F5 301A Online Practice Questions and Exam Preparation

F5 301A Online Questions & Answers

• Question 31:

  An LTM is configure an application that is separated into several subdomains across multiple virtual servers. Many of these subdomains require encryption and could be accessed by anyone on the internet. The configuration must NOT result in SSL warnings to end users. How should the LTM Specialist configure the SSL profiles for these virtual servers?

  A. Obtain an SSL certificate for each subdomain, make a ServerSSL profile for each subdomain, and apply to the related SSL Virtual Server.
  B. Obtain a wildcard certificate, create one ClientSSL profile and apply to all SSL Virtual Servers
  C. Create a self-singed SSL certificate for each subdomain make a ClientSSL profile for each subdomain, and apply to the related SSL Virtual server
  D. Create a self-singed SSL certificate for each subdomain make a Client profile for each SSL Virtual Server
  B. Obtain a wildcard certificate, create one ClientSSL profile and apply to all SSL Virtual Servers

• Question 32:

  An LTM Specialist needs to use a set of addresses to access an Internet website in an outbound configuration. Which feature should the LTM Specialist configure?

  A. NAT pool
  B. NAT address
  C. SNAT pool
  D. SNAT address
  C. SNAT pool

• Question 33:

  An LTM device receives a response string containing "error" Which monitor type and parameter will mark the HTTP server as down?

  A. HTTP monitor, Receive String "error", and set the Reverse option to Yes
  B. HTTP monitor and Receive String "error'' ... flag is up
  C. HTTP monitor. Receive String "down", and set the Reverse option to Yes .... flag is
  D. HTTP monitor and Receive Disable String "error'' .... flag is disable
  A. HTTP monitor, Receive String "error", and set the Reverse option to Yes

• Question 34:

  Exhibit.



  The three VLANS shown provide connectivity to backend servers. The backend servers are being moved to unmanaged switches and require separate interfaces. How should the F5 device interfaces be configured?

  A. Create a Trunk interface and combined interface 1.1.1.2 and 1.3.
  B. Create a Trunk interface and select VLAN,,A, VLAN_B. and VLAN_C.
  C. Create VLAN named VLAN_A enter 100 under Tag and move interface 1.1 to tagged Create VLAN_B enter 200 and move interface 1.2 to tagged Create VLAN_C Center 300 and move interface 1.3 to tagged.
  D. Create VLAN_A move interface 1.1 to untagged. Create VLAN_B move interface 1.2 to untagged. Create VLAN_C move interface 1.3 to untagged.
  D. Create VLAN_A move interface 1.1 to untagged. Create VLAN_B move interface 1.2 to untagged. Create VLAN_C move interface 1.3 to untagged.

• Question 35:

  An LTM Specialist must create a new virtual server for HTTP access. The LTM Specialist creates a forwarding virtual server to reach the resource. What is a potential result of this action?

  A. IP conflict result
  B. HTTP traffic is NOT allowed
  C. Other service ports could be allowed
  D. Packet filter allowances are also required
  B. HTTP traffic is NOT allowed

• Question 36:

  An LTM Specialist has recently taken over administration or an LTM device that has experienced resource availability issues. The LTM device will need to be solely used for load balancing and SSL offload. Previously, the LTM device was also used to provide statistical analysis of application traffic. However, that functionality has been moved to a third party solution. Based on the output below, which configuration change should be made to ensure the LTM module receives the most amount of resources?



  A. Provision AVR to Minimum. Provision LTM at Maximum
  B. Provision AVR to none. Provision LTM to Dedicated
  C. Provision AVR to Minimum, Provision LTM to Dedicated
  D. Provision LTM to Dedicated, Provision AVR to Dedicated
  B. Provision AVR to none. Provision LTM to Dedicated

• Question 37:

  An application is expected to maintain more than 100,000 concurrent TCP connections to a single pool member. What is an appropriate SNAT configuration in this situation?

  A. A SNAT pool with 4 IP addresses
  B. SNAT automap enabled
  C. A static SNAT
  D. A SNAT pool with IP address
  A. A SNAT pool with 4 IP addresses

• Question 38:

  An LTM Specialist to configure a backend server to be disabled it takes longer than 30 seconds to respond to a request. Which values should the LTM Specialist enter for interval and timeout?

  A. Interval 10, timeout 30
  B. Interval 10, timeout 31
  C. Interval 30, timeout 30
  D. Interval 30, timeout 91
  B. Interval 10, timeout 31

• Question 39:

  Refer to the exhibit.



  The LTM devices LTM3 and LTM2 have four Traffic Groups defined with approximately the sar of failover objects defined in each group.

  -

  Traffic Groups A and C have Default Device set to LTM1

  -

  Traffic Groups Band D have Default Device set to LTM2.

  -

  Traffic Groups B and C do NOT have Auto Failback enabled. Traffic Groups A and D have Auto Failback enabled with a timeout value of 60 seconds.

  -

  Traffic Groups A and D have Auto Fallback enabled with a timeout value of 60 seconds. Both LTM devices are healthy and able to pass traffic for any Traffic Group. LTM1 loses connectivity on interface 1.4. The LTM Specialists notified 60

  seconds after the interface goes down.

  What is the state of the Traffic Groups on each LTM device?

  A. LTM1: Traffic Group C LTM2: Traffic Groups A, B, and 0
  B. LTM1: No Traffic Groups LTM2: Traffic Groups A, B. C, and D
  C. LTM1: Traffic Groups A, B, C, and D LTM2: No Traffic Groups
  D. LTM1: Traffic Groups B and C LTM2: Traffic Groups A and 0
  B. LTM1: No Traffic Groups LTM2: Traffic Groups A, B. C, and D

• Question 40:

  A company plans to launch a huge marketing campaign and expects increase demand of their secure website. With the current virtual server setup, the LTM Specialist expects that the LTM device will reach its capacity limits. For the wen application to function properly. Cookies persistence is required. The LTM Specialist needs to reduce LTM device load without breaking the application. Which two settings should the LTM Specialist modify to meet the requirement? (Choose two.)

  A. Remove HTTP compression profile
  B. Remove HTTP profile
  C. Remove web acceleration profile.
  D. Modify virtual Server type to performance (Layer 4)
  E. Remove ClientSSL profile
  A. Remove HTTP compression profile
  C. Remove web acceleration profile.
