Cisco 210-065 Online Practice Questions and Exam Preparation

Cisco 210-065 Online Questions & Answers

• Question 51:

  Refer to the exhibit.



  A network engineer configures a Cisco Unified Communications Manager and VCS integration via a SIP trunk. Endpoint A is able to conduct video calls to Endpoint B. When Endpoint A attempts to share presentation content with Endpoint B, Endpoint B sees the presentation video on the main screen rather than on the presentation display. What is the cause?

  A. The default MTP telephony payload is incorrect.
  B. The SIP trunk is not running on all active Cisco Unified Communications Manager nodes.
  C. MTP is not forced to be required.
  D. BFCP is not enabled.
  E. The MTP preferred codec is incorrect for content presentation.
  D. BFCP is not enabled.

• Question 52:

  An engineer is switching layout views using a Cisco Video-Surveillance Solution. Which component determines which layout and cameras are used?

  A. Operations Manager
  B. Virtual Matrix
  C. Integrated Services Router
  D. Media Server
  B. Virtual Matrix

• Question 53:

  A Cisco SX20 is registered to Cisco Unified Communications Manager. It cannot place calls. It is configured with SIP URI 1007 and when traces are run, SIP Forbidden and Unknown calling DN errors are found. Which statement describes the problem?

  A. The wrong network IP address is assigned to device.
  B. The ACL is blocking port 5060 from device.
  C. H.323 is not configured correctly.
  D. SIP URI does not contain IP address or hostname.
  D. SIP URI does not contain IP address or hostname.

• Question 54:

  A network engineer must install a video conferencing solution that needs TIP protocol for multiscreen setups. Which product enables TIP support via API?

  A. MCU 3515
  B. Cisco Meeting Server
  C. UCS Server
  D. Cisco TPs
  B. Cisco Meeting Server

• Question 55:

  Which two methods can be used to set the default call protocol of a Cisco TelePresence endpoint running TelePresence codec firmware? (Choose two.)

  A. Use the GUI and set System > H.323 > Settings > Default Call Protocol > H.323.
  B. Use the CLI command xConfiguration Conference 1 DefaultCall Protocol: H323.
  C. Use the CLI command Conference Default Protocol: H323.
  D. Use the CLI command Default Protocol: H323.
  E. Use the GUI and set Configuration > System Configuration > Conference > DefaultCall > H.323.
  B. Use the CLI command xConfiguration Conference 1 DefaultCall Protocol: H323.
  E. Use the GUI and set Configuration > System Configuration > Conference > DefaultCall > H.323.

• Question 56:

  A Cisco TMS application has failed completely and shows several errors. Movi is in use. The engineer wants to perform a clean installation/restoration. Which two elements are required? (Choose two.)

  A. TMS OS backup
  B. TMSNG SQL database backup
  C. TMS SQL server credentials
  D. TMS IIS credentials
  E. TMS IIS configuration settings
  C. TMS SQL server credentials
  D. TMS IIS credentials

• Question 57:

  Refer to the exhibit.



  You have just finished installing a 65-inch dual profile system in a multipurpose room. After powering up the entire system, only one display is used. Using the information in the exhibit, why is the second display not displaying anything from the system?

  A. The Cisco TelePresence profile systems do not support dual display.
  B. The display is not powered on.
  C. The dual display option key has not been input into the codec.
  D. The codec has the appropriate option keys installed, so either the display is not cabled correctly, the codec is configured incorrectly, or there is no input being sent to the display.
  D. The codec has the appropriate option keys installed, so either the display is not cabled correctly, the codec is configured incorrectly, or there is no input being sent to the display.

• Question 58:

  Which encoder is best suited for professional, studio-quality audio and video processing?

  A. Scientific Atlanta Encoder
  B. Cisco Digital Media Encoder 1000
  C. Cisco Digital Media Encoder 2000
  D. Cisco Digital Media Encoder 3000
  C. Cisco Digital Media Encoder 2000

• Question 59:

  An engineer is using a cascading feature with Cisco TelePresence Conductor and Cisco TelePresence Servers. Which two limitations will the engineer likely encounter? (Choose two.)

  A. Ad-hoc conferencing cascading is not supported.
  B. Only single-screen endpoints are supported through cascading links.
  C. Multiple-screen endpoints are supported only with three or more Cisco TelePresence Servers.
  D. Scheduled conferencing is not supported.
  E. Ad-hoc conferencing cascading is supported only with three or more Cisco TelePresence Servers.
  A. Ad-hoc conferencing cascading is not supported.
  D. Scheduled conferencing is not supported.

• Question 60:

  An engineer sees a video camera icon on the Cisco IP phone screen status line. Which meaning of this icon is true?

  A. The Cisco VT camera is connected to the PC, and the PC is connected to the Cisco IP phone.
  B. The Cisco IP phone has web access.
  C. The Cisco IP phone is receiving a video call.
  D. The Cisco IP phone is configured with video capabilities.
  D. The Cisco IP phone is configured with video capabilities.
