Cisco 350-801 Online Practice Questions and Exam Preparation

Cisco 350-801 Online Questions & Answers

• Question 91:

  Which statement about Cisco Unified Communications Manager and Cisco IM and Presence backups is true?

  A. Backups should be scheduled during off-peak hours to avoid system performance issues.
  B. Backups are saved as .tar files and encrypted using the web administrator account.
  C. Backups are saved as unencrypted .tar files.
  D. Backups are not needed for subscriber Cisco Unified Communications Manager and Cisco IM and Presence servers.
  A. Backups should be scheduled during off-peak hours to avoid system performance issues.

  ---

  Explanation

  References:

  https://www.cisco.com/c/en/us/td/docs/voice_ip_comm/cucm/admin/11_5_1_SU1/Administration/cucm_b_administration-guide-1151su1/cucm_b_administration-guide-1151su1_chapter_01010.html#CUCM_TK_S7FC26D5_00

• Question 92:

  Refer to the exhibit. A collaboration engineer adds an analog gateway to a Cisco UCM cluster. The engineer chooses MGCP over SCCP as the gateway protocol.



  Which two actions ensure that the gateway registers? (Choose two.)

  A. Delete and re-add the gateway configuration in Cisco UCM.
  B. Enter "mgcp" on the gateway in configuration mode.
  C. Enter "no sccp" on the gateway in configuration mode.
  D. Enter "ccm-manager config" on the gateway in configuration mode.
  E. Enter "ccm-manager mgcp" on the gateway in configuration mode.
  B. Enter "mgcp" on the gateway in configuration mode.
  E. Enter "ccm-manager mgcp" on the gateway in configuration mode.

  ---

  Explanation

  References:

  https://community.cisco.com/t5/unified-communications/cisco-router-2901-mgcp-x-callmanager-9-1-1/td-p/2419551

• Question 93:

  What is the most important consideration when designing a QoS voice framework?

  A. bandwidth calculations
  B. codec selection
  C. speed propagation
  D. Layer 2 overhead consumption
  B. codec selection

• Question 94:

  A company deploys centralized cisco ucm architecture for a hub location and two remote sites.

  1. The company has only one ITSP connection at the hub connection, and ITSP supports only G.711 calls

  2. Remote site A has a 1-Gbps fiber connection to the hub connection and calls to and from remote side A use G.711 codec

  3. Remote site B has a 1 T1 connection to the hub location and calls to and from remote site B use G.729 codec Based on the provided guidance, a Cisco voice engineer must design media resource management for the customer.

  What is the method that needs to be followed?

  A. configure the hardware transcoder on the site B router.
  B. configure the hardware transcoder on the site A router.
  C. configure the hardware transcoder on the hub location router.
  D. configure the software transcoder on Cisco UCM to support voice calls to and from both remote sites.
  C. configure the hardware transcoder on the hub location router.

  ---

  Explanation

  Site B has a T1 connection and we don't want to force them to limit the number of calls. As an administrator, i would take the incoming calls from site B in G729 and do a transcode at the hub location, and receive an Incoming call to Site B in G 711 and transcode it to G729 and traverse over T1. Win Win situation.

• Question 95:

  What is required when deploying co-resident VMs by using Cisco UCM?

  A. Provide a guaranteed bandwidth of 10 Mbps.
  B. Ensure that applications will perform QoS.
  C. Avoid hardware oversubscription.
  D. Deploy the VMs to a server running Cisco UCM.
  C. Avoid hardware oversubscription.

  ---

  Explanation

  When deploying co-resident VMs by using Cisco UCM, it is important to avoid hardware oversubscription. This means that you should not assign more resources to the VMs than the physical hardware can provide. For example, if you have a server with 16 CPU cores, you should not assign more than 16 CPU cores to the VMs. If you oversubscribe the hardware, the VMs will not be able to get the resources they need to run properly. This can lead to performance problems and even outages. To avoid hardware oversubscription, you should carefully plan your VM deployments. You should also monitor the performance of the VMs to make sure that they are not overusing the resources.

