VMware 2V0-21.23 Online Practice Questions and Exam Preparation

VMware 2V0-21.23 Online Questions & Answers

• Question 1:

  An administrator creates a virtual machine that contains the latest company-approved software, tools and security updates. Company policy requires that only full clones are allowed for server workloads.

  A combination of which two tasks should the administrator complete to prepare for the deployment of this virtual machine for multiple users? (Choose two.)

  A. Set appropriate permissions on the virtual machine.
  B. Create a virtual machine customization specification.
  C. Upgrade the virtual hardware.
  D. Convert the virtual machine to a template.
  E. Take a snapshot of the virtual machine.
  B. Create a virtual machine customization specification.
  D. Convert the virtual machine to a template.

  ---

  explanation:

  Explanation/Reference:

  Option B and D are correct because they allow the administrator to create a virtual machine customization specification, which can be used to customize guest operating system settings for multiple virtual machines, and convert the virtual machine to a template, which can be used to create full clones of server workloads. Option A is incorrect because assigning appropriate permissions on the virtual machine does not prepare it for deployment for multiple users. Option C is incorrect because upgrading the virtual hardware does not prepare it for deployment for multiple users. Option E is incorrect because taking a snapshot of the virtual machine does not prepare it for deployment for multiple users. References: https://docs.vmware.com/en/VMware- vSphere/7.0/com.vmware.vsphere.vm_admin.doc/GUID-9F9E3F8C-0E2B-4B6A-8C5C- 3F8E5F6B4E9D.html

• Question 2:

  Which step is completed during Stage 1 of the vCenter Server Appliance deployment?

  A. Join a vCenter Single Sign-On domain
  B. Create a new vCenter Single Sign-On domain
  C. Select the deployment size
  D. Configure SSH access
  C. Select the deployment size

  ---

  explanation:

  Explanation/Reference:

  The minimum network throughput in Gb/s for vSAN using the Express Storage Architecture (ESA) is 1 Gb/s, which is the minimum requirement for vSAN network adapters. However, VMware recommends using 10 Gb/s or higher for better performance and reliability. References: https://docs.vmware.com/en/VMware- vSphere/8.0/com.vmware.vsphere.vsan-planning.doc/GUID-9F1D4A3B-3392-4684-812C- DB8042C1FBCD.html https://docs.vmware.com/en/VMware-vSphere/7.0/com.vmware.vcenter.install.doc/GUID- 1E39EF05-1DD7-4E9B-B9FE-6F373AA81862.html https://docs.vmware.com/en/VMware-vSphere/7.0/com.vmware.vcenter.install.doc/GUID- 1E39EF05-1DD7-4E9B-B9FE-6F373AA81862.html

• Question 3:

  An administrator is deploying a new all flash vSAN cluster based on the vSAN Original Storage Architecture (OSA).

  What is the minimum supported network throughput in Gb/s for each host?

  A. 50
  B. 10
  C. 25
  D. 1
  B. 10

  ---

  explanation:

  Explanation/Reference:

  The minimum supported network throughput in Gb/s for each host in an all flash vSAN cluster based on the vSAN Original Storage Architecture (OSA) is 10. References: https://docs.vmware.com/en/VMware-vSphere/7.0/com.vmware.vsphere.vsan- planning.doc/GUID-FCEA0CDD-F40F-45EB-A27F-F24005BA0749.html

  vSAN Express Storage Architecture (ESA) are only supported with 25Gbps and higher connection speeds. ESA ReadyNodes configured for vSAN ESA will be configured with 25/50/100Gbps NICs. vSAN OSA all-flash configurations are only supported with a 10Gb or higher connections. One reason for this is that the improved performance with an all-flash configuration may consume more network bandwidth between the hosts to gain higher throughput. https://core.vmware.com/resource/vmware-vsan-design-guide#sec6815-sub3

• Question 4:

  A VMkernel port is labelled PROD01 and uses the default TCP/IP stack. Currently, this VMkernel port is configured for supporting live virtual machine (VM) migrations.

