NetApp Network Appliance NCIE-SAN NS0-504 Questions & Answers

• Question 21:

  A storage administrator tested a storage failover but when attempting a giveback, the data aggregate was not returned to the original controller until after boot up of DATA ONTAP. However, the root aggregate was given back correctly prior to

  the boot up of the Data ONTAP.

  What is a likely cause?

  A. There is no problem. This is the default behaviour.

  B. The cables connect to the client network properly installed.

  C. The VTIC cables are NOT installed.

  D. The shelves cables are NOT properly installed.

  Correct Answer: A

• Question 22:

  Where would you go to find out more information about how to configure a Brocade FC Switch?

  A. Fabric OS Administrator's Guide

  B. NetApp StorageGRID Administration Guide

  C. Data ONTAP Administration Guide

  D. Data ONTAP iSCSI Administration Guide

  Correct Answer: A

• Question 23:

  How many nodes are supported running san protocols in Clustered Data ONTAP 8.2?

  A. 8

  B. 10

  C. 12

  D. 16

  E. 24

  Correct Answer: A

• Question 24:

  Which three does clustered Data ONTAP support for iSCSI with Microsoft Windows 2012 solutions? (Choose 3)

  A. Enhanced Transmission Services

  B. NIC teaming

  C. Jumbo frames

  D. VLANs

  E. ALUA

  Correct Answer: ACD

• Question 25:

  What is the name of the Brocade Fibre Channel switch OS?

  A. Fabric OS (FOS)

  B. Internetworks OS (IOS)

  C. Internet OS (I-OS)

  D. Network OS (NX-OS)

  Correct Answer: A

• Question 26:

  Portsets limit host access to certain paths when they are bound to ____________.

  A. A LUN

  B. An igroup

  C. A logical interface (LIF)

  D. A physical port

  Correct Answer: B

• Question 27:

  When applied to an igroup, what is the function of a portset?

  A. A portset allows a host to utilize all of its paths equally.

  B. A portset constrains the target ports where a LUN is visible to a host.

  C. A portset specifies which paths to a LUN are Direct and Indirect.

  D. A portset throttles the amount of traffic available to the hosts in that igroup

  Correct Answer: B

• Question 28:

  iSCSI and FC SAN deployments share requirements for these planning steps with one exception. Which task is NOT required for both types of deployments?

  A. Review implementation flowchart with customer - assign tasks

  B. Verify logistics plan for staging and installation of equipment

  C. Validate equipment move path to installation location (doorway clearances, floor loading inabilities, etc.)

  D. Finalize switch zone configurations

  E. Verify Ethernet cabling plan and availability of cable supports

  Correct Answer: D

• Question 29:

  For a Brocade Fibre Channel switch, which commands can you use to check the devices that have logged in to the switch? (Choose two.)

  A. targetshow

  B. initiatorshow

  C. deviceloginshow

  D. deviceshow

  E. portshow

  F. portloginshow

  Correct Answer: EF

• Question 30:

  When running Data ONTAP in Cluster-Mode, which three statements are true about Asymmetric Logical Unit Access (ALUA)? (Choose three.)

  A. There is no configuration required on the storage system.

  B. It allows the initiator to query the target about path attributes, such as primary path and secondary path.

  C. It is a set of SCSI commands for discovering and managing multiple paths to LUNs on Fibre Channel SANs.

  D. It requires Array Support Library (ASL), a proprietary vendor library.

  E. It no longer requires proprietary SCSI commands.

  Correct Answer: BCE
