VMware VMware SD-WAN Design and Deploy 2021 5V0-42.21 Questions & Answers

• Question 1:

  Refer to the exhibit.



  An MSP is designing a solution for a merger of Customer A and Customer B to Customer A's enterprise. Due to overlapping IP addresses and security requirements, the segments with the same names between Customer A and Customer A cannot be merged. Based on the graphic and the requirements, how many new segments need to be configured in the VMware SD-WAN Orchestrator?

  A. 4 segments

  B. 2 segments

  C. 6 segments

  D. 5 segments

  Correct Answer: D

• Question 2:

  A technician needs to SSH to it VMware SU-WAN Virtual Edge running version 3.3.2. What is the default password?

  A. adnim

  B. No password required

  C. Password configured in cloud_init

  D. velocloud

  Correct Answer: C

• Question 3:

  Which form factor can a customer use to deploy VMware SD WAN Edge?

  A. Oracle Virtual Box

  B. Open Virtualization Appliance

  C. Docker Container

  D. Hyper-V Virtual Machine

  Correct Answer: B

• Question 4:

  A service provider assigns two Partner Gateways to a VMware SD-WAN Edge. Which description is correct about default route.

  A. A default route 0.0.0.0/0 can be configured as a static route and set to NAT only on the Gateway

  B. It default route 0 0 0.010 has been configured for both Gateways, internet traffic originated from the Edge can failover to the other Gateway in case of a Gateway failure.

  C. When handoff is turned off on a Partner Gateway, the Gateway does not advertise a default route 0.0 0.0/0 to the Edge.

  D. The service provider administrator decides whether the Partner Gateway advertises a default route 0.0.0.0/0 or not, although it is advertised by default.

  Correct Answer: A

• Question 5:

  Which VMware SD-WAN component Is responsible for overlay route distribution?

  A. VMware SD-WAN Controller

  B. VMware SD-WAN Orchestrator

  C. VMware SD-WAN Edge

  D. VMware SD-WAN Hub

  Correct Answer: A

• Question 6:

  A customer has a hybrid VMware SD-WAN deployment and wants to use the SD-WAN Service Reachable

  feature on the private WAN.

  What is the main dependency that must be met for the feature to work?

  A. Internet reachability via the private WAN

  B. Gateway IPs must be routed in the overlay

  C. Default route learned via dynamic routing

  D. Static mute for gateway IPs on the edge

  Correct Answer: C

• Question 7:

  What is considered a typical VMware SD-WAN use case?

  A. Provide a distributed (per device) commands line interface (CLI) based configurations to implement complex network design integration options.

  B. Provide high speed layer 2 data center interconnects.

  C. Provide cloud delivered central management Orchestrator to implement complex design network integration options.

  D. Provide management, control plane, and data forwarding from a single system to reduce complexly for the network administrator.

  Correct Answer: D

• Question 8:

  A network architect from a service provider is designing an architecture using a VMware SD-WAN Partner

  Gateway handoff.

  Which dynamic routing protocol should the engineering choose?

  A. RIP Version 2

  B. OSPF

  C. Static

  D. BGP

  Correct Answer: A

• Question 9:

  Due to very strict security policies an enterprise customer is looking for an on-premises deployment of the VMware SD-WAN Orchestrator and Controllers. Customer data is not expected to flow through this Controller, however it is desirable that management plane traffic towards the Orchestrator coming from VMware SD-WAN Edges can take the overlay tunnels through this controls. What are some of the needed steps to achieve the requirements above?

  A. Under gateway configuration -> Configure the Gateway roles as Control Plane, disable Data Plane and enable management plane forward

  B. Under gateway configuration -> Configure the Gateway roles as Control Plane, disable Data Plane and add static host routes with NAT hand off settings porting to the Orchestrator IPs under Partner Gateway advanced hand off settings

  C. Under gateway configuration -> Configure the Gateway roles as Control-Plane, enable Data Plane and Partner Gateway role and add static host mules with NAT hand off settings pointing to the Orchestrator IPs under Partner Gateway advanced hand off settings

  D. Under gateway configuration -> Configure the Gateway roles as Control-Plane, enable Data Plant- and Partner Gateway role and add a static default route with NAT hand off settings under Partner Gateway advanced hand oft settings

  Correct Answer: C

• Question 10:

  An administrator is looking for a cost effective model of hardware-based Edge for some branch offices. The

  device must be mounted in rack cabinet, and to meet performance requirements and projected growth, the

  appliance must support up to 2 Gpbs bandwidth.

  Which Edge model satisfies these requirements?

  A. Edge 3400

  B. Edge 540

  C. Edge 510

  D. Edge 620

  Correct Answer: B
