• Question 241:

  Configure the Option 43 field on the Windows 2003 DHCP server. For example, configure the character string 030C3139322E3136382E32322E31 to indicate the IP address 192.168.22.1. In the character string, 03 is a fixed value; 0C is 12 in decimal format, indicating the string length of the IP address. The IP address 192.168.22.1 has a total of 12 characters. The hexadecimal value 31 is the ASCII value of 1, 39 is the ASCII value of 9, and so on. 2E is the ASCII value of dots. Based on the preceding example, what is the character string corresponding to the IP address 32.15.2.14?

  A. 030733322E31352E322E3134
  B. 030A33322E31352E322E3134
  C. 030A3033322E3031352E3030322E303134
  D. 030A32332E35312E322E3431
  B. 030A33322E31352E322E3134

• Question 242:

  As shown in the figure, in the dual-link load balancing hot standby network, AP1 is a new online AP, and both ACs have access configuration. Which AC does AP1 choose to access?

  A. AC1
  B. AC2
  C. Random access
  D. Will not access
  A. AC1

• Question 243:

  Which statements about roaming are TRUE? (Multiple Choice)

  A. STA roaming indicates the process in which STAs switch from one AP to another.
  B. In both Layer 2 and Layer 3 roaming, STAs' IP addresses remain unchanged.
  C. The APs used to implement WLAN roaming must be of the same model.
  D. When an AC receives an association/re-association request, it determines that the STA roams if an entry about the STA already exists.
  A. STA roaming indicates the process in which STAs switch from one AP to another.
  B. In both Layer 2 and Layer 3 roaming, STAs' IP addresses remain unchanged.
  D. When an AC receives an association/re-association request, it determines that the STA roams if an entry about the STA already exists.

• Question 244:

  The following is true about the three backup methods?

  A. Dual-link hot backup: Back up AP and STA information at the same time, and back up CAPWAP link information.
  B. VRRP hot backup: back up AP and STA information at the same time, and back up CAPWAP link information.
  C. Whether a cold backup or a hot backup is a backup AC only supports backup for one primary AC.
  D. Dual-link backup is a cold backup and does not back up STA information. The AP establishes two links with the active and standby ACs at the same time. During the active/standby switchover or the switchback process, the STA needs to go online again, and the service will be temporarily interrupted.
  D. Dual-link backup is a cold backup and does not back up STA information. The AP establishes two links with the active and standby ACs at the same time. During the active/standby switchover or the switchback process, the STA needs to go online again, and the service will be temporarily interrupted.

• Question 245:

  The Agile Controller fails to connect to the AD server during the configuration of the Agile Controller. The AD server IP address and synchronization account and password are all correct, and no additional configuration is performed for the AD server. The configuration is shown in the following figure. What causes the connection failure? (Multiple Choice)



  A. Incorrect synchronization type
  B. Incorrect authentication source name
  C. Incorrect port number
  D. Incorrect base DN r SSL is disabled
  C. Incorrect port number
  D. Incorrect base DN r SSL is disabled

• Question 246:

  Which of the following statements is TRUE about the Agile Controller admission control model? (Multiple Choice)

  A. The core of the model is the authorization condition and authorization result.
  B. Currently, only 802.1x and Portal authentication support all conditions in the admission control model.
  C. The authorization elements do not include the IP address range.
  D. Authorization conditions include authorization elements.
  A. The core of the model is the authorization condition and authorization result.
  B. Currently, only 802.1x and Portal authentication support all conditions in the admission control model.
  D. Authorization conditions include authorization elements.

• Question 247:

  Which of the following steps are involved in the roaming process? (Multiple Choice)

  A. Measurement
  B. Identification
  C. Decision
  D. Execution
  A. Measurement
  C. Decision
  D. Execution

• Question 248:

  Regarding the relationship between the two technologies of 802.1x and RADIUS, what is the following description correct?

  A. 802.1x and RADIUS are different names for the same technology
  B. 802.1x is a technical system that includes RADIUS
  C. 802.1x and RADIUS are different technologies, but they are often used together to complete access control for end users.
  D. 802.1x and RADIUS are completely different technologies and usually do not work together.
  C. 802.1x and RADIUS are different technologies, but they are often used together to complete access control for end users.

• Question 249:

  In the N+1 backup networking shown in the figure, the global priority of AC3 is set to 5, and the global priorities of AC1 and AC2 are set to 6. The API-specific priority of AC1 is set to 3, and the AP3-specific priority of AC2 is set to 3. When no AP connects to AC1, AC2, and AC3, which AC will API, AP2, AP3, and AP4 connect to respectively?



  A. API connects to AC1, AP2 connects to AC3, AP3 connects to AC2, and AP4 connects to AC3.
  B. API connects to AC3, AP2 connects to AC3, AP3 connects to AC3, and AP4 connects to AC1 or AC2.
  C. API connects to AC1, AP2 connects to AC1 or AC2, AP3 connects to AC2, and AP4 connects to AC1 or AC2.
  D. API connects to AC3, AP2 connects to AC1 or AC2, AP3 connects to AC3, and AP4 connects to AC3.
  A. API connects to AC1, AP2 connects to AC3, AP3 connects to AC2, and AP4 connects to AC3.

• Question 250:

  On an intra-frequency Mesh network, two APs provide 200 Mbps bandwidth. Which is the average bandwidth if one more AP is added to the network?

  A. Up to 200 Mbps
  B. Up to 150 Mbps
  C. Up to 100 Mbps
  D. Up to 50 Mbps
  C. Up to 100 Mbps
