Microsoft 74-697 Online Practice Questions and Exam Preparation

Microsoft 74-697 Online Questions & Answers

• Question 1:

  You have a Windows Assessment and Deployment Kit (Windows ADK) environment that con- tains a file server named Served. Served runs Windows Server 2012.

  You copy the Windows 8 installation media to a shared folder on Served. You install Windows 8 on a reference computer, and then you generalize the installation.

  You need to replace the image in the share with an image of the reference computer.

  Which three actions should you perform in sequence? (To answer, move the appropriate three actions from the list of actions to the answer area and arrange them in the correct order.)

  Select and Place:





• Question 2:

  You have a server that has the Windows Deployment Services server role installed. Windows Deployment Services (WDS) has an image group that contains several Windows 8 images.

  You need to ensure that the company name and the support phone number of the OEM are con- figured when the image is deployed to a computer.

  Which file should you modify?

  A. Unattend.xml
  B. Startnet.cmd
  C. Sysprep.inf
  D. Winpeshl.ini
  A. Unattend.xml

• Question 3:

  You deploy an image of Windows 8 to 500 client computers that will be shipped to a customer. You start one of the computers and verify that the Windows Welcome screen is displayed.

  You need to restart the computer in audit mode.

  Which keyboard shortcut should you use?

  A. CTRL+SHIFT+ESC
  B. WIN + D
  C. CTRL+SHIFT+F3
  D. CTRL+ALT+TAB
  C. CTRL+SHIFT+F3

• Question 4:

  You plan to deploy operating systems to several servers. The servers have RAID controllers.

  You plan to install three hard disks on each server.

  You need to configure the servers to meet the following requirements:



  Ensure that all data will be available if a single disk fails.



  Provide the highest amount of disk space to store files. Which RAID level should you configure on the servers?

  A. RAID 0
  B. RAID 1
  C. RAID 5
  D. RAID 6
  C. RAID 5

• Question 5:

  You are an OEM system builder.

  A customer purchases an OEM System Builder pack for Windows 8 Pro to install under a Per- sonal Use License.

  Who is responsible for providing support to the customer under a Personal Use License?

  A. a Microsoft Authorized Distributor
  B. the customer
  C. Microsoft
  D. the OEM system builder
  D. the OEM system builder

• Question 6:

  You have a Windows 8 image.

  You are testing the Out-of-Box-Experience (OOBE).

  You discover that when neither a keyboard nor a mouse is connected, the Human Interface De- vice (HID) pairing instructions do not appear.

  You need to ensure that the HID pairing instructions appear when the image starts on a client computer that has neither a keyboard nor a mouse connected.

  Which file should you create?

  A. unattend.xml
  B. Oobe.xml
  C. Coconfig.xml
  D. Sysprep.inf
  B. Oobe.xml

• Question 7:

  You plan to deliver 20 new client computers to a customer. The computers will have Windows 8 preinstalled.

  The customer currently has four client computers that have a Full Packaged Product (FPP) ver- sion of Windows 7 Ultimate.

  The customer plans to install Windows 8 on the four computers.

  You need to recommend a Windows 8 licensing solution for the 24 computers. The solution must minimize licensing costs.

  What should you recommend?

  A. 20 FPP licenses for Windows 8 and four OEM licenses for Windows 8
  B. 20 OEM licenses for Windows 8 and four FPP licenses for Windows 8
  C. 24 OEM licenses for Windows 8 with Software Assurance
  D. 24 OEM licenses for Windows 8
  B. 20 OEM licenses for Windows 8 and four FPP licenses for Windows 8

• Question 8:

  You have a technician computer named Computer1 and a server named Server1.

  You plan to deploy several images to computers on the network. The planned installation will in- clude multiple language packs.

  You create a folder on Server1 and share the folder as Share1.

  You need to configure Share1 as a distribution share from Windows System Image Manager (Windows SIM).

  What should you do first?

  A. Copy the Windows 8 installation media to Share1.
  B. Create a folder named Install in Share1.
  C. Copy the Windows Assessment and Deployment Kit (Windows ADK) to Share1.
  D. Create a folder named Packages in Share1.
  D. Create a folder named Packages in Share1.

• Question 9:

  You have three images sealed in Out-of-Box-Experience (OOBE) mode.

  You use the images on a daily basis to build client computers for customers.

  A new customer places an order for 500 computers. The customer's requirements for the comput- ers are not met by any of the images.

  You identify an image that you can modify by installing two applications required by the cu- tomer.

  You plan to customize the image before you deploy the image to the computers.

  You need to identify which steps must be taken to modify the image.

  What should you do before you capture the image?

  A. Start the image in audit mode on a reference computer. Install the required applications. Seal the image in audit mode.
  B. Start the image in audit mode on a reference computer. Install the required applications. Seal the image in OOBE mode.
  C. Start the image in audit mode on a reference computer. Install the required applications. Restart the computer.
  D. Start the image on a reference computer. Install the required applications. Seal the image in audit mode.
  B. Start the image in audit mode on a reference computer. Install the required applications. Seal the image in OOBE mode.

• Question 10:

  A technician is preparing a reference image of Windows 8 on a client computer.

  The technician runs sysprep.exe on the reference computer and receives an error message.

  You need to identify which error occurred when sysprep.exe was run.

  Which file should you view?

  A. C:\Windows\System32\Sysprep\Panther\Setupact.log
  B. C:\Windows\Panther\Setupact.log
  C. C:\Windows\System32\Sysprep\Panther\Diagwrn.xml
  D. C:\Windows\Panther\Diagwrn.xml
  A. C:\Windows\System32\Sysprep\Panther\Setupact.log
