CompTIA N10-006 Online Practice Questions and Exam Preparation

CompTIA N10-006 Online Questions & Answers

• Question 621:

  A company has separate subnets for each floor. A technician has moved a device from one floor to another and manually configured only the static IP address. The device can reach other devices on the floor in the same subnet, but it cannot reach devices on other floors. Which of following should be configured to allow this device to work?

  A. Gateway
  B. SNMP
  C. Port speed
  D. MTU
  E. Subnet mask
  A. Gateway

• Question 622:

  Which of the following security methods is used to attract users attempting to gain unauthorized access to various systems within a single network?

  A. Network based IDS
  B. Firewall
  C. Network based IPS
  D. Honeynet
  D. Honeynet

  ---

  Explanation Explanation/Reference:A network-based intrusion prevention system (NIPS) is a system used to monitor a network as well as protect the confidentiality, integrity, and availability of a network. Its main functions include protecting the network from threats, such as denial of service (DoS) and unauthorized usage.

• Question 623:

  Kim, a user, cannot access the network using wireless.

  Which of the following is MOST likely the cause?

  A. TXRX is reversed
  B. Faulty crossover cable
  C. Incorrect WEP key
  D. A short in the cable pairs
  C. Incorrect WEP key

• Question 624:

  Which of the following describes an area containing a rack that is used to connect customer equipment to a service provider?

  A. 110 block
  B. MDF
  C. DSU
  D. CSU
  B. MDF

  ---

  MDFstands for Main Distribution Frame. A Main Distribution Frame is a commonly a long steel rack accessible from both sides. On one side of the rack is cabling that connects the service provider's network. The other side of the rack is for the connections tothe customer's equipment.

• Question 625:

  Jeff, a network technician, is installing a wireless router. Which of the following should Jeff consider to get the BEST signal strength?

  A. WAP placement
  B. PoE devices
  C. MAC filtering
  D. Encryption type
  A. WAP placement

• Question 626:

  A user reports a network failure on a computer. The technician determines that the computer and NIC are operating properly. Which of the following tools can the technician use to trace the network cabling back to the punch down block?

  A. Protocol analyzer
  B. Multimeter
  C. Punch down tool
  D. Toner probe
  D. Toner probe

• Question 627:

  During a high availability test of a system, a fiber interruption did not re-route traffic. This is an indication of which of the following routing concepts?

  A. Static
  B. Dynamic
  C. Hybrid
  D. Routing loops
  A. Static

• Question 628:

  A web-based application is responding very slowly. The network administrator is looking at the following information from the transparent web proxy, which is configured in virtual-wire mode and is in the between the company's network and the Internet.



  Given the above information, which of the following is the layer of the OSI model at which the issue is occurring and the MOST likely reason it is occurring? (Select two.)

  A. Layer 1
  B. Layer 4
  C. Layer 3
  D. Layer 7
  E. The application crashed
  F. NO IP addresses on interfaces
  G. Excessive TCP resets
  H. Bad cable
  C. Layer 3
  H. Bad cable

  ---

  http://www.cisco.com/en/US/docs/internetworking/troubleshooting/guide/tr1907.html https://blog.ruxit.com/detecting-network-errors-impact-on-services/

• Question 629:

  When introducing new devices to the network, the organization's security policy requires that devices be monitored to establish normal traffic patterns for the device. Which of the following is generated from initial monitoring?

  A. SLA
  B. Baseline
  C. Forensic log
  D. Vulnerability assessment
  B. Baseline

• Question 630:

  In order for switching loops to be automatically disabled, which of the following needs to be implemented?

  A. Routing tables
  B. Collision domains
  C. Port mirroring
  D. Spanning-tree protocol
  D. Spanning-tree protocol
