Cisco 400-201 Online Practice Questions and Exam Preparation

Cisco 400-201 Online Questions & Answers

• Question 401:

  An Enterprise XYZ company has a requirement to extend the MPLS/Layer 3 VPN MAN network to the remote branches using Internet as the transport. Which solution can you provide seamless extension of the MPLS/Layer 3 VPN?

  A. LISP
  B. L2TPv3
  C. Cisco Unified MPLS
  D. 2547oDMVPN
  E. Carrier Supporting Carrier
  D. 2547oDMVPN

• Question 402:

  What is the main different between an SNMP trap and a syslog message?

  A. SNMP traps are formally defined in a MIB, and syslog body contents are not formally defined
  B. SNMP traps are forwarded to EMS systems and syslog messages are forwarded to any NMS system
  C. SNMP traps are user-definable and vary based on vendor and syslog messages are standards-based
  D. SNMP traps are secure, and syslog message are not
  E. SNMP traps are triggered during network outages, and syslog messages are informational only
  A. SNMP traps are formally defined in a MIB, and syslog body contents are not formally defined

• Question 403:

  DRAG DROP

  Drag and drop the IPFIX terminology on the left to the correct description on the right. Not all options will be used.

  Select and Place:





• Question 404:

  In which modes does selective packet discard (SPD) operate? (Choose three.)

  A. discard
  B. random
  C. normal
  D. full
  E. select
  B. random
  C. normal
  D. full

• Question 405:

  Which three options are tasks of the BGP scanner process? (Choose three.)

  A. processing of BGP packets
  B. processing any route "churn"
  C. updating IP RIB
  D. providing BGP Dampening information updates
  E. performing Conditional Advertisement checks
  F. performing BGP synchronization
  G. checking next-hop reachability
  D. providing BGP Dampening information updates
  E. performing Conditional Advertisement checks
  G. checking next-hop reachability

• Question 406:

  Which protocol is used to establish LSP tunnels, enabling resource allocation such as bandwidth along the path?

  A. LDP
  B. RSVP
  C. TDP
  D. IPsec
  B. RSVP

• Question 407:

  Which three of these options can be a forwarding equivalence class? (Choose three.)

  A. groups of IP addresses
  B. bridge or switch instance
  C. traffic engineering tunnel
  D. IPsec tunnel
  E. routing equivalence paths
  F. a bgp prefix
  A. groups of IP addresses
  B. bridge or switch instance
  C. traffic engineering tunnel

• Question 408:

  Company_X provides Layer 3 VPN services using BGP as PE-CE routing protocol. Company_X has a requirement to improve the convergence time in an event of fiber connection failure in the backbone. Which two technologies meet these requirements? (Choose two.)

  A. BGP PIC
  B. BGP support for BFD
  C. MPLS LDP IGP Synchronization
  D. MPLS TE autotunnel backup with SRLGs
  E. SSO/NSF
  A. BGP PIC
  B. BGP support for BFD

• Question 409:

  What statement is true?

  A. Link Control Protocol (LCP) is used for denying PPP connections to unauthorized devices.
  B. Link Control Protocol (LCP) is used for basic PPP link setup and operation
  C. Link Control Protocol (LCP) for PPP is synonymous to ARP for Ethernet.
  D. None of the above.
  B. Link Control Protocol (LCP) is used for basic PPP link setup and operation

• Question 410:

  Which statement about implementing the Cisco IPv6 provider Edge Router over MPLS is true?

  A. 6PE feature is supported over tunnels other than RSVP-TE tunnels.
  B. Core MPLS routers are supporting IPv6 only.
  C. 6PE feature is not supported over tunnels other than RSVP-TE tunnels.
  D. Core MPLS routers are supporting IPv4 only.
  C. 6PE feature is not supported over tunnels other than RSVP-TE tunnels.