  Which configuration change should the administrator make to isolate live VM migration traffic from other network traffic?

  A. Remove PROD01 and create a new VMkernel port and set the TCP/IP stack to vSphere vMotion.
  B. Remove PROD01 and create a new VMkernel port with the TCP/IP stack set to provisioning.
  C. Create a new VMkernel port and set the TCP/IP stack to provisioning.
  D. Modify PROD01 by changing the TCP/IP stack to vSphere vMotion.
  A. Remove PROD01 and create a new VMkernel port and set the TCP/IP stack to vSphere vMotion.

  ---

  explanation:

  Explanation/Reference:

  Select a TCP/IP stack from the list. Once you set a TCP/IP stack for the VMkernel adapter, you cannot change it later. If you select the vMotion or the Provisioning TCP/IP stack, you will be able to use only these stacks to handle vMotion or Provisioning traffic on the host. All VMkernel adapters for vMotion on the default TCP/IP stack are disabled for future vMotion sessions. If you set the Provisioning TCP/IP stack, VMkernel adapters on the default TCP/IP stack are disabled for operations that include Provisioning traffic, such as virtual machine cold migration, cloning, and snapshot migration.

  https://docs.vmware.com/en/VMware-vSphere/8.0/vsphere-networking/GUID-AA3656B0- 005A-40A0-A293-4309C5ACF682.html

• Question 5:

  What is the minimum network throughput in Gb/s for vSAN using the Express Storage Architecture (ESA)?

  A. 50
  B. 25
  C. 1
  D. 10
  D. 10

  ---

  explanation:

  Explanation/Reference:

  https://core.vmware.com/resource/vmware-vsan-design- guide#:~:text=Summary%20of%20Network%20Design%20Considerations,are%20recomm ended%20for%20best%20performance.

• Question 6:

  A vSphere cluster hosts a three-tier application. The cluster has 50% resources available. If a host in the cluster fails, the database server must be online before the application server, and the application server must be online before the Web server.

  Which feature can be used to meet these requirements?

  A. Predictive DRS
  B. vSphere HA Orchestrated Restart
  C. vSphere HA Restart Priority
  D. Proactive HA
  B. vSphere HA Orchestrated Restart

  ---

  explanation:

  Explanation/Reference:

  https://www.vladan.fr/what-is-vmware-orchestrated-restart/

• Question 7:

  An administrator is investigating reports of users experiencing difficulties logging into a VMware vCenter instance using LDAP accounts. Which service should the administrator check as part of troubleshooting?

  A. vSphere Authentication Proxy Service
  B. Lookup Service
  C. Identity Management Service
  D. VMware Authentication Framework Daemon
  C. Identity Management Service

  ---

  explanation:

  Explanation/Reference:

  Identity Management Service is the service that handles authentication requests from LDAP accounts and other identity sources in vCenter Server. References: https://docs.vmware.com/en/VMware-vSphere/7.0/com.vmware.vcenter.install.doc/GUID-FE1D5F2E-E3AC-4DCC-BFB8- D2DD31FF9DCF.html

• Question 8:

  An administrator is tasked with configuring certificates for a VMware software-defined data center (SDDC) based on the following requirements:

  All certificates should use certificates trusted by the Enterprise Certificate Authority (CA).

  The solution should minimize the ongoing management overhead of replacing certificates.

  Which three actions should the administrator take to ensure that the solution meets corporate policy? (Choose three.)

