Nokia 4A0-C01 Online Practice Questions and Exam Preparation

Nokia 4A0-C01 Online Questions & Answers

• Question 881:

  Click on the exhibit button below.



  If CE1 and PE1 use BGP to exchange routing information and CE2 and PE2 use static routing to forward traffic to and from the VPRN, which of the following statements is considered TRUE?

  A. An export policy is required on PE1 to advertise routes to CE1.
  B. An export policy is not required on PE2 to advertise routes to CE2.
  C. An export policy is not required to advertise routes between PE routers
  D. All of the above statements are true
  E. All of the above statements are false
  D. All of the above statements are true

• Question 882:

  Which service is needed to bridge an ATM service to an Ethernet service?

  A. Apipe
  B. Fpipe
  C. Cpipe
  D. Epipe
  E. Bridge service
  D. Epipe

• Question 883:

  What are the two major differences between configuring an IES service and configuring VPWS or VPLS services? (Choose 2)

  A. IES does not support QoS.
  B. IES has a configurable IP-MTU
  C. A virtual route table must be configured for an IES service.
  D. An IES interface has an IP address assigned to it.
  B. IES has a configurable IP-MTU
  D. An IES interface has an IP address assigned to it.

• Question 884:

  Click on the exhibit.



  The route table on router R2 shows the system address of router R5 but it does not show any of the interfaces from the non-OSPF area. What may be causing this?

  A. 'asbr' is missing from router R1's configuration.
  B. Router R1 needs to have an export policy added to it.
  C. Router R5 does not have an export policy for these prefixes.
  D. Router R1 needs to have an import policy added to it.
  C. Router R5 does not have an export policy for these prefixes.

• Question 885:

  Which of the following options are used to configure an MPLS signaling type to be used on an SDP? (Choose 2)

  A. configure service sdp sdp-id gre create
  B. configure service sdp sdp-id create
  C. Idp
  D. Isp Isp-name
  C. Idp
  D. Isp Isp-name

• Question 886:

  Click on the exhibit.



  The OSPF adjacency between routers R1 and R3 does not come up. Which of the following is a possible solution to the problem?

  A. Stub must be configured on Area 1 of router R1, and removed from Area 1 on router R3.
  B. Stub must be configured on Area 1 of router R1 and Area 1 of router R3.
  C. Stub must be configured on Area 0 of router R1 and Area 1 of router R3.
  D. Area 1 of router R3 should be Area 0, in order to connect via stub to router R1.
  B. Stub must be configured on Area 1 of router R1 and Area 1 of router R3.

• Question 887:

  The SAP 1/1/1:2.3 receives an untagged Ethernet frame. Which of the following is TRUE?

  A. The frame is dropped.
  B. VLAN tags 2 and 3 are added to the frame.
  C. Only outer VLAN tag 2 is added.
  D. Only inner VLAN tag 3 is added.
  A. The frame is dropped.

• Question 888:

  An LSP is configured with a fully loose path and CSPF is not enabled. An LSR receives the first PATH message for this LSP. Which of the following is NOT performed by the LSR?

  A. The LSR regenerates and forwards a new PATH message.
  B. The LSR stores the PATH message in the PSB.
  C. The LSR forwards the PATH message based on the HOP object in the RSB.
  D. The LSR looks up the PATH message's destination IP address in the FIB.
  C. The LSR forwards the PATH message based on the HOP object in the RSB.

• Question 889:

  Which of the following is a characteristic of a VPLS?

  A. All SAPs of a VPLS belong to the same broadcast domain.
  B. When a new site is added, all the existing sites need to be shutdown and re-provisioned.
  C. An additional T-LDP session is required between PEs for each additional VPLS that is provisioned.
  D. Multiple VPLSes on the same router share a single MAC FDB.
  A. All SAPs of a VPLS belong to the same broadcast domain.

• Question 890:

  A router has two admin groups defined (GREEN=1 and RED=3). An interface is associated to both admin groups. What value will be shown in the Admin Group sub-TLV for this interface?

  A. 0x4
  B. 0x5
  C. 0x10
  D. 0xa
  D. 0xa
