Cisco 300-320 Online Practice Questions and Exam Preparation

Cisco 300-320 Online Questions & Answers

• Question 91:

  An HSRP design requirement states that preemption must be enabled for the active switch, which is a Cisco 4507R. Assume a boot time of 300 seconds. Which setting of the preemption delay timer minimizes the loss of traffic?

  A. 50 seconds
  B. 100 seconds
  C. 150 seconds
  D. 200 seconds
  D. 200 seconds

  ---

  https://www.cisco.com/c/en/us/td/docs/solutions/Enterprise/Campus/HA_campus_DG/ hacampusdg.html#wp1107923 The recommended best practice is to measure the system boot time, and set the HSRP preempt delay statement to 50 percent greater than this value. This ensures that the HSRP primary distribution node has established full connectivity to all parts of the network before HSRP preemption is allowed to occur"-> We can't choose 450 secondes so we take the higher delay available..

• Question 92:

  Which option must be included in the design when implementing a triangle looped access layer design?

  A. first hop redundancy protocol.
  B. Single uplinks between access and distribution switches.
  C. Layer 2 links between access switches.
  D. Layer 3 links between distribution switches.
  A. first hop redundancy protocol.

  ---

  http://www.cisco.com/c/en/us/td/docs/solutions/Enterprise/Data_Center/DC_Infra2_5/DCInfra_6.html

• Question 93:

  Which router type injects external LSAs into the OSPF database using either other routing protocols or static routes?

  A. backbone router
  B. ABR
  C. internal router
  D. designated router
  E. ASBR
  E. ASBR

• Question 94:

  Which of the following features might be used by the Enterprise Campus network designer as a means of route filtering?

  A. IPv4 static routes
  B. Route tagging using a route map in an ACL
  C. Tagging routes using the BGP MED
  D. EIGRP stub networks
  D. EIGRP stub networks

• Question 95:

  DRAG DROP

  Drag the characteristic on the left to the corresponding IPSec VPN solution on the right.

  Select and Place:





• Question 96:

  An OSPF router should have a maximum of how many adjacent neighbors?

  A. 100
  B. 80
  C. 60
  D. 50
  C. 60

• Question 97:

  An engineer is designing a campus network with dedicated VLANs per access layer switch and wants to ensure that load sharing is supported.

  Which type of distribution to access link must be implemented to accomplish this configuration?

  A. shared
  B. spanned
  C. Layer 3
  D. Layer 2
  A. shared

• Question 98:

  Merging two company network. No subnets overlap, but engineer must limit the networks advertised to new organization. Which feature implements this requirement?

  A. interface ACL
  B. stub area
  C. passive interface
  D. route filtering
  E. route summary
  E. route summary

• Question 99:

  Which option describes why duplicate IP addresses reside on the same network in Cisco network design?

  A. HSRP designed network
  B. using Cisco ACE in active/passive mode
  C. VRRP designed network
  D. running multiple routing protocols
  B. using Cisco ACE in active/passive mode

• Question 100:

  What security feature would require a packet to be received on the interface that the interface would use to forward the return packet?

  A. urpf
  B. arp inspection
  C. vlan acl
  D. ...
  A. urpf
