Cisco 200-125 Online Practice Questions and Exam Preparation

Cisco 200-125 Online Questions & Answers

• Question 761:

  Which command should you enter to view the error log in an EIGRP for IPv6 environment?

  A. show ipv6 eigrp traffic
  B. show ipv6 eigrp topology
  C. show ipv6 eigrp events
  D. show ipv6 eigrp neighbors
  C. show ipv6 eigrp events

• Question 762:

  Which statement about EIGRP on IPv6 device is true?

  A. It is configured directly on the interface
  B. the configuration uses secondary ip address
  C. the neighbors of each deice are directly configured
  D. the configuration uses process numbers
  A. It is configured directly on the interface

  ---

  Explanation: http://www.cisco.com/c/en/us/support/docs/ip/enhanced-interior-gateway-routing-protocol- eigrp/113267-eigrp-ipv6-00.html

• Question 763:

  Which set of commands is recommended to prevent the use of a hub in the access layer?

  A. switch(config-if)#switchport mode trunk switch(config-if)#switchport port-security maximum 1
  B. switch(config-if)#switchport mode trunk switch(config-if)#switchport port-security mac-address 1
  C. switch(config-if)#switchport mode access switch(config-if)#switchport port-security maximum 1
  D. switch(config-if)#switchport mode access switch(config-if)#switchport port-security mac-address 1
  C. switch(config-if)#switchport mode access switch(config-if)#switchport port-security maximum 1

  ---

  This question is to examine the layer 2 security configuration. In order to satisfy the requirements of this question, you should perform the following configurations in the interface mode: First, configure the interface mode as the access mode Second, enable the port security and set the maximum number of connections to 1.

• Question 764:

  Which part of the PPPoE server configuration contains the information used to assign an IP address to a PPPoE client?

  A. virtual-template interface
  B. DHCP
  C. dialer interface
  D. AAA authentication
  A. virtual-template interface

• Question 765:

  Which command allows you to set the administrative distance for EIGRP for IPv6?

  A. metric weights
  B. ipv6 summary-address eigrp
  C. ipv6 next-hop-self eigrp
  D. ipv6 bandwidth-percent eigrp
  B. ipv6 summary-address eigrp

• Question 766:

  Which two statements about eBGP neighbor relationships are true? (Choose two)

  A. The two devices must reside in different autonomous systems
  B. Neighbors must be specifically declared in the configuration of each device
  C. They can be created dynamically after the network statement is configured.
  D. The two devices must reside in the same autonomous system
  E. The two devices must have matching timer settings
  A. The two devices must reside in different autonomous systems
  B. Neighbors must be specifically declared in the configuration of each device

• Question 767:

  Which two VLANs are reserved for system use only? (Choose two.)

  A. 2
  B. 4095
  C. 1001
  D. 4096
  E. 1
  B. 4095

• Question 768:

  Which command should you enter to configure a single port to bypass the spanning-tree Forward and Delay timers?

  A. spanning-tree portfast bpdufiter default
  B. spanning-tree portfast default
  C. spanning-tree portfast
  D. spanning-tree portfast bpduguard default
  C. spanning-tree portfast

• Question 769:

  Which three statements about VTP features are true? (Choose three.)

  A. VTP works at Layer 3 of the OSI model and requires that a management VLAN IP address be configured.
  B. When properly configured, VTP minimizes VLAN misconfigurations and configuration inconsistencies.
  C. When properly configured, VTP maintains VLAN configuration consistency and accelerates trunk link negotiation.
  D. Each broadcast domain on a switch can have its own unique VTP domain.
  E. VTP pruning is used to increase available bandwidth in trunk links.
  F. To configure a switch to be part of two VTP domains, each domain must have its own passwords.
  G. Client, server, and transparent are valid VTP modes.
  B. When properly configured, VTP minimizes VLAN misconfigurations and configuration inconsistencies.
  E. VTP pruning is used to increase available bandwidth in trunk links.
  G. Client, server, and transparent are valid VTP modes.

• Question 770:

  Refer to the exhibit.



  The Lakeside Company has the internetwork in the exhibit. The administrator would like to reduce the size of the routing table on the Central router. Which partial routing table entry in the Central router represents a route summary that represents the LANs in Phoenix but no additional subnets?

  A. 10.0.0.0/22 is subnetted, 1 subnets D 10.0.0.0 [90/20514560] via 10.2.0.2, 6w0d, Serial0/1
  B. 10.0.0.0/28 is subnetted, 1 subnets D 10.2.0.0 [90/20514560] via 10.2.0.2, 6w0d, Serial0/1
  C. 10.0.0.0/30 is subnetted, 1 subnets D 10.2.2.0 [90/20514560] via 10.2.0.2, 6w0d, Serial0/1
  D. 10.0.0.0/22 is subnetted, 1 subnets D 10.4.0.0 [90/20514560] via 10.2.0.2, 6w0d, Serial0/1
  E. 10.0.0.0/28 is subnetted, 1 subnets D 10.4.4.0 [90/20514560] via 10.2.0.2, 6w0d, Serial0/1
  F. 10.0.0.0/30 is subnetted, 1 subnets D 10.4.4.4 [90/20514560] via 10.2.0.2, 6w0d, Serial0/1
  D. 10.0.0.0/22 is subnetted, 1 subnets D 10.4.0.0 [90/20514560] via 10.2.0.2, 6w0d, Serial0/1

  ---

  The 10.4.0.0/22 route includes 10.4.0.0/24, 10.4.1.0/24, 10.4.2.0/24 and 10.4.3.0/24 networks only.
