Citrix Citrix Certification 1Y0-440 Questions & Answers

• Question 61:

  Scenario: Based on a discussion between a Citrix Architect and a team of Workspacelab members, the MPX Logical layout for Workspacelab has been created across three (3) sites.

  The requirements captured during the design discussion held for a NetScaler design project are as follows:

  1.

  Two (2) pairs of NetScaler MPX appliances deployed in the DMZ and internal network.

  2.

  High Availability will be accessible for each NetScaler MPX

  3.

  The external NetScaler MPX appliance will be deployed in multi-arm mode.

  4.

  The internal NetScaler MPX will be deployed in single-arm mode wherein it will be connected to Cisco ACI Fabric.

  5.

  All three (3) Workspacelab sites: Dc, NDR and DR, will have similar NetScaler configurations and design.

  How many NetScaler MPX appliances should the architect deploy at each site to meet the design requirements above?

  A. 4

  B. 12

  C. 6

  D. 2

  Correct Answer: C

• Question 62:

  A Citrix Architect can execute a configuration job using a DeployMasterConfiguration template on a NetScaler_________deployed_________. (Choose the correct option to complete sentence.)

  A. CPX; as part of a high availability pair

  B. CPX; as a stand alone device

  C. SDX; with less than 6 partitions and dedicated management interface

  D. MPX; as part of the cluster but Cluster IP is NOT configured

  E. SDX; with no partitions as a stand alone device

  Correct Answer: C

• Question 63:

  A Citrix Architect has deployed NetScaler Management and Analytics System (NMAS) to monitor a high availability pair of NetScaler VPX devices.

  The architect needs to deploy automated configuration backup to meet the following requirements:

  1.

  The configuration backup file must be protected using a password.

  2.

  The configuration backup must be performed each day at 8:00 AM GMT.

  3.

  The configuration backup must also be performed if any changes are made in the ns.conf file.

  4.

  Once the transfer is successful, auto-delete the configuration file from the NMAS.

  Which SNMP trap will trigger the configuration file backup?

  A. netScalerConfigSave

  B. sysTotSaveConfigs

  C. netScalerConfigChange

  D. sysconfigSave

  Correct Answer: A

  Reference: https://docs.citrix.com/en-us/netscaler-mas/12/instance-management/how-to-backup-andrestore-using-mas.html#configuring-instance-backup-settings
