Cisco 642-980 Online Practice Questions and Exam Preparation

Cisco 642-980 Online Questions & Answers

• Question 71:

  Which two describe the correct requirements for non-disruptive IOS ISSU on Cisco Nexus 7000 Series Switches? (Choose two.)

  A. updated kickstart and system images must be staged in bootflash on single-supervisor switches
  B. updated kickstart and system images must be staged in bootflash on dual-supervisor switches
  C. low version skew
  D. dual supervisors
  E. clock synchronization
  C. low version skew
  D. dual supervisors

• Question 72:

  Refer to the exhibit.



  When your customers have NPV problems, whichthree actions should you take?(Choose three.)

  A. Verify that the NPV core switch supports NPIV and that it is enabled.
  B. Verify that all ports are properly configured and connected.
  C. Ensure that the VLAN values are configured on both sides of the NPV core switch.
  D. Verify the status of the servers and external interfaces, using the show npv server status command.
  E. Ensure that the VSAN value that is configured on the device links is correct.
  F. For all the device links, ensure that the port mode on the NPV device is in Full_port mode.
  A. Verify that the NPV core switch supports NPIV and that it is enabled.
  B. Verify that all ports are properly configured and connected.
  E. Ensure that the VSAN value that is configured on the device links is correct.

• Question 73:

  Refer to the output.

  feature otv

  otv site-vlan 2

  otv site-identifier 256

  !

  interface ethernet 2/0

  ip address 192.0.2.1/24

  ip igmp version 3

  !

  interface ethernet 2/1

  ip address 192.0.2.2/24

  ip igmp version 3

  !

  interface Overlay1

  otv control-group 239.1.1.1

  otv join-interface ethernet 2/0

  otv extend-vlan 3-100

  !

  interface Overlay2

  otv control-group 239.1.1.1

  otv join-interface ethernet 2/1

  otv extend-vlan 101-115

  Which command best represents where the control plane configurations are applied?

  A. switch(config-if-overlay)# otv isis hello-interval 30
  B. switch(config-if)# otv isis hello-interval 30
  C. switch(config-vlan)# otv isis hello-interval 30
  D. switch(config)# otv isis hello-interval 30
  A. switch(config-if-overlay)# otv isis hello-interval 30

• Question 74:

  When you ping your new Cisco Nexus 7010 Switch, you see this output:

  !!...!!...!!...!!...!!...

  What could be the problem?

  A. Traffic may be taking a bad route through the network.
  B. HSRP is flapping.
  C. CoPP is rate-limiting the pings.
  D. The switch has high CPU utilization.
  C. CoPP is rate-limiting the pings.

• Question 75:

  Your customer is an ISP providing service to thousands of end customers. Its main concerns are focused on using up the total number of 4096 VLANs per VDC, wasting an unused block of IP addresses, and IP address management. Which technique will address these concerns?

  A. create a separate VDC to scale VLAN limitation and upgrade to Cisco Nexus 7018 Switch
  B. segment VLANs using secondary IP addresses, which will reduce the management domain
  C. create mapping between the VLAN and VSAN to run FCoE to consolidate VLAN and IP addresses
  D. use PVLANs, which will solve the scalability problem and provide IP address management
  D. use PVLANs, which will solve the scalability problem and provide IP address management

• Question 76:

  A customer is deploying multihop FCoE in its network. Which guideline must the customer follow with respect to VE ports to make this deployment possible?

  A. Auto mode on the vFC interface is supported.
  B. VE-port trunking is supported over FCoE-enabled VLANs.
  C. VE-port interface binding to MAC addresses is supported.
  D. A VE port is disabled for trunk mode by default.
  B. VE-port trunking is supported over FCoE-enabled VLANs.

• Question 77:

  Your customer has a dual Cisco Nexus 7010 Switches in its data center. Customer's representatives want to know how to determine if Cisco IOS ISSU is possible on the switches as they are upgrading to version 6.0.4. Which command is useful to determine if the upgrade will be non-disruptive?

  A. N7010-C1# show system redundancy ha status
  B. N7010-C1# show incompatibility system
  C. N7010-C1# install all
  D. N7010-C1# show issu test bootflash:n7000-s1-system.6.0.4.bin
  C. N7010-C1# install all

• Question 78:

  While troubleshooting HSRP adjacency, a packet analyzer captures the remote packet with the information: IP 224.0.0.102 with a MAC address of 0000.0C9F.0256. The DCI local group number is 256.

  Which solutionresolves the problem?

  A. Request that the remote data center change the HSRP version to V1.
  B. Report the issue as a suspected bug because the group number is correct based on the analyzer.
  C. Request that the remote data center verifies that they do not have an HSRP password configured.
  D. Request that the remote data center to use the correct HSRP group number.
  E. Change the local HSRP version to V1.
  D. Request that the remote data center to use the correct HSRP group number.

• Question 79:

  NPV mode is not operating properly on a Cisco Nexus or Cisco MDS Series Switch. What are two reasons? (Choose two.)

  A. An uplink NP port is stuck initializing.
  B. The VSAN does not match at each end of the connection.
  C. The VLAN does not match at each end of the connection.
  D. The license is invalid.
  A. An uplink NP port is stuck initializing.
  B. The VSAN does not match at each end of the connection.

• Question 80:



  Fibre Channel traffic on VSAN 12 between N5K2 and MDS9124-2 is degraded. Which statement explains the cause of this degradation?

  A. Performance is decreased by half due to the incorrect port type being used.
  B. The load-balancing scheme for VSAN 12 should be src-id/dst-id.
  C. B2B credits on N5K2 should be increased to 128.
  D. A VSAN port channel must be configured between N5K2 and MDS9124-2.
  D. A VSAN port channel must be configured between N5K2 and MDS9124-2.
