Cisco 300-115 Online Practice Questions and Exam Preparation

Cisco 300-115 Online Questions & Answers

• Question 971:

  Which option lists the modes that are available for configuring UDLD on a Cisco switch?

  A. normal and aggressive
  B. active and aggressive
  C. normal and active
  D. normal and passive
  E. normal and standby
  A. normal and aggressive

  ---

  The Cisco-proprietary UDLD protocol monitors the physical configuration of the links between devices and ports that support UDLD. UDLD detects the existence of

  unidirectional links. When a unidirectional link is detected, UDLD puts the affected port into the errdisabled state and alerts the user. UDLD can operate in either normal or aggressive mode.

  Reference:

  http://www.cisco.com/en/US/docs/switches/lan/catalyst6500/ios/12.2SX/configuration/guide/udl d.html

• Question 972:

  Drag and Drop

  Select and Place:





• Question 973:

  Which hot standby groups numbers are used in a HSRP token ring?

  A. 0, 1 and 2
  B. 3, 5, and 7
  C. 0 and 1
  D. 2 and 4
  A. 0, 1 and 2

• Question 974:

  If all switches in a network have the same spanning-tree priority, which switch is elected as the root bridge?

  A. the switch with the highest physical interface IP address
  B. the switch with the lowest MAC address
  C. the switch with the lowest loopback interface IP address
  D. the switch with the highest MAC address
  B. the switch with the lowest MAC address

• Question 975:

  Which two control protocols use the native VLAN 1 by default? (Choose two.)

  A. CDP
  B. VTP
  C. NTP
  D. LACP
  E. STP
  A. CDP
  B. VTP

• Question 976:

  Which command enables a RADIUS server configuration to use vendor-proprietary attributes?

  A. radius-server host non-standard
  B. radius-server attribute nas-port extended
  C. radius-server configure-nas
  D. radius-server vsa send authentication
  A. radius-server host non-standard

• Question 977:

  When you configure a private VLAN, which type of port must you configure the gateway router port as?

  A. promiscuous port
  B. isolated port
  C. community port
  D. access port
  A. promiscuous port

  ---

  There are mainly two types of ports in a Private VLAN: Promiscuous port (P-Port) and Host port. Host port further divides in two types Isolated port (I-Port) and Community port (C-port). Promiscuous port (P-Port):

  The switch port connects to a router, firewall or other common gateway device. This port can communicate with anything else connected to the primary or any secondary VLAN. In other words, it is a type of a port that is allowed to send and

  receive frames from any other port on the VLAN.

  Host Ports:

  o Isolated Port (I-Port): Connects to the regular host that resides on isolated VLAN. This port communicates only with P-Ports. o Community Port (C-Port): Connects to the regular host that resides on community VLAN. This port communicates with P-Ports and ports on the same community VLAN. Reference: http://en.wikipedia.org/ wiki/Private_VLAN

• Question 978:

  What happens on a Cisco switch that runs Cisco IOS when an RSTP-configured switch receives 802.1d BPDU?

  A. 802.1d does not understand RSTP BPDUs because they are different versions, but when a RSTP switch receives an 802.1d BPDU, it responds with an 802.1d BPDU and eventually the two switches run 802.1d to communicate.
  B. 802.1d understands RSTP BPDUs because they are the same version, but when a RSTP switch receives a 802.1d BPDU, it responds with a 802.1d BPDU and eventually the two switches run 802.1d to communicate.
  C. 802.1d does not understand RSTP BPDUs because they are different versions, but when a RSTP switch receives a 802.1d BPDU, it does not respond with a 802.1d BPDU.
  D. 802.1d understands RSTP BPDUs because they are the same version, but when a RSTP switch receives a 802.1d BPDU, it does not respond with a 802.1d BPDU and eventually the two switches run 802.1d to communicate.
  A. 802.1d does not understand RSTP BPDUs because they are different versions, but when a RSTP switch receives an 802.1d BPDU, it responds with an 802.1d BPDU and eventually the two switches run 802.1d to communicate.

  ---

  For backward compatibility with 802.1D switches, RSTP selectively sends 802.1D configuration BPDUs and TCN BPDUs on a per-port basis. When a port is initialized, the migrate-delay timer is started (specifies the minimum time during which RSTP BPDUs are sent), and RSTP BPDUs are sent. While this timer is active, the switch processes all BPDUs received on that port and ignores the protocol type. If the switch receives an 802.1D BPDU after the port migration-delay timer has expired, it assumes that it is connected to an 802.1D switch and starts using only 802.1D BPDUs. However, if the RSTP switch is using 802.1D BPDUs on a port and receives an RSTP BPDU after the timer has expired, it restarts the timer and starts using RSTP BPDUs on that port. Reference: http:// www.cisco.com/c/en/us/td/ docs/switches/lan/catalyst6500/ios/12- 2SX/configuration/guide/book/spantree.html https://www.CertBus.com/300-115.html

• Question 979:

  In a switch stack is configured to use SDM template,where are the templates stored?

  A. all stack members
  B. stack master
  C. flash memory
  D. TFTP server
  B. stack master

• Question 980:

  A question in regards to RSPAN

  A. vlan 510 remote span
  B. vlan 4029 remote span
  C. vlan 4029 span
  D. vlan 510 span
  A. vlan 510 remote span
