Juniper JN0-1361 Online Questions & Answers

• Question 1:

  Your company is designing a new data center in a remote location that must be connected to your local data center. You have a service provider connection between the CE devices at each site. You want to implement EVPN with VXLAN

  services between sites, but the service provider does not offer EVPN services.

  Which two statements are true in this scenario? (Choose two )

  A. The provider's edge devices must map your VXLAN VNIs to MPLS LSPs within the provider network at each site
  B. The customer's edge devices within your data center can act as VXLAN Layer 2 gateways
  C. You can still implement EVPN service across the service provider as long as there is IP reachability between the sites.
  D. The service provider must provide an MPLS-based VPN connection between sites
  B. The customer's edge devices within your data center can act as VXLAN Layer 2 gateways
  C. You can still implement EVPN service across the service provider as long as there is IP reachability between the sites.

• Question 2:

  Exhibit: You are asked to ensure that most traffic that traverses your network is load balanced over all of the equal cost links between the routers in your network. However, you must also ensure that traffic from ISP A that is destined for ISP D must traverse the R1-R2-R3-R4-R5 path. Referring to the exhibit how would you accomplish this task?



  A. Force the ISP A to ISP D traffic over RSVP-signaled LSPs.
  B. Adjust the BGFs LOCAL PREF attribute to ensure that the raw IP packets follow the required path.
  C. Adjust the OSPF metrics of each link so that the raw IP packets follow the required path.
  D. Force the ISP A to ISP D traffic over LDP-signaled LSPs.
  A. Force the ISP A to ISP D traffic over RSVP-signaled LSPs.

• Question 3:

  Which security implementation does Juniper Networks recommend for all core routers in a service provider network?

  A. intrusion and detection prevention
  B. unified threat management
  C. application firewall
  D. stateless loopback firewall filter
  D. stateless loopback firewall filter

• Question 4:

  You are asked to design a Cloud CPE solution that can dynamically add new sites to an existing MPLS Layer 3 VPN. The CPE for each new site must support the service chaining of multiple VNFs. Which Juniper Networks Cloud CPE solution supports these requirements?

  A. Distributed Cloud CPE - Managed Internet
  B. SD-WAN
  C. Centralized Cloud CPE
  D. Distributed Cloud CPE - Option 1
  D. Distributed Cloud CPE - Option 1

• Question 5:

  Your customer wants to use NorthStar to communicate with network devices and acquire the MPLS topology. Which protocol is recommended for this purpose?

  A. PIM-SSM
  B. OSPF
  C. BGP-LS
  D. ISIS
  C. BGP-LS

• Question 6:

  You are creating a design proposal for a new service provider network using MX Series devices. You must design an OoB management network that is isolated from the production network. In this scenario which two statements are correct? (Choose two )

  A. The management network should connect to a separate network infrastructure.
  B. The FXPO interface can be used to connect devices to the management network.
  C. The management network should connect to the production network infrastructure.
  D. You must use the console port to access the devices on the management network.
  A. The management network should connect to a separate network infrastructure.
  B. The FXPO interface can be used to connect devices to the management network.

• Question 7:

  You are designing a solution for an energy trading organization that allows them to stream natural gas prices to trading partners. Prices will be streamed to trading partners using the Internet. Trading regulations require that any trading data

  streamed over a public network must be encrypted and authenticated.

  Which connectivity solution meets these requirements?

  A. L2VPN
  B. IPsec
  C. VPLS
  D. L3VPN
  B. IPsec

• Question 8:

  Your client asked you to design a solution with the requirements shown below.

  Have better traffic engineering for applications across an existing MPLS core.

  Support both IPv4 and IPv6 traffic

  Work with an MX Series core.

  Work with a North Star Controller

  Work with existing IGP (ISIS)

  Which feature would you recommend be implemented in this solution?

  A. zero touch provisioning
  B. segment routing
  C. CoS-based forwarding
  D. opaque area LSAs
  B. segment routing

• Question 9:

  What are three components of a class-of-service scheduler? (Choose three.)

  A. transmit rate
  B. forwarding class
  C. queue priority
  D. delay buffer size
  E. policing rate
  A. transmit rate
  C. queue priority
  D. delay buffer size

  ---

  Junos OS schedulers allow you to define the priority, bandwidth, delay buffer size, rate control status, and RED drop profiles to be applied to a particular queue for packet transmission

• Question 10:

  Your customer is paying for traffic prioritization and you must ensure that all traffic from their 172.27. 10.0/24 network receives top priority through your network. Which action will satisfy this requirement?

  A. Apply a behavior aggregate classifier to the egress interface.
  B. Apply a custom rewrite rule to the ingress interface.
  C. Apply a multifield classifier to the ingress interfaces.
  D. Apply a custom scheduler map to the ingress interface.
  C. Apply a multifield classifier to the ingress interfaces.

  ---

  We would need MF to match the address and set the forwarding class.
