• Question 331:

  Calculate the gain of an amplifier if 1 watt is applied to the input and 2 watts is measured at the output:

  A. 0.5 dB
  B. 1 dB
  C. 2dB
  D. 3dB
  E. 4dB
  D. 3dB

• Question 332:

  If the PMD coefficient of a given fiber is 4 ps and the distance under consideration is 625Km calculate the effect of dispersion (differential group delay) due to PMD.

  A. 100ps
  B. 200ps
  C. 50ps
  D. 150ps
  A. 100ps

• Question 333:

  Click the Exhibit button to view the topology.



  Host 1 and Host 2 are on Ethernet LANs in different buildings. A serial line is installed between two Cisco routers using Cisco HDLC serial line encapsulation. Routers A and B are configured to route IP traffic. Host 1 sends a packet to Host 2. A line hit on the serial line causes an error in the packet. When this is detected, the retransmission is sent by:

  A. Host 1
  B. Host2
  C. Router A
  D. RouterB
  E. Protocol analyzer
  A. Host 1

• Question 334:

  How many bytes are dedicated to the Path Overhead in an STS-3 Frame?

  A. 3
  B. 6
  C. 9
  D. 18
  E. 24
  C. 9

• Question 335:

  When using IS-IS for IP routing, Dual IS-IS defined by RFC 1195, what is true? (multiple answer)

  A. It is necessary to configure a NSAP address.
  B. It is not possible to perform both IP and CLNS routing with the same process.
  C. IP address and subnet information is carried in the TLVfield on the L-1/L-1 LSPs.
  D. Dual IS-IS does not support VLSM information.
  A. It is necessary to configure a NSAP address.
  C. IP address and subnet information is carried in the TLVfield on the L-1/L-1 LSPs.

• Question 336:

  What is NOT a characteristic of Direct attached Storage (DAS)?

  A. High speed
  B. Low latency
  C. Limited distance
  D. Re-routable protection
  D. Re-routable protection

• Question 337:

  How many E-1s can be aggregated (maximum) and mapped into a VC-12 Signal?

  A. 1
  B. 7
  C. 14
  D. 28
  E. 32
  A. 1

• Question 338:

  In SDH, what is the meaning of S-16.1 defining an interface?

  A. S-16forSTM-16, 1 for Short Haul
  B. S for Short Haul, 16forSTM-16,1 for 1-port card
  C. S for Short Haul, 16forSTM-16,1 for 1310 nm
  D. S for Short Haul, 16forSTM-16,1 for 1st port on card
  C. S for Short Haul, 16forSTM-16,1 for 1310 nm

• Question 339:

  In SDH the function of the K1-K2 bytes is to:

  A. Specify the level of synchronization of the signal
  B. Provide a 64kbit/s voice channel for communication between multiplexers
  C. Provide multiplexer section error monitoring using bit interleaved parity
  D. Provide automatic protection switching signaling between two MSTEs
  D. Provide automatic protection switching signaling between two MSTEs

• Question 340:

  OSPF is defined on a Frame Relay interface providing point-to-multipoint connections. The remote neighbors can reach this central site, but are complaining of routing failures between each of the remote sites. The central router has all the routes for each remote site. Based on this information, what can be diagnosed as the biggest potential problem?

  A. An over-subscribed Frame Relay switch will cause some packet loss.
  B. There are problems in the use of OSPF Authentication.
  C. There is an incorrect selection of the Designated Router.
  D. There is an incorrect DLCI assigned on a point-to-point sub-interface.
  C. There is an incorrect selection of the Designated Router.
