HP HP0-S35 Online Practice Questions and Exam Preparation

HP HP0-S35 Online Questions & Answers

• Question 201:

  Which features were added to the Hyper V role in Windows Server 2008 R2 (Select two)

  A. Failover clustering
  B. Support for up to 192 running virtual machines
  C. Second-Level Address Translation
  D. Virtual machine snapshots
  E. Support for 24 logical processors
  C. Second-Level Address Translation
  D. Virtual machine snapshots

  ---

  Reference: http://www.virtualizationadmin.com/articles-tutorials/microsoft-hyper-v- articles/general/what-newwindows-server-2008-r2-hyper-v.html (see second level address translation and virtual machine snapshot operation) http:// en.wikipedia.org/wiki/Hyper-V

• Question 202:

  You are looking to expand a raid what command is needed to do this?

  A. EXPAND
  B. DISKPART
  C. AU CLI
  D. ORCA
  C. AU CLI

  ---

  http://h20000.www2.hp.com/bc/docs/support/SupportManual/c00729544/c00729544.pdf Expanding an array

  You can increase the storage space on an array by adding physical drives. Any drive that you want to add must meet the following criteria:



  It must be an unassigned drive.



  It must be of the same type as existing drives in the array (for example, SATA or SAS).



  It must have a capacity no less than that of the smallest drive in the array.

  When you want to expand an array, allow about 15 minutes per gigabyte for the expansion to be completed. During this time, the controller cannot perform any other expansion or migration. Performance might be degraded slightly during the

  expansion, depending on the Expand Priority setting ("Setting the rebuild priority or expand priority" on page 15). To minimize any effect on normal server operations, expand an array during periods of low server use.

  To expand an array:

  1.

  Back up all data on the array. Although array expansion is unlikely to cause data loss, observing this precaution provides extra data security.

  2.

  Confirm that the cache battery is connected and fully charged.

  3.

  In the Logical Configuration View panel, highlight the array, and then press the Enter key.

  4.

  In the Array Options menu, highlight the Expand Array option, and then press the Enter key. The screen displays three panels (Expand Array, Physical Drives, and Expand Existing Array), and the highlight moves to the Expand Array panel.

  5.

  Highlight the Assign Drive option, and then press the Enter key.

  The highlight moves to the Physical Drives panel.

  6.

  Highlight a physical drive that you want to add to the array, and then press the Enter key. (For optimum use of drive capacity, select a drive that has the same capacity as other drives in the array.) The highlight returns to the Expand Array panel.

  7.

  (Optional) Repeat steps 5 and 6 to add more drives.

  8.

  Highlight the Accept Changes option, and then press the Enter key.

  9.

  Press the Esc key to begin the array expansion and return to the Logical Configuration View panel.

  To view the progress of the array expansion, press the F3 key, and then scroll to the progress bar near the bottom of the screen.

• Question 203:

  Which best practice can be considered when building an iSCSI network with high availability as a key deliverable?

  A. Ensure iSCSI traffic flows through the same broadcast domain as user traffic.
  B. Set iSCSI MTUs to 9000 and switch to 1500.
  C. Disable flowcontrol on the Ethernet switches.
  D. Separate iSCSI traffic from user traffic separate physical switches.
  D. Separate iSCSI traffic from user traffic separate physical switches.

• Question 204:

  The Onboard Administrator screenshot below displays a c7000 enclosures showing the port mapping interconnect bay 3. New ProLiant BL460c blade servers are in 14. All newly installed blade servers are correctly configured with mezzanine cards. How many unused Device Bay ports will be shown after populating these new blades?



  A. 2
  B. 3
  C. 4
  D. 6
  C. 4

• Question 205:

  A customer wants to move an HP blade server from one bay to another within the same Virtual Connect domain. The customer requires that the server maintains the same WWNs MACs. What must be done to meet this requirement?

  A. Nothing needs to be done as the profile follows the server automatically to the new bay
  B. Copy the profile from the original bay to the new bay.
  C. Write the profile to the server, than move the server to the new bay.
  D. Move the profile from the original bay to the new bay.
  D. Move the profile from the original bay to the new bay.

  ---

  Reference: http://jreypo.wordpress.com/2011/01/07/hp-virtual-connect-domain-setup-%E2%80%93- part-4-server-profiles/

• Question 206:

  You are configuring HP Integrity Virtual Machines on an HP Inegrity BL8x0c i2 blade server system based on the Intel Itanium processor 9300 series. You plan to use the default 10 Gb Ethernet adapters with jumbo frame support. Which memory sizing rule must be used for the HP-UX guest OS?

  A. The memory required for the 10 GbE adapter is not enough to require consideration
  B. Use the maximum I/O per second multiplied by the total virtual machine memory allocated
  C. Minimum memory size is based on CPU allocations
  D. Add an additional 1 GB of memory per 10 GbE networks port
  D. Add an additional 1 GB of memory per 10 GbE networks port

  ---

  http://bizsupport2.austin.hp.com/bc/docs/support/SupportManual/c02157777/c02157777.pdf - Pages 12 and 13

  For most Integrity systems, the memory required for I/O adopters is negligible. One exception is the HP Integrity BL8x0c i2 Server Blade system - based on the Intel Itanium processor 9300 series. The l0GbE (10GigE) network ports on BL8x0c i2 server blades require an additional 500MB of memory per 10GbE network port when they are configured for Flex 10 or jumbo frames. If these ports have both Flex 10 and jumbo frames enabled, then the additional memory requirement is 1GB per 10GbE network port. Refer to latest memory subsystem documentation for changes to these requirements.

• Question 207:

  A technician wants to find local real-time hardware and firmware information about an HP ProLiant server. Which product should be used?

  A. vCenter
  B. System Insight Manager
  C. System Management Homepage
  D. System Console Operation Management
  C. System Management Homepage
