F5 LTM Specialist 301A Questions & Answers

• Question 131:

  A design requires the LTM device to become HA standby when the one of the two physical interface on the External trunk is down the External trunk is an interface on the External VLAN Which TMOS command enables this behavior?

  A. tmsh modify net van External failsafe enabled

  B. tmsh create sys ha-group External trunks add Externally

  C. tmsh create sys ha-group External trunks add External threshold 2 weight 101)

  D. tmsh create sys ha-group External trunks add ( External( attribute percent up-members 100))

  Correct Answer: C

• Question 132:

  Traffic to a pool of SFTP servers that share storage must be balanced by an LTM device. What are the required profile and persistence settings for a standard virtual server?

  A. tcp, ctientsst, ftp serverssl persistence

  B. tcp, clientssl, serverssl persistence

  C. tcp, ftp - Source address persistence

  D. tcp - no persistence profile will be used

  Correct Answer: C

• Question 133:

  set payload {CACHE :: payload}

  }

  Which two profiles should be used on the virtual server? (Choose two.)

  A. http-transparent

  B. http compression

  C. http

  D. webacceleration

  E. stream

  Correct Answer: CD

• Question 134:

  An LTM device needs an additional traffic group. Which configuration item is required?

  A. Default device

  B. Group name

  C. MAC Masquerade Address

  D. Auto Fallback Timeout

  Correct Answer: B

• Question 135:

  A new HITP server has been deployed on an LTM device. The application running on the server must be

  monitored by the LIM device. The following is required:

  When the server is unavailable, it will send an HTTP status code of 200 in response to a request for the

  status html page.

  When the server is available. I will send and HTTP status code of 201 in response to a request for the

  status html page.

  When the 200 status code is received, the pool member should receive No new connections. Which

  configuration change should be made to meet these requirements?

  A. set the Send String to GET/ status html and the Receive String to 200 and Receive Disable String to

  201.

  B. set the Send String to GET Arian and the Receive String to 200 and Receive Disable String to 201.

  C. set the Send String to GET Arian and the Receive Disable String to 200 and Receive String to 201.

  D. set the Send String to Get /status html and the Receive Disable String to 200 and Receive String to

  201.

  Correct Answer: D

• Question 136:

  A pool with a default connection limit is configured to use Round Robin as the load balancing method. An

  LTM Specialist needs to ensure that the LTM device selects a server with the fewest number of

  connections when new clients connect.

  Another pool is using the same set of backend servers.

  Which load balancing-method should the pool be changed to?

  A. Weighted Least Connections (node]

  B. Weighted Least Connections (member)

  C. Least Connections

  D. Least Connections

  Correct Answer: C

• Question 137:

  An ITM Specialist has the configuration shown: The LTM Specialist needs to create a new virtual server in part B. Which virtual address(es) should be used for the new virtual server?



  A. 10.100.0.1 and.10.120.0.1

  B. 10.90.0.1 and 10.12.0.1

  C. 10.120.0.1 only

  D. 10.90.0.1 and 10.100.0.1

  Correct Answer: A

• Question 138:

  Remote users who access the LTM device are authenticated via Radius. The default remote user role is

  Guest Some users need LTM device with the Administrator role. The F5 Radius attributes are configure on

  the Radius server.

  Which configuration item needs to be created?

  A. Remote User role

  B. Admin account

  C. User role

  D. User account

  Correct Answer: A

• Question 139:

  An HTTP monitor is created and assigned to a pool with the following non-default configuration: Interval: 7 seconds Timeout: 22 seconds Reverse: Yes Send String: GET/status.html HTTP/1.1/r/nHost:test.example.com/r/nConnector:Close Receive String: Up The HTTP server sends the following response:



  What is the resulting pool status?

  A. Unavailable (Enabled)

  B. Available (Enabled)

  C. Offline (Enabled)

  D. Unknown (Disabled)

  Correct Answer: A

• Question 140:

  An LTM Specialist needs to load balance an application using an LTM device to meet the requirements:

  1.

  The application servers do NOT Support SSL, but client access to the application should be secured.

  2.

  Multiple requests from the same client should be sent to the same pool member.

  3.

  All pool members will have roughly the same processing power, and traffic should be distributed evenly.

  The LTM device is NOT the pool members' default gateway. Which configuration should the LTM Specialist.

  A. a performance 14 virtual server with a SNAT and cookie persistence

  B. a performance L4 virtual server with a Client SSL profile and Source Address persistence

  C. A performance L4 virtual server with a SNAT, HTTP profile. Server SSL profile, and cookie persistence

  D. A standard virtual server with a SNAT, HTTP profile Server SSL profile, and cookie persistence

  E. A standard virtual server with a SNAT, HTTP profile, Client profile, andd cookie persistance.

  Correct Answer: E
