Huawei H12-321 Online Practice Questions and Exam Preparation

Huawei H12-321 Online Questions & Answers

• Question 211:

  As shown in the figure, which AP and STA in the figure cannot perform normal data communication?

  A. AP1 and STA1
  B. AP1 and STA2
  C. AP2 and STA1
  D. AP2 and STA2
  A. AP1 and STA1
  C. AP2 and STA1
  D. AP2 and STA2

• Question 212:

  When the STA uses the WPA2-802.1x security policy and supports fast roaming, the STA only needs to perform key negotiation, but does not need to pass 802.lx authentication again during roaming.

  A. TRUE
  B. FALSE
  A. TRUE

• Question 213:

  Which are the methods to prevent bops on a multi-MPP Mesh network? (Multiple Choice)

  A. STP
  B. MSTP
  C. TTL
  D. Repeated frame sequence number check
  A. STP
  B. MSTP

• Question 214:

  As shown in the figure, in the Mesh networking, what is required to enable the STP spanning tree protocol?

  A. AC G0/0/1 interface
  B. MPP
  C. MP
  D. Switch
  D. Switch

• Question 215:

  Which are the correct procedures of Mesh route establishment in pro-active mode? (Multiple Choice)

  A. 1. The MP periodically broadcasts PREQ. 2. The MPs/MPPs receiving the PREQ reply with unicast PREP. 3. The route and return route are established between two points.
  B. 1. The MPP periodically broadcasts RANN. 2. The MP receiving the RANN sends a unicast PREQ to the MPP. 3. The MPP replies with a PREP. 4. The route is established between MP and MPP.
  C. 1. The MPP periodically broadcasts RANN. 2. The MP receiving the RANN sends a unicast PREP to the MPP.
  D. 3. The route is established between MP and MPP.
  E. 1. The MPP periodically broadcasts PREQ. 2. The MP receiving the PREQ sends a unicast PREP to the MPP. 3. The route is established between MP and MPP.
  B. 1. The MPP periodically broadcasts RANN. 2. The MP receiving the RANN sends a unicast PREQ to the MPP. 3. The MPP replies with a PREP. 4. The route is established between MP and MPP.
  D. 3. The route is established between MP and MPP.

• Question 216:

  What is the sequence of VLAN VLAN allocation for a terminal?

  1.

  The terminal accesses from the divided VLANs.

  2.

  Determines the VLAN Pool and VLAN algorithm bound to the VAP.

  3.

  The terminal accesses the VAP.

  4.

  Assigns a VLAN to the terminal according to the VLAN algorithm.

  A. 3->2->4->1
  B. 4->2->3->1
  C. 4->3->2->1
  D. 3->4->2->1
  A. 3->2->4->1

• Question 217:

  Which of the following statements about the HSB solution are TRUE?



  A. Figure (a) shows the active/standby mode.
  B. Figure (b) shows the active/standby mode.
  C. Figure (a) shows the load balancing mode.
  D. Figure (b) shows the load balancing mode.
  B. Figure (b) shows the active/standby mode.
  C. Figure (a) shows the load balancing mode.

• Question 218:

  Regarding the usage scenarios and characteristics of various ACs, is the following description correct?

  A. A separate AC board, such as ACU2, is suitable for large-scale networks. In the future, there will be capacity expansion requirements and rack slots will be tight.
  B. Stand-alone box AC, such as AC6605, is suitable for unified construction of wired and wireless networks, and unified management of wired and wireless users.
  C. The board with the AC, such as the X1E board, is suitable for the independent management of wired and wireless users.
  D. With the board AC, such as the X1E board, it has higher forwarding performance than the independent AC, such as the AC6605, and can achieve redundant backup at the device level and link level, which makes the WLAN network have better reliability.
  A. A separate AC board, such as ACU2, is suitable for large-scale networks. In the future, there will be capacity expansion requirements and rack slots will be tight.
  D. With the board AC, such as the X1E board, it has higher forwarding performance than the independent AC, such as the AC6605, and can achieve redundant backup at the device level and link level, which makes the WLAN network have better reliability.

• Question 219:

  When the dual-link hot standby switchover is performed, what is the correct behavior about the AP and the user?

  A. AP does not need to go online again
  B. AP needs to go online again
  C. Users do not need to go online again
  D. Users need to go online again
  A. AP does not need to go online again
  C. Users do not need to go online again

• Question 220:

  Which of the following statements about active neighbor probe is FALSE?

  A. An AP periodically sends Probe Request frames destined for a specified multicast address on different channels. After receiving the frames, surrounding APs learn that the AP is a neighbor.
  B. Active probe is used to establish neighbor relationships between authorized APs.
  C. Active probe is used to obtain the maximum interference signal strength between authorized neighboring APs, in which signal strength of the neighboring AP is the key.
  D. Active probe and passive probe are used to collect interference information from rogue APs.
  D. Active probe and passive probe are used to collect interference information from rogue APs.
