Huawei H12-222 Online Practice Questions and Exam Preparation

Huawei H12-222 Online Questions & Answers

• Question 121:

  In the MPLS VPN, RD values are added to IPv4 addresses to distinguish IPv4 prefixes with the same address space. Which of the following statements are true? (Multiple Choice)

  A. The RD is encapsulated into the Update packet as the BGP extended attribute.
  B. After receiving IPv4 routes from a CE, a PE adds RDs to them to convert them to globally unique VPN-IPv4 routes and advertises the routes on the public network.
  C. Each VPN instance on a PE corresponds to a RD value. The RD on the same PE must be globally unique.
  D. The RD can be used to control advertisement of VPN routing information.
  B. After receiving IPv4 routes from a CE, a PE adds RDs to them to convert them to globally unique VPN-IPv4 routes and advertises the routes on the public network.
  C. Each VPN instance on a PE corresponds to a RD value. The RD on the same PE must be globally unique.

• Question 122:

  Which zones are provided by the Huawei firewall by default? (Multiple Choice)

  A. Local zone
  B. Trusted zone
  C. Untrusted zone
  D. Security zone
  D. Security zone

• Question 123:

  On a carrier's MPLS VPN network, PE1 and PE2 transmit data packets between VPNs. After PE1 receives VPN route 172.16.1.0/24 from a client, it converts the route into a VPNv4 route and distributes label 1027 to the packet. After the packet arrives at PE2, PE2 distributes label 1025 to the packet. When a client on PE2 accesses this route, what are the outer and inner labels in the packet transmitted over the carrier network?

  A. Outer label: 1027; inner label: 1025
  B. Outer label: 1025; inner label: 1025
  C. Outer label: 1027; inner label: 1027
  D. Outer label: 1025; inner label: 1027
  D. Outer label: 1025; inner label: 1027

• Question 124:

  What are the mainly methods of data collection? (Multiple Choice)

  A. Collection by physical optical splitter
  B. Collection through port mirroring
  C. Centralized collection by NMS
  D. Automatic collection
  A. Collection by physical optical splitter
  B. Collection through port mirroring
  C. Centralized collection by NMS

• Question 125:

  How is NFV defined?

  A. Network infrastructure virtualization
  B. Network function virtualization
  C. Network bus virtualization
  D. Network architecture virtualization
  B. Network function virtualization

• Question 126:

  For the IntServ model, an application needs to apply for reserved resources before sending packets.

  A. TRUE
  B. FALSE
  A. TRUE

• Question 127:

  If the DSCP priority (leftmost 6 bits of the ToS field) is used, how many types of packets can be classified?

  A. 8
  B. 16
  C. 32
  D. 64
  D. 64

• Question 128:

  Which are the new requirements on the enterprise network stimulated by the mobility trend? (Multiple Choice)

  A. Unified wired and wireless management
  B. Consistent service experience anytime, anywhere
  C. Fast deployment of mobile applications
  D. Strict hierarchical networking
  A. Unified wired and wireless management
  B. Consistent service experience anytime, anywhere
  C. Fast deployment of mobile applications

• Question 129:

  On the MPLS network shown in the following figure, which of the following statements are true? (Multiple Choice)



  A. The switch uses the directly-connected interface to set up a TCP connection.
  B. The switch's peer LDP ID is an interface IP address of the peer device.
  C. The switch's peer LDP ID is the MPLS LSR ID of the peer device.
  D. The switch uses the LSR ID to set up a TCP connection.
  A. The switch uses the directly-connected interface to set up a TCP connection.
  C. The switch's peer LDP ID is the MPLS LSR ID of the peer device.

• Question 130:

  Which of the following statements regarding Huawei eSight network management software is false?

  A. eSight is a lightweight system and a wizard is available for eSight installation.
  B. eSight adopts the C/S architecture, so users can access eSight using a browser anytime, anywhere.
  C. eSight provides corresponding solutions for different customers.
  D. eSight can uniformly manage devices from multiple vendors.
  B. eSight adopts the C/S architecture, so users can access eSight using a browser anytime, anywhere.
