Cisco 648-238 Online Practice Questions and Exam Preparation

Cisco 648-238 Online Questions & Answers

• Question 111:

  How many Cisco camera licenses are included with Cisco VSOM?

  A. None. Even though they are no-cost part numbers, you still must order them separately depending on the number of cameras you plan to use.
  B. 10000
  C. 1000
  D. No licenses are necessary for Cisco cameras.
  B. 10000

• Question 112:

  When a View is edited, which four parameters can be modified? (Choose four.)

  A. access location
  B. camera tour rotation order
  C. layout options
  D. cameras associated with a locked pane
  E. default video wall
  F. video wall rotation order
  A. access location
  B. camera tour rotation order
  C. layout options
  D. cameras associated with a locked pane

• Question 113:

  When adding a backup media server to VSOM, which of the following options is not correct?

  A. Backup media server can back up archives from multiple media servers
  B. Camera recordings can be selectively backed up
  C. Either full recording or events from the past 24 hours can be backed up on a daily basis
  D. Backups can be scheduled to occur in the future, for example, after one week or one month
  D. Backups can be scheduled to occur in the future, for example, after one week or one month

• Question 114:

  Cisco UCS B-Series chassis is populated with five half-width B200 compute blades. Each blade is configured with dual 6-core, 3 Ghz Intel Xeon processors and 96 GB of RAM. Assume 2 Mb video stream per camera and that no additional applications are running on this system.

  Which two configurations are valid and supported by this chassis? (Choose two.)

  A. 1 x VSOM virtual servers 20 x VSMS virtual servers 2,000 x cameras
  B. 2 x VSOM virtual servers 18 x VSMS virtual servers 2,000 x cameras
  C. 3 x VSOM virtual servers 15 x VSMS virtual servers 2,000 x cameras
  D. 4 x VSOM virtual servers 16 x VSMS virtual servers 2,000 x cameras
  E. 5 x VSOM virtual servers 20 x VSMS virtual servers 2,500 x cameras
  B. 2 x VSOM virtual servers 18 x VSMS virtual servers 2,000 x cameras
  D. 4 x VSOM virtual servers 16 x VSMS virtual servers 2,000 x cameras

• Question 115:

  In Cisco VSM 7.x, how can PTZ cameras be controlled?

  A. USB joystick only
  B. USB mouse only
  C. USB joystick and USB mouse are both required to control PTZ cameras.
  D. USB joystick or USB mouse can be used to control PTZ cameras.
  D. USB joystick or USB mouse can be used to control PTZ cameras.

• Question 116:

  When a Video Wall is edited, which three options can be modified? (Choose three.)

  A. access location
  B. camera tour rotation order
  C. layout options
  D. rollback time
  E. default view
  F. video wall rotation order
  A. access location
  D. rollback time
  E. default view

• Question 117:

  Which Cisco technology is embedded in Cisco IP cameras that simplifies deployment of video surveillance, saves time, and reduces network configuration errors?

  A. Medianet MSI
  B. Medianet MSP
  C. Cisco Discovery Protocol
  D. Medianet Experience Engine
  A. Medianet MSI

• Question 118:

  In the Cisco VSM 7.0.x solution, where should you install a new, third-party IP camera driver?

  A. Cisco VSOM only
  B. Cisco VSMC only
  C. Cisco VSMS only D. Third-party camera drivers can be installed through Cisco VSOM, Cisco SASD, and Cisco VSMC.
  E. Third-party camera drivers are not installed via Cisco VSOM, Cisco VSMS, nor Cisco VSMC.
  B. Cisco VSMC only

• Question 119:

  Refer to the exhibit.



  Cameras and a Cisco VSM server are connected to a Layer 2 switch.

  Which three steps will allow the Cisco VSM servers to see video traffic from the two IP cameras? (Choose three.)

  A. GigE 0/10 should be configured to accept traffic from all VLANs using the #switchport mode access vlan all command.
  B. GigE 0/10 should be configured to dynamic mode using the #switchport mode dynamic desirable command.
  C. Implement "router-on-a-stick".
  D. Implement inter-VLAN routing.
  E. The link between GigE 0/5 and FE 1/1 should be configured as a trunk port.
  C. Implement "router-on-a-stick".
  D. Implement inter-VLAN routing.
  E. The link between GigE 0/5 and FE 1/1 should be configured as a trunk port.

• Question 120:

  What is the approximate usable drive capacity for a CPS-MSP-2RU-K9 with half of the drive bays populated with 2 TB HDDs?

  A. 4 TB
  B. 8 TB
  C. 10 TB
  D. 20 TB
  B. 8 TB
