VMware VCP5-DCV Online Practice Questions and Exam Preparation

VMware VCP5-DCV Online Questions & Answers

• Question 71:

  A Distributed Resource Scheduler (DRS) cluster is displaying a message that recommends the migration of virtual machines, even though the cluster is currently balanced. What is the likely reason for this?

  A. The DRS cluster does not satisfy the resource pool reservations.
  B. The DRS cluster is not configured with shared storage.
  C. The DRS cluster is in a critical state.
  D. The DRS cluster contains hosts with CPU compatibility issues.
  A. The DRS cluster does not satisfy the resource pool reservations.

• Question 72:

  When deploying two sibling resource pools (RP1 and RP2), an administrator needs to make all resources in RP1 available to virtual machines in RP2.

  Which configuration should the administrator use to meet this requirement?

  A. Set the Reservation of RP2 to 0
  B. Set the Reservation of RP1 to 0
  C. Set the Limit of RP1 to Unlimited
  D. Set the Limit of RP2 to Unlimited
  B. Set the Reservation of RP1 to 0

• Question 73:

  A vSphere administrator needs to enable Distributed Resource Scheduling (DRS) in an existing vSphere environment:

  The environment contains a High Availability (HA) cluster with eight ESXi hosts.

  Six ESXi hosts are not in a cluster.

  DRS should be used on as many hosts as possible.

  Initial placement of virtual machines should be automatically performed.

  Migration recommendations should be provided, but not performed without approval.

  Which procedure should the administrator perform to accomplish this task?

  A. Select the datacenter and create a DRS cluster. Add the six remaining hosts to this cluster, then enable DRS. Edit the DRS settings and change the automation level to Partial.
  B. Select the existing HA cluster. Add the six remaining hosts to the cluster. Enable DRS, then edit the settings and change the automation level to Manual.
  C. Select the datacenter and create a DRS cluster. Add the six remaining hosts to this cluster, then enable DRS. Edit the DRS settings and change the automation level to Manual.
  D. Select the existing HA cluster. Add the six remaining hosts to the cluster. Enable DRS, then edit the settings and change the automation level to Partial.
  D. Select the existing HA cluster. Add the six remaining hosts to the cluster. Enable DRS, then edit the settings and change the automation level to Partial.

  ---

  Explanation/Reference:

• Question 74:

  A VMware administrator needs to export a vApp and create a self-contained package that has a single file.

  Which format should the administrator use?

  A. Export as OVF
  B. Export as OVA
  C. Export as ZIP
  D. Export as ISO
  B. Export as OVA

• Question 75:

  An administrator is migrating 135 virtual machines from a vSphere Standard Switch to a vSphere Distributed switch. The migration reports an error and only some of the virtual machines are transferred. What is causing the error to occur?

  A. The vSphere Distributed Switch was created with a single, default port group.
  B. The switch has become disconnected from an ESXi host.
  C. The port group on the vSphere Distributed Switch was not configured with an Elastic port binding.
  D. The virtual machine that failed to transfer did not have a network adapter.
  A. The vSphere Distributed Switch was created with a single, default port group.

• Question 76:

  -- Exhibit -



  -- Exhibit -

  What is portrayed in the performance chart?

  A. The ESXi host running the VM has Transparent Page Sharing enabled.
  B. The virtual machine's memory share value is set too high.
  C. The virtual machine is memory constrained.
  D. The ESXi host running the VM is low on memory.
  D. The ESXi host running the VM is low on memory.

• Question 77:

  When a virtual machine interacts with persistent thick virtual disks stored on a traditional Fibre Channel storage array, which two actions are always taken by the VMkernel? (Choose two.)

  A. The file corresponding to the virtual machine is located on the VMFS datastore using NPIV.
  B. Correlate the blocks requested by the virtual machine with the actual blocks on the array.
  C. Send the I/O request through the device driver to the physical HBA or software FCoE adapter.
  D. Place an atomic lock on the metadata database for the VMFS volume.
  B. Correlate the blocks requested by the virtual machine with the actual blocks on the array.
  C. Send the I/O request through the device driver to the physical HBA or software FCoE adapter.

  ---

  Explanation/Reference:

  Reference: http://www.vmware.com/files/pdf/techpaper/VMware-vSphere-Storage-API-Array- Integration.pdf

• Question 78:

  Which two conditions will cause a vMotion validation check to fail? (Choose two.)

  A. An active connection that matches an existing port group label on the target host
  B. Insufficient network bandwidth on the target virtual switch
  C. Different security policies on the target virtual switch
  D. An active connection to an internal virtual switch
  B. Insufficient network bandwidth on the target virtual switch
  D. An active connection to an internal virtual switch

  ---

  Explanation/Reference:

  Reference: http://www.datadisk.co.uk/html_docs/vmware/vmotion.htm There are different security policies on the target virtual switch ("Inconsistent security settings on a vSwitch/port group, if you have mismatched settings vMotion will error") There is an active connection to an internal virtual swicth ("Active connections that use an internal switch, by active I mean that the VM is configured and connected to the same internal switch.")

• Question 79:

  Click the Exhibit button.



  An administrator has implemented a new vSphere 5 environment and is deploying their first Windows 2008 R2 template. When running the Deploy Template wizard, the error shown in the exhibit appears. What can be done to correct the problem?

  A. Select the correct guest OS setting for the virtual machine.
  B. Windows 2003 x64 cannot be customized.
  C. Download and install the Microsoft Sysprep tool into the virtual machine to be customized.
  D. Download the Microsoft Sysprep tool to the appropriate vCenter Server directory.
  D. Download the Microsoft Sysprep tool to the appropriate vCenter Server directory.

  ---

  Explanation/Reference:

  http://communities.vmware.com/thread/45830 See the table at: http://kb.vmware.com/selfservice/microsites/search.do? language=en_USandcmd=displayKCandexternalId=1005593

• Question 80:

  What would be a valid reason to enable traffic shaping?

  A. Limiting the bandwidth of a FTP server
  B. Restricting the load on a IDS server
  C. Limiting the bandwidth used by an independent hardware iSCSI adapter
  D. Improving the performance of a CPU-intensive application server
  A. Limiting the bandwidth of a FTP server

  ---

  Explanation/Reference:

  By limiting the bandwidth of a FTP server, you can enable traffic shaping.
