F5 LTM Specialist 301A Questions & Answers

• Question 21:

  An LTM Specialist needs to create a pool with a set of monitor that checks both the pool members and corresponding application service ports. The pool members have services on port 80. The application service is on port 8009. The LTM device should load balance traffic to the pool member when the pool member and corresponding application service pass monitor. Which monitor and parameter set meets this requirement?

  A. TCP monitor for port* Plus a custom TCP monitor with alias port 8009, And the pool's availability requirements set to the ALL

  B. TCP monitor for port Plus a ustom TCP monitor with alias port 8009, And the pool's availability requirement set to All

  C. TCP monitor for port* Plus a custom TCP monitor with alias port 8009 And the pool `s availability requirement set to 1.

  D. TCP monitor for port Plus a custom TCP monitor with alias port 80 And the pool's availability requirement set to ALL

  Correct Answer: A

• Question 22:

  Refer to the exhibit.



  The pool shown is configured with four pool members in a variety of states. The application is receiving a

  large number of request. The LTM Specialist needs to make changes to make sure that all members

  receive the same levels of traffic.

  Which changes need to be made?

  A. Enable 10.80.1.40 disable priority group activation, enable ratio

  B. Enable 10.80.1.40 and 10.80.1.1.20 disable group activation, enable Round Robin

  C. Enable 10.80.1.20 disable priority group activation, enable Round Robin

  D. Enable 10.80.1.40 and 10.80.1.20 disable priority group activation, enable ratio.

  Correct Answer: B

• Question 23:

  A new iRule needs to be tested. The LTM Specialist needs to measure page load times and monitor potential changes in memory usage A load test is scheduled. Which two features should the LTM Specialist use to monitor these requirements? (Choose two.)

  A. Tmsh show memory

  B. Analytics

  C. Tmsh show sys proc-info

  D. Tmsh show sys provision

  Correct Answer: BC

  Need to detect memory changes in real time, use to Page load times with Analytics profile

• Question 24:

  An LTM Specialist is the administrator of an HA pair that contains two BIG IP units and one floating traffic group (TG1). A new project requires the creation of 30 virtual servers. The Specialist decides to create a new floating traffic group (TG2) to handle this requirement. Objects for this project created by the BIG-IP Managers must appears in the correct traffic group. Which configuration should the LTM Specialist use to meet the requirement?

  A. Move the BIG-IP Managers from TG1 to TG2

  B. Create a new partition and set the default traffic group to TG2

  C. Modify the default traffic group of the Common partition to TG2

  D. Restrict the Traffic Group Access of BIG-I Managers to TG2

  Correct Answer: B

• Question 25:

  The network team introduces a new subnet 10.10.22.0/24 to the network. The route needs to be

  configured on the F5 device to access this network via the 30.30.30.158 gateway.

  How should the LTM Specialist configure this route?

  A. Tmsh modify net route 10.10.22/24 gw 30.30.30.158

  B. Tmsh create net route 10.10.22/24 gw 30.30.30.158

  C. Tmsh changey net route 10.10.22/24 gw 30.30.30.158

  D. Tmsh add net route 10.10.22/24 gw 30.30.30.158

  Correct Answer: B

• Question 26:

  An LTM Specialist needs to use the tmsh command to create a pool named http_pool with member

  10.10.101:80

  on an LTM device. Which expression should the LTM Specialist use?

  A.

  # tmsh create pool http_pool members {10.10.10.101:80}

  B.

  # tmsh create pool http_pool members add {10.10.10.101:80}

  C.

  # tmsh create it pool http_pool members {10.10.10.101:80}

  D.

  # tmsh create itm pool http_pool member {10.10.10.101:80}

  Correct Answer: C

  The option should be wrong, it should ne itm instead of it, the correct command is:tmsh create itm pool http_pool members add (10.10.10.101:80}

• Question 27:

  An LTM Specialist is configuring a client profile to offload processing a new application Company policy

  requires that clients can resume session for up to 30 minutes, but must renegotiate a new session after

  that.

  Which setting should the LTM Specialist change to satisfy this requirement?

  A. Renegotiate Max Record Delay

  B. Renegotiation period

  C. Cache size

  D. Cache timeout

  Correct Answer: D

• Question 28:

  An LTM Specialist upgrades the switching infrastructure and the backend servers on the LAN segments.

  The LTM Specialist notices a 20% memory usage increase on the BIG-IP device while handling the same

  number of concurrent connections.

  A comparison of statistics pre-upgrade and post-upgrade shows a significant reduction on the following:

  -RTT between the BIG-IP device and the backend servers

  -Packet drops in the switch

  Time to First Byte (TTFB)

  The LTM Specialist is concerned with the scalability of the number of concurrent connections with the new

  memory usage.

  Which setting should be changed to reduce the memory usage on the BIG-IP device?

  A. Reduce the proxy buffer high setting on the server-side TCP profile

  B. Increase the receive window of the client-side TCP profile

  C. Increase the proxy buffer high setting on the server-side TCP profile

  D. Reduce the idle of the client-side TCP profile

  Correct Answer: A

  After adjusting the architecture, the network quality becomes better. With the connection unchanged the memory usage increase by 20%. It means that the sending speed of the server is higher than the receiving speed of the client. F5 caches more content on the memory and causes the memory usage to....

• Question 29:

  An LTM Specialist needs to upgrade all guests on a Viprion eight CMP guests. What is the maximum number of guests that the LTM Specialist should upgrade at once?

  A. Eight

  B. One

  C. TWO

  D. Four

  Correct Answer: B

• Question 30:

  An LTM Specialist needs to force only FTP traffic, sourced from subnet 10.10.10.0/24 to virtual server

  10.10.20.1 to the new FTP1 server. The following virtual servers are configured on the LTM device: Traffic sourced from 10.10.10/24 must use the specific pool member for load balancing. Which configuration change is needed to meet the requirements?

  A. Create a new virtual server for traffic sourced from 10.10.10.0/24 on port 80 that is destined to 10.10.20.1/32, and create a new pool has only the pool member FTP1 defined.

  B. Add FTP1 to the pool assigned to the MyVS4 virtual server, and remove all other pool members from the pool.

  C. Create a new virtual server for traffic sourced from 10.10.10.0/24 on traffic sourced from 10.10.10./24

  on port 21 that is destined to 10.10.20.1/32, and create a new pool that has only the pool member FTP1 defined.

  D. Add FTP1 to the pool assigned to the MyVS2 virtual server, and remove all other pool member from the pool.

  Correct Answer: D

  According to the VS matching order, first match the destination host IP, then match the destination port and finally match the source network segment. In the current network configuration, 10.10.10./24 access to

  10.10.10.20.1 will hit MyVS2.

  If there is no error in the title, subnet 10.10.10.0 to virtual

  Server 10.10.20.1 to the FTP1 server,'' Is to distribute all traffic from 10.10.10.1 to FTP1, then D That's

  right.