  A. Replace the VMware Certificate Authority (VMCA) certificate with a self-signed certificate generated from the
  B. Replace the machine SSL certificates with custom certificates generated from the Enterprise CA.
  C. Replace the machine SSL certificates with trusted certificates generated from the VMware Certificate Authority (VMCA).
  D. Replace the VMware Certificate Authority (VMCA) certificate with a custom certificate generated from the Enterprise CA.
  E. Replace the solution user certificates wife custom certificates generated from the Enterprise CA.
  F. Replace the solution user certificates with trusted certificates generated from the VMware Certificate Authority (VMCA).
  B. Replace the machine SSL certificates with custom certificates generated from the Enterprise CA.
  D. Replace the VMware Certificate Authority (VMCA) certificate with a custom certificate generated from the Enterprise CA.
  E. Replace the solution user certificates wife custom certificates generated from the Enterprise CA.

  ---

  explanation:

  Explanation/Reference:

  Option B, D and E are correct because they allow the administrator to replace the machine SSL certificates, the VMware Certificate Authority (VMCA) certificate and the solution user certificates with custom certificates generated

  from the Enterprise CA, which will ensure that all certificates are trusted by the Enterprise CA and minimize the ongoing management overhead of replacing certificates. Option A is incorrect because replacing the VMCA certificate with a self-

  signed certificate generated from the VMCA will not ensure that the certificate is trusted by the Enterprise CA. Option C is incorrect because replacing the machine SSL certificates with trusted certificates generated from the VMCA will not

  ensure that the certificates are trusted by the Enterprise CA. Option F is incorrect because replacing the solution user certificates with trusted certificates generated from the VMCA will not ensure that the certificates are trusted by the

  Enterprise CA.

  References:

  https://docs.vmware.com/en/VMware-vSphere/7.0/com.vmware.vsphere.security.doc/GUID-A2A4371A-B888-404C-B23F- C422A8C40F54.html

• Question 9:

  An administrator is working with VMware Support and Is asked to provide log bundles for the ESXI hosts in an environment. Which three options Joes the administrator have? (Choose three.)

  A. Generate a combined log bundle for all ESXI hosts using the vCenter Management Interface.
  B. Generate a separate log bundle for each ESXI host using the vSphere Host Client.
  C. Generate a combined log bundle for all ESXI hosts using the vSphere Client.
  D. Generate a separate log bundle for each ESXI host using the vSphere Client.
  E. Generate a separate log bundle for each ESXI host using the vCenter Management Interface.
  F. Generate a combined log bundle for all ESXi hosts using the vSphere Host Client.
  B. Generate a separate log bundle for each ESXI host using the vSphere Host Client.
  C. Generate a combined log bundle for all ESXI hosts using the vSphere Client.
  D. Generate a separate log bundle for each ESXI host using the vSphere Client.

  ---

  explanation:

  Explanation/Reference:

  Option B, C and D are correct because they are valid methods to generate log bundles for individual or multiple ESXi hosts using different interfaces. Option A and E are incorrect because they are not possible options to generate log bundles for all ESXi hosts using the vCenter Management Interface. Option F is incorrect because it is not possible to generate a combined log bundle for all ESXi hosts using the vSphere Host Client.

  References: https://docs.vmware.com/en/VMware- vSphere/7.0/com.vmware.vsphere.troubleshooting.doc/GUID-9A94C3D1-38A4-4A5F- AFE7-8CDBE8D6D988.html

• Question 10:

  What is the role of vSphere Distributed Services Engine?

  A. Provide a live shadow Instance of a virtual machine (VM) that mirror, the primary VM to prevent data loss and downtime during outages
  B. Implement Quality of Service (QoS) on network traffic within a vSphere Distributed Switch
  C. Provide hardware accelerated data processing to boor.t infrastructure performance
  D. Redistribute virtual machines across vSphere cluster host affinity rules following host failures or during maintenance operations
  C. Provide hardware accelerated data processing to boor.t infrastructure performance

  ---

  explanation:

  Explanation/Reference:

  The role of vSphere Distributed Services Engine is to provide hardware accelerated data processing to boost infrastructure performance by offloading network services from the CPU to the DPU. References: https://core.vmware.com/resource/whats-new-vsphere-8
