• Question 201:

  An engineer is configuring URI calling within the same cluster. Which four actions must be taken to accomplish this configuration? (Choose four.)

  A. Configure SIP route patterns.
  B. Configure the directory URI partition and calling search space.
  C. Associate the directory URIs to directory numbers.
  D. Activate the URI service in Cisco Unified Serviceability.
  E. Configure SIP trunk.
  F. Assign directory URIs to users.
  G. Configure the SIP profile.
  H. Configure the URI service parameters.
  B. Configure the directory URI partition and calling search space.
  C. Associate the directory URIs to directory numbers.
  F. Assign directory URIs to users.
  G. Configure the SIP profile.

• Question 202:

  How is a SIP trunk in Cisco Unified Communications Manager configured for SIP precondition?

  A. The configuration is done by selecting a SIP precondition trunk for trunk type.
  B. The configuration is automatically selected when RSVP is enabled for the location assigned to the trunk.
  C. SIP precondition is configured by selecting E2E for RSVP over SIP on the default SIP profile assigned to the SIP trunk.
  D. SIP precondition is configured by configuring a new SIP profile and selecting E2E for RSVP over SIP. The new SIP profile must then be assigned to the SIP trunk.
  D. SIP precondition is configured by configuring a new SIP profile and selecting E2E for RSVP over SIP. The new SIP profile must then be assigned to the SIP trunk.

• Question 203:

  Which two functions can be implemented without MTP resources? (Choose two.)

  A. h.323 fast start
  B. IPV6-IPV4 transform
  C. DTMF inband RTP-NTE (rfc2833)
  D. SIP delay offer
  E. Multicast MOH
  D. SIP delay offer
  E. Multicast MOH

• Question 204:

  What command is used to map internal extensions to the corresponding E.164 PSTN number when using Cisco Unified Communications Manager Express in SRST mode?

  A. ephone-dn
  B. dialplan-pattern
  C. number
  D. number-e.164
  E. ephone-transnumber
  B. dialplan-pattern

• Question 205:

  What component acts as a user agent for both ends of a SIP call while Cisco Unified SIP SRST is providing failover during a WAN outage?

  A. B2BUA
  B. SIP server
  C. SIP proxy
  D. SIP SRST router
  E. SIP registrar
  A. B2BUA

• Question 206:

  Which two locations are the best locations that an end user can use to determine if an IP phone is working in SRST mode? (Choose two.)

  A. Cisco Unified Communications Manager Administration
  B. IP phone display
  C. Cisco Unified SRST Router
  D. Cisco Unified MGCP Fallback Router
  E. physical IP phone settings
  B. IP phone display
  E. physical IP phone settings

• Question 207:

  Refer to the exhibit.



  With the Mobile Connect feature configured, when the PSTN phone calls the Enterprise user at extension 3001, the Enterprise user's mobile phone does not ring. Which CSS is responsible for ensuring that the correct partitions are accessed when calls are sent to the Enterprise user's mobile phone?

  A. the gateway CSS
  B. the Phone Device CSS
  C. the Remote Destination Profile CSS
  D. the Remote Destination Profile Rerouting CSS
  E. the Phone Line (DN)CSS
  D. the Remote Destination Profile Rerouting CSS

• Question 208:

  When using SAF, how do you prevent multiple nodes in a cluster from showing up in the Show Advance section of the SAF Forwarder configuration?

  A. Configure the publisher node only in the SAF Forwarder configuration page.
  B. Append an @ symbol at the end of the client label value in the SAF Forwarder configuration page.
  C. Configure the correct node in the EIGRP configuration of the gateway router that is associated with the Cisco Unified Communications Manager node.
  D. Configure the SAF Security Profile Configuration to support only a single node.
  B. Append an @ symbol at the end of the client label value in the SAF Forwarder configuration page.

• Question 209:

  Which two steps must you take when implementing TEHO in your environment? (Choose two.)

  A. Implement local failover.
  B. Implement SIP to POTS.
  C. Load-balance PRI connections.
  D. Load-balance route lists within the cluster.
  E. Implement ICT trunks to remote locations.
  F. Implement centralized failover.
  A. Implement local failover.
  F. Implement centralized failover.

• Question 210:

  An engineer is configuring a new DX-80 in Cisco Unified Communications Manager. Where can an engineer verify the default DSCP value of AF41?

  A. enterprise phone configuration
  B. common phone profile
  C. service parameters
  D. enterprise parameters
  C. service parameters
