Huawei H12-321 Online Practice Questions and Exam Preparation

Huawei H12-321 Online Questions & Answers

• Question 271:

  When a large-scale enterprise deploys a WLAN Layer 3 network, you need to configure the Option 43 field on the Windows 2003 DHCP server to notify the AP of the IP address of the AC. The IP address of the AC is 10.23.100.1. Which of the following is required in the Option 43 field on the DHCP server?

  A. 030831302E32332E3130302E31
  B. 040831302E32332E3130302E31
  C. 030B31302E32332E3130302E31
  D. 030B31302E32332E31302E3031
  C. 030B31302E32332E3130302E31

• Question 272:

  Which of the followings are WLAN security technologies? (Multiple Choice)

  A. Access authentication
  B. Radio link encryption
  C. wds
  D. wips
  A. Access authentication
  B. Radio link encryption
  D. wips

• Question 273:

  What is wrong about the description of the omnidirectional antenna below?

  A. Omnidirectional antenna distributes the signal evenly over a 360-degree omnidirectional area around the center point
  B. The omnidirectional antenna has a lobe width of 360 degrees horizontally
  C. The omnidirectional antenna has strong energy gathering ability and the direction of the signal is good.
  D. The omnidirectional antenna has a lobe width of 360 degrees vertically
  D. The omnidirectional antenna has a lobe width of 360 degrees vertically

• Question 274:

  The following description of the Mesh profile is wrong?

  A. In a Mesh BSS, all Mesh STAs have the same Mesh profile. If all the parameters of the Mesh profile are matched, the Mesh profile is considered to be consistent.
  B. Mesh profile contains the following contents, Mesh ID, A path selection protocol identifier (fixed), A path metric identifier (fixed)
  C. After creating a Mesh BSS or becoming a BSS member, a Mesh STA will generate a Mesh profile.
  D. Unless the Mesh profile leaves the Mesh BSS (the Mesh STA is already a member of the Mesh BSS), the Mesh STA does not change its Mesh profile.
  C. After creating a Mesh BSS or becoming a BSS member, a Mesh STA will generate a Mesh profile.

• Question 275:

  The following description of the directional antenna is wrong?

  A. Directional antennas are radiated in a range of angles on a horizontal pattern, which is commonly referred to as a directional antenna.
  B. The directional antenna has the strongest energy gathering ability, and the direction of the signal is very good.
  C. When the number of remote link points is small, or the angular orientation is quite concentrated, the use of directional antennas is the most effective solution.
  D. Directional antennas have only the main flap for practical use, so the side lobes can be ignored.
  D. Directional antennas have only the main flap for practical use, so the side lobes can be ignored.

• Question 276:

  In the WLAN network, which of the following will trigger an alarm?

  A. Flood attack
  B. Spoof attack
  C. Weak IV attack
  D. Violent cracking
  A. Flood attack
  B. Spoof attack
  C. Weak IV attack
  D. Violent cracking

• Question 277:

  Which of the following factors will affect the calculation of the radius of the Fresnel zone in outdoor communication?

  A. Antenna beamwidth
  B. RF visual line of sight
  C. Distance between transceiver antennas
  D. Signal transmission frequency
  C. Distance between transceiver antennas
  D. Signal transmission frequency

• Question 278:

  On a WLAN that uses the Agile Controller, which of the followings is NOT a step in the procedure for troubleshooting an 802.lx authentication fault?

  A. Check whether the number of online users reaches the maximum.
  B. Check the AAA configuration on the device.
  C. Check 802.1x authentication configuration.
  D. Check web authentication configuration.
  D. Check web authentication configuration.

• Question 279:

  What are the advantages of a WLAN Mesh network over a traditional WLAN?

  A. The limitations of coverage are broken
  B. Reduce reliance on wired networks
  C. Wireless signal is stronger
  D. Support AP or AC function of Mesh device is more powerful
  A. The limitations of coverage are broken
  B. Reduce reliance on wired networks

• Question 280:

  In the figure, transparent transmission of STP packets may cause mutual impact between bops. To prevent the impact, which statement about STP is TRUE?



  A. STP needs to be enabled on only MPP's wired interfaces.
  B. STP needs to be enabled on only MP3's wired interfaces.
  C. STP needs to be enabled on the wired interfaces of both MPP and MP3.
  D. STP needs to be enabled on MP1 and MP2.
  C. STP needs to be enabled on the wired interfaces of both MPP and MP3.
