F5 201 Online Practice Questions and Exam Preparation

F5 201 Online Questions & Answers

• Question 131:

  Refer to the exhibit.



  A pool member fails the monitor checks for about 30 minutes and then starts passing the monitor checks. New traffic is Not being sent to the pool member. What is the likely reason for this problem?

  A. The pool member is disabled
  B. Monitor Type is TCP Half Open
  C. Manual resume is enabled
  D. Time Until Up is zero
  C. Manual resume is enabled

• Question 132:

  The ICMP monitor has been assigned to all nodes. In addition, all pools have been assigned custom monitors. The pool is marked available. If a pool is marked available (green) which situation is sufficient to cause this?

  A. All of the pool member nodes are responding to the ICMP monitor as expected.
  B. Less than 50% of the pool member nodes responded to the ICMP echo request.
  C. All of the members of the pool have had their content updated recently and their responses no longer match the monitor.
  D. Over 25% of the pool members have had their content updated and it no longer matches the receive rule of the custom monitor. The other respond as expected.
  D. Over 25% of the pool members have had their content updated and it no longer matches the receive rule of the custom monitor. The other respond as expected.

• Question 133:

  A BIG-IP Administrator adds new Pool Members into an existing, highly utilized pool. Soon after, there are reports that the application is failing to load for some users. What pool level setting should the BIG-IP Administrator check?

  A. Availability Requirement
  B. Allow SNAT
  C. Action On Service Down
  D. Slow Ramp Time
  D. Slow Ramp Time

• Question 134:

  A 8IG-IP device is replaced with an RMA device. The BIG-IP Administrator renews the license and tries to restore the configuration from a previously generated UCS archive on the RMA device. The device configuration is NOT fully loading. What is causing the configuration load to fail?

  A. The Device Group is NOT configured for Full Sync.
  B. The US does NOT contain the full config
  C. The clock is NOT set correctly
  D. The Master Key is NOT restored
  D. The Master Key is NOT restored

• Question 135:

  A virtual server is listening at 10.10.1.100:80 and has the following iRule associated with it:

  when HTTP_REQUEST { if { [HTTP::header UserAgent] contains "MSIE" }

  { pool MSIE_pool }

  else { pool Mozilla_pool }

  If a user connects to http://10.10.1.100/foo.html and their browser does not specify a UserAgent, which pool will receive the request?

  A. MSIE_pool
  B. Mozilla_pool
  C. None. The request will be dropped.
  D. Unknown. The pool cannot be determined from the information provided.
  B. Mozilla_pool

• Question 136:

  During a high-demand traffic event, the BIG-IP Administrator needs to limit the number of new connections per second allowed to a Virtual Server. What should the administrator apply to accomplish this task?

  A. An HTTP Compression profile to the Virtual Server
  B. A connection rate limit to the Virtual Server
  C. A connection limit to the Virtual Server
  D. A OneConnect profile to the Virtual Server
  B. A connection rate limit to the Virtual Server

• Question 137:

  Administrative user accounts have been defined on the remote LDAP server and are unable to log in to the BIG-IP device. Which log file should the BIG-IP Administrator check to find the related messages?

  A. /var/log/secure
  B. /var/log/messages
  C. /Nar/log/ltm
  D. /var/log/user.log
  A. /var/log/secure

• Question 138:

  In the BIG-IP Configuration Utility, a user requests a single screen view to determine the status of all Virtual Servers and associated pool members, as well as any iRules in use. Where should the BIG-IP Administrator instruct the user to find this view?

  A. Local Traffic > Monitors
  B. Local Traffic > Virtual Servers
  C. Local Traffic > Network Map
  D. Statistics
  C. Local Traffic > Network Map

• Question 139:

  Assume the bigd daemon fails on the active system. Which three are possible results? (Choose three.)

  A. The active system will restart the bigd daemon and continue in active mode.
  B. The active system will restart the tmm daemon and continue in active mode.
  C. The active system will reboot and the standby system will go into active mode.
  D. The active system will failover and the standby system will go into active mode.
  E. The active system will continue in active mode but gather member and node state information from the standby system.
  A. The active system will restart the bigd daemon and continue in active mode.
  C. The active system will reboot and the standby system will go into active mode.
  D. The active system will failover and the standby system will go into active mode.

• Question 140:

  A BIG-IP Administrator creates an HTTP Virtual Server using an iApp template. After the Virtual Server is created, the user requests to change the destination IP addresses. The BIG-IP Administrator tries to change the destination IP address

  from 10.1.1.1 to 10.2.1.1 in Virtual Server settings, but receives the following error:

  The application service must be updated using an application management interface.

  What is causing this error?

  A. The Application Service was NOT deleted before making the IP address change.
  B. The IP addresses are already in use.
  C. The Application Services have Strict Updates enabled.
  D. The IP addresses used are NOT from the same subnet as the Self IP.
  C. The Application Services have Strict Updates enabled.
