F5 201 Online Practice Questions and Exam Preparation

F5 201 Online Questions & Answers

• Question 51:

  You have a pool of servers that need to be tested. All of the servers but one should be tested every 10 seconds, but one is slower and should only be tested every 20 seconds. How do you proceed?

  A. It cannot be done. All monitors test every five seconds.
  B. It can be done, but will require assigning monitors to each pool member.
  C. It cannot be done. All of the members of a pool must be tested at the same frequency.
  D. It can be done by assigning one monitor to the pool and a different monitor to the slower pool member.
  D. It can be done by assigning one monitor to the pool and a different monitor to the slower pool member.

• Question 52:

  What should the BIG-IP Administrator do to apply and activate a hotfix to a BIG-IP device that is currently running version 11.0.0 on active partition HD1.1?

  A. 1. confirm that 11.0.0 is installed on inactive partition HD1.2 2. apply a hotfix to partition HD 1.2 3. activate partition HD1.2
  B. 1. reactivate the license on partition HD1.1 2. apply a hotfix to partition HD1.1
  C. 1. activate partition HD1.2 2 confirm version 11.0.0 on partition HD1.2 3. install a hotfix on partition HD1.2
  D. 1. set partition HD1.2 active 2. apply a hotfix to partition HD1.2
  A. 1. confirm that 11.0.0 is installed on inactive partition HD1.2 2. apply a hotfix to partition HD 1.2 3. activate partition HD1.2

• Question 53:

  A custom HTTP monitor is failing to a pool member 10.10.3.75:8080 that serves up www.example.com.

  A ping works to the pool member address.

  The SEND string that the monitor is using is:

  GET/HTTP/l.l/r/n/Host.www.example.com/r/n/Connection

  Close/r/n/r/n

  Which CLI tool syntax will show that the web server returns the correct HTTP response?

  A. curlhttp://10.10.10.3.75:8080/www.example.com/index.html
  B. curl-header 'Host:www.example.com' http://10.10.3.75:8080/
  C. tracepath 'http://www.example.com:80
  D. tracepath 10.10.3.75:8080 GET /index
  B. curl-header 'Host:www.example.com' http://10.10.3.75:8080/

• Question 54:

  When can a single virtual server be associated with multiple profiles?

  A. Never. Each virtual server has a maximum of one profile.
  B. Often. Profiles work on different layers and combining profiles is common.
  C. Rarely. One combination, using both the TCP and HTTP profile does occur, but it is the exception.
  D. Unlimited. Profiles can work together in any combination to ensure that all traffic types are supported in a given virtual server.
  B. Often. Profiles work on different layers and combining profiles is common.

• Question 55:

  Which process or system can be monitored by the BIG-IP system and used as a failover trigger in a redundant pair configuration?

  A. bandwidth utilization
  B. duplicate IP address
  C. CPU utilization percentage
  D. VLAN communication ability
  D. VLAN communication ability

• Question 56:

  When using the setup utility to configure a redundant pair, you are asked to provide a "Failover Peer IP". Which address is this?

  A. an address of the other system in its management network
  B. an address of the other system in a redundant pair configuration
  C. an address on the current system used to listen for failover messages from the partner BIG-IP
  D. an address on the current system used to initiate mirroring and network failover heartbeat messages
  B. an address of the other system in a redundant pair configuration

• Question 57:

  You have created a custom profile named TEST2. The parent profile of TEST2 is named TEST1. If additional changes are made to TEST1, what is the effect on TEST2?

  A. All changes to TEST1 are propagated to TEST2.
  B. Some of the changes to TEST1 may propagate to TEST2.
  C. Changes to TEST1 cannot affect TEST2 once TEST2 is saved.
  D. When TEST1 is changed, the administrator is prompted and can choose whether to propagate changes to TEST2.
  B. Some of the changes to TEST1 may propagate to TEST2.

• Question 58:

  Assuming there are open connections through an active system's NAT and a fail over occurs, by default, what happens to those connections?



  A. All open connections will be lost.
  B. All open connections will be maintained.
  C. The "Mirror" option must be chosen on the NAT and the setting synchronized prior to the connection establishment.
  D. Longlived connections such as Telnet and FTP will be maintained while shortlived connections such as HTTP will be lost.
  E. All open connections are lost, but new connections are initiated by the newly active BIG IP, resulting in minimal client downtime.
  B. All open connections will be maintained.

• Question 59:

  A BIGJP Administrator needs to load a UCS file but must exclude the license file. How should the administrator perform this task?

  A. From the CLI with command U tmsh load /$ys ucs no-license
  B. From the GUI, select the UCS file, unchcck the license box, and click restore
  C. From the CLI with command(tmos)?tmsh load /sys ucs; no-license
  D. From the GUI, select the UCS file and click restore
  A. From the CLI with command U tmsh load /$ys ucs no-license

• Question 60:

  The BIG-IP Administrator needs to avoid overloading any of the Pool Members with connections, when they become active. What should the BIG-IP Administrator configure to meet this requirement?

  A. Different Ratio for each member
  B. Same Priority Group to each member
  C. Action On Service Down to Reselect
  D. Slow Ramp Time to the Pool
  D. Slow Ramp Time to the Pool
