support after their telecom administrator was unable to add 50 new telephones for new hires. Avaya support determined that the number of telephones exceeded the capacity the system could support. Which pre-implementation step was omitted?

  A. Access support.avaya.com to verify customer systems compatibility.
  B. Test all third-party equipment and software.
  C. Verify version installed is compatible with existing versions.
  D. Provide accurate licensing specification.
  D. Provide accurate licensing specification.

• Question 47:

  A customer faces a situation in which the SIP endpoints do not register to Session Manager using Transport Layer Security (TLS). A test reveals that the SIP endpoints do register using the Transmission Control Protocol (TCP). While investigating the problem, the company decides to temporarily use the TCP.

  What 8D Discipline covers this decision?

  A. D5
  B. D4
  C. D2
  D. D1
  E. D3
  E. D3

• Question 48:

  Which Linux command allows you to view the installed certificates on Aura?Communication Manager (CM)?

  A. tlscertmanage
  B. show certs
  C. displaycertificates
  D. start certmanager -f
  A. tlscertmanage

• Question 49:

  A customer called Avaya Support stating that shortly after some maintenance work was done, they cannot make or receive calls.

  Which command in Avaya Aura?Communication Manager (CM) can the administrator execute, to determine if the H.248 Gateways were placed in a maintenance busy state?

  A. Status signaling group x
  B. Status health
  C. Status media-gateways
  D. Trace trunk x
  C. Status media-gateways

• Question 50:

  Refer to the Exhibits.



  The SIP call flow made from an Avaya Communicator Remote Worker is on the left, and the call flow made from a 96X1 telephone Remote Worker is on the right.

  When comparing the two call flows, which statement is true?

  A. There is no difference between the two.
  B. Avaya Aura?Communication Manager does full call model processing for the SIP-to- SIP call flow and does half-call model processing for the SIP-to-Communicator call flow.
  C. The Communicator does not register to Avaya Aura?Session Manager.
  D. The Communicator registers to Avaya Session Border Controller for Enterprise (SBCE).
  A. There is no difference between the two.