  Here are some additional tips for deploying co-resident VMs by using

  Cisco UCM: Use a virtualization platform that supports Cisco UCM. Make sure that the VMs have the correct operating system and software installed. Configure the VMs to use the correct network settings. Monitor the performance of the VMs to make sure that they are running properly.

  References:

  https://www.cisco.com/c/dam/en/us/td/docs/voice_ip_comm/uc_system/virtualization/collaboration-virtualization-sizing.html

• Question 96:

  Which DiffServ marking is the most likely to drop packets?

  A. AF32
  B. AF12
  C. AF11
  D. AF13
  D. AF13

  ---

  Explanation

  Resource

  https://www.cisco.com/c/en/us/td/docs/ios-xml/ios/qos_dfsrv/configuration/15-mt/qos-dfsrv-15-mt-book/qos-dfsrv.html

• Question 97:

  An engineer must configure switch port 5/1 to send CDP packets to configure an attached Cisco IP phone to trust tagged traffic on it's access port.

  Which command is required to complete the configuration?

  Router# configure terminal

  Router(config)# interface gigabitethernet 5/1

  Router(config-if)# description Cube E42.421-5965

  A. platform qos trust extend cos 3
  B. platform qos trust extend
  C. platform qos extend trust
  D. platform qos trust extend cos 5
  B. platform qos trust extend

  ---

  Explanation

  https://www.cisco.com/c/en/us/td/docs/switches/lan/catalyst6500/ios/15-5SY/config_guide/sup6T/15_5_sy_swcg_6T/voip.html

• Question 98:

  Which action is required for a firewall configuration on a Mobile and Remote Access through Cisco Expressway deployment?

  A. The external firewall must allow these inbound connections to Expressway: SIP: TCP 5061: HTTPS: TCP 8443; XMPP: TCP 5222; Media: UDP 36002 to 59999.
  B. The internal firewall must allow these inbound and outbound connections between Expressway-and Expressway-E: SIP: HTTPS (tunneled over SSH between and E): TCP 2222: TCP 7001; Traversal Media: UDP 2776 to 2777 (or 36000 to 36011 for large VM/appliance); XMPP: TCP 7400.
  C. Do not use a shared address for Expressway-E and Expressway-, as the firewall cannot distinguish between them. If static NAT for IP addressing on Expressway-E is used, ensure that any NAT operation on Expressway-does not resolve the same traffic IP address. Shared NAT is not supported.
  D. The traversal zone on Expressway-points to Expressway-E through the peer address field on the traversal zone, which specifies the Expressway-E server address. For dual NIC deployments, set the Expressway-E address using an FQDN that resolves the IP address of the internal interface.
  A. The external firewall must allow these inbound connections to Expressway: SIP: TCP 5061: HTTPS: TCP 8443; XMPP: TCP 5222; Media: UDP 36002 to 59999.

  ---

  Explanation

  References:

  https://www.cisco.com/c/dam/en/us/td/docs/voice_ip_comm/expressway/config_guide/X8-7/Cisco-Expressway-IP-Port-Usage-for-Firewall-Traversal-Deployment-Guide-X8-7.pdf

• Question 99:

  After an engineer implements the FAC and CMC features together, users report that calls take almost one minute to complete and that they occasionally hear the reorder tone.

  Which two actions address this issue? (Choose two.)

  A. Do not wait for the tones; immediately dial the FAC and CMC.
  B. Advise the user to hang up and try again.
  C. Advise the user to press the button after dialing the FAC and CMC codes.
  D. Change the code if the problem persists.
  E. Adjust the T302 timer from the default of 15 seconds to 5 seconds to shorten the interdigit timer.
  C. Advise the user to press the button after dialing the FAC and CMC codes.
  E. Adjust the T302 timer from the default of 15 seconds to 5 seconds to shorten the interdigit timer.

• Question 100:

  Refer to the exhibit.



  Which option describes the security encryption status of this active call on a Cisco IP phone?

  A. unencrypted call signaling and media
  B. encrypted call signaling but unencrypted call media
  C. encrypted call media but unencrypted call signaling
  D. encrypted call signaling and media
  E. Not enough information provided to answer this question.
  D. encrypted call signaling and media
