Cisco 300-630 Online Practice Questions and Exam Preparation

Cisco 300-630 Online Questions & Answers

• Question 31:



  Refer to the exhibit. A customer experiences resource overconsumption on one of its border leaf switches. Which action should be taken to reduce the consumption on this switch?

  A. Disable VRF Policy Control Enforcement
  B. Disable IP Data Plane Learning
  C. Migrate L3Outs to another switch
  D. Disable Remote EP Learning
  D. Disable Remote EP Learning

• Question 32:

  An engineer troubleshoots a Cisco ACI fabric and receives this output.



  What does tunnel 6 use?

  A. default VRF
  B. GRE protocol
  C. jumbo frames
  D. public IP address
  B. GRE protocol

• Question 33:



  Refer to the exhibit. The client endpoint uses the load-balancer VIP as the destination address to send traffic to the server endpoint. If the load balancer does not do source NAT, which set of configurations must be applied on Cisco ACI to allow only the return traffic to be redirected to the service node?

  A. 1. Create a contract with a filter matching "IP" only 2. Create a L4-L7 device, function type "GoTo" 3. Create a L4-L7 Policy-Based Redirect Policy with the L3 Destination set to the load-balancer inside IP/MAC 4. Create a service graph template that references the previously created contract and L4-L7 device 5. Apply the service graph template. Select "L3 Destination" and reference L4-L7 Policy-Based Redirect Policy on the provider connector only
  B. 1. Create a contract linked to the common/default filter 2. Create a L4-L7 device, function type "GoThrough" 3. Create a L4-L7 Policy-Based Redirect Policy with the L3 Destination set to the load-balancer inside IP/MAC 4. Create a service graph template that references the previously created contract and L4-L7 device 5. Apply the service graph template. Select "L3 Destination" and reference L4-L7 Policy-Based Redirect Policy on the consumer and provider connector
  C. 1. Create a contract linked to the common/default filter 2. Create a L4-L7 device, function type "GoTo" 3. Create a L4-L7 Policy-Based Redirect Policy with "Anycast Endpoint" enabled and the L3 Destination set to the load-balancer inside IP/MAC 4. Create a service graph template that references the previously created contract and L4-L7 device 5. Apply the service graph template. Select "L3 Destination" and reference L4-L7 Policy-Based Redirect Policy on the consumer connector only
  D. 1. Create a contract with a filter matching "IP" only 2. Create a L4-L7 device, function type "GoThrough" 3. Create a L4-L7 Policy-Based Redirect Policy with "Anycast Endpoint" enabled and the L3 Destination set to the load-balancer inside IP/MAC 4. Create a service graph template that references the previously created contract and L4-L7 device 5. Apply the service graph template. Select "L3 Destination" and reference L4-L7 Policy-Based Redirect Policy on the consumer and provider
  A. 1. Create a contract with a filter matching "IP" only 2. Create a L4-L7 device, function type "GoTo" 3. Create a L4-L7 Policy-Based Redirect Policy with the L3 Destination set to the load-balancer inside IP/MAC 4. Create a service graph template that references the previously created contract and L4-L7 device 5. Apply the service graph template. Select "L3 Destination" and reference L4-L7 Policy-Based Redirect Policy on the provider connector only

• Question 34:

  An engineer deployed a Cisco ACI fabric and noticed that the fabric learns endpoints from subnets that are not configured on a bridge domain. To meet strict security requirements, the engineer must prevent this behavior. Which action must be taken to prevent this behavior?

  A. Activate Enable Data Plane Endpoint Learning
  B. Implement Pervasive Gateway
  C. Configure Static Binding
  D. Enable Enforce Subnet Check
  D. Enable Enforce Subnet Check

• Question 35:

  What is a use of the Overlay Multicast TEP in Cisco ACI Multi-Site communication?

  A. to perform headend replication
  B. to act as the source IP for BUM traffic
  C. to establish MP-BGP adjacencies with remote spines
  D. to send and receive unicast VXLAN data plane traffic
  B. to act as the source IP for BUM traffic

  ---

  https://www.cisco.com/c/en/us/solutions/collateral/data-center-virtualization/application-centric-infrastructure/white-paper-c11-739609.html#CiscoACIMultiSiteoverlaydataplane

• Question 36:

  In a Cisco ACI Multi-Site fabric, the Inter-Site BUM Traffic Allow option is enabled in a specific stretched bridge domain. What is used to forward BUM traffic to all endpoints in the same broadcast domain?

  A. ingress replication on the spines in the source site
  B. egress replication on the source leaf switches
  C. egress replication on the destination leaf switches
  D. ingress replication on the spines in the destination site
  A. ingress replication on the spines in the source site

• Question 37:



  Refer to the exhibit. What must be configured in the service graph to redirect HTTP traffic between the EPG client and EPG server to go through the Cisco ASA firewall?

  A. contract filter to allow ARP and HTTP
  B. precise filter to allow only HTTP traffic
  C. contract with no filter
  D. permit-all contract filter
  B. precise filter to allow only HTTP traffic

• Question 38:

  An engineer is configuring ACI Multi-Pod between two data centers and must plan the physical cabling in the primary data center. How must the Cisco ACI Multi-Pod topology be connected?

  A. Connect spine switch 201 and 202 in pod 1 directly to spine switch 201 and 202 in pod 2.
  B. Connect leaf switch 101 and 102 in pod 1 directly to leaf switch 101 and 102 in pod 2
  C. Connect spine switch 201 and 202 in pod 1 to ports on a device that is providing IP connectivity between pods
  D. Connect leaf switch 101 and 102 in pod 1 to ports on a device that is providing IP connectivity between pods.
  C. Connect spine switch 201 and 202 in pod 1 to ports on a device that is providing IP connectivity between pods

• Question 39:

  An engineer designs a Cisco ACI Multi-Pod solution that requires a pair of active-standby firewalls in different pods for external connectivity. How should the firewalls be implemented?

  A. PBR for routed firewalls
  B. separate L3Out peerings for routed firewalls
  C. routed firewall for the default gateway
  D. transparent firewalls
  B. separate L3Out peerings for routed firewalls

• Question 40:

  Refer to the exhibit.



  Which type of design approach is shown?

  A. traditional VLAN/subnet model
  B. edge-core-edge model
  C. application-centric
  D. network-centric
  C. application-centric
